Wind Top AE2020
Model Wind Top AE2020Part no. AE2020-092ES
79 specifications
- Display50.8 cm (20")
- Resolution1600 x 900 pixels
- ProcessorIntel® Pentium® Dual-Core
- Memory3 GB
- Storage320 GB
- GraphicsNVIDIA® GeForce® 9300
Overview
- Display
- 50.8 cm (20")
- Resolution
- 1600 x 900 pixels
- Processor
- Intel® Pentium® Dual-Core
- Memory
- 3 GB
- Storage
- 320 GB
- Graphics
- NVIDIA® GeForce® 9300
- Brand
- MSI
- Category
- PCs/Workstations
- Model
- Wind Top AE2020
- Part number
- AE2020-092ES
- Also known as
- MSI Wind Top AE2020 Intel® Pentium® Dual-Core T4500 3 GB DDR2-SDRAM 320 GB NVIDIA® GeForce® 9300 Windows 7 Home Premium Tower PC Black
Specifications
79 specifications in 17 groups
Processor
| Specification | Value |
|---|---|
| Processor manufacturer | Intel |
| Processor family | Intel® Pentium® Dual-Core |
| Processor model | T4500 |
| Processor cores | 2 |
| Processor threads | 2 |
| Processor frequency | 2.3 GHz |
| Processor cache | 1 MB |
| Processor cache type | Smart Cache |
| Processor front side bus | 800 MHz |
| Processor lithography | 45 nm |
| Processor operating modes | 64-bit |
| Processor codename | Penryn |
| Thermal Design Power (TDP) | 35 W |
| Number of processors installed | 1 |
| Number of Processing Die Transistors | 410 M |
| Processing Die size | 107 mm² |
Memory
| Specification | Value |
|---|---|
| Internal memory | 3 GB |
| Maximum internal memory | 8 GB |
| Internal memory type | DDR2-SDRAM |
| Memory layout (slots x size) | 1 x 1 + 1 x 2 GB |
| Memory clock speed | 800 MHz |
Storage
| Specification | Value |
|---|---|
| Total storage capacity | 320 GB |
| Optical drive type | DVD Super Multi DL |
| Number of HDDs installed | 1 |
| HDD interface | SATA II |
| Card reader integrated | Yes |
| Compatible memory cards | MMC, SD, SDHC, XD |
| Floppy drive installed | No |
Graphics
| Specification | Value |
|---|---|
| On-board graphics card | Yes |
| Discrete graphics card model | NVIDIA® GeForce® 9300 |
| Discrete graphics card memory | 0.256 GB |
| Graphics card family | NVIDIA |
Performance
| Specification | Value |
|---|---|
| Product type | PC |
| Motherboard chipset | NVIDIA® ION™ |
Network
| Specification | Value |
|---|---|
| Ethernet LAN | Yes |
| Ethernet LAN data rates | 1000 Mbit/s |
| Wi-Fi | Yes |
| Networking features | Gigabit Ethernet, WLAN |
| Wireless technology | 802.11 b/g/n |
Ports & interfaces
| Specification | Value |
|---|---|
| USB 2.0 ports quantity | 6 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 0 |
| HDMI ports quantity | 1 |
| Ethernet LAN (RJ-45) ports | 1 |
| Headphone outputs | 1 |
| Microphone in | Yes |
| VGA (D-Sub) ports quantity | 1 |
| DVI port | No |
| PS/2 ports quantity | 0 |
| Firewire (IEEE 1394) ports | 0 |
| eSATA ports quantity | 1 |
| Serial ports quantity | 0 |
| Parallel ports quantity | 0 |
Power
| Specification | Value |
|---|---|
| Power supply | 120 W |
Design
| Specification | Value |
|---|---|
| Chassis type | Tower |
| Product colour | Black |
Software
| Specification | Value |
|---|---|
| Operating system installed | Windows 7 Home Premium |
Display
| Specification | Value |
|---|---|
| Display included | Yes |
| Display diagonal | 50.8 cm (20") |
| Display resolution | 1600 x 900 pixels |
| Touchscreen | Yes |
| Display | WSXGA+ |
Processor special features
| Specification | Value |
|---|---|
| Embedded options available | No |
| Enhanced Intel SpeedStep Technology | Yes |
| Execute Disable Bit | Yes |
| Intel 64 | Yes |
| Intel Trusted Execution Technology | No |
| Intel Virtualization Technology (VT-x) | No |
| Processor ARK ID | 42925 |
| Processor code | SLGZC |
| Thermal Monitoring Technologies | Yes |
| Intel® Turbo Boost Technology | No |
Audio
| Specification | Value |
|---|---|
| Audio system | SRS Premium Sound |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 509.7 mm |
| Depth | 54.7 mm |
| Height | 392.6 mm |
| Weight | 7.31 kg |
Packaging content
| Specification | Value |
|---|---|
| Remote control included | No |
Multimedia
| Specification | Value |
|---|---|
| Built-in camera | Yes |
Other features
| Specification | Value |
|---|---|
| TV tuner integrated | No |
