MSI N 8GL-018XRU

Model N 8GL-018XRUPart no. 9S6-B17111-018

106 specifications

Overview

Brand: MSI
Category: PCs/Workstations
Model: N 8GL-018XRU
Part number: 9S6-B17111-018
Also known as: MSI Cubi N 8GL-018XRU Intel® Celeron® N4000 4 GB DDR4-SDRAM 256 GB SSD Mini PC Black

106 specifications in 15 groups

Specification	Value
Processor manufacturer	Intel
Processor family	Intel® Celeron®
Processor model	N4000
Processor cores	2
Processor threads	2
Processor boost frequency	2.6 GHz
Processor frequency	1.1 GHz
Processor cache	4 MB
Processor lithography	14 nm
Processor operating modes	64-bit
Processor codename	Gemini Lake
Thermal Design Power (TDP)	6 W
Scenario Design Power (SDP)	4.8 W
Tjunction	105 °C
Maximum number of PCI Express lanes	6
PCI Express configurations	1x2, 1x2+2x1, 1x4, 2x1, 4x1
PCI Express slots version	2.0
Number of processors installed	1
Processor socket	BGA 1090
Maximum internal memory supported by processor	8 GB
Memory types supported by processor	DDR4-SDRAM, LPDDR4-SDRAM
Memory clock speeds supported by processor	2400 MHz
ECC supported by processor	No

Specification	Value
Discrete graphics card	No
On-board graphics card	Yes
Discrete graphics card model	Not available
On-board graphics card model	Intel® UHD Graphics 600
Maximum on-board graphics card memory	8 GB
Number of displays supported (on-board graphics)	3
On-board graphics card base frequency	200 MHz
On-board graphics card burst frequency	650 MHz
On-board graphics card dynamic frequency (max)	650 MHz
On-board graphics card DirectX version	12.0
On-board graphics card ID	0x3185
Number of execution units	12

Specification	Value
Product type	Mini PC

Specification	Value
USB 2.0 ports quantity	0
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	4
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity	0
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity	0
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity	0
Thunderbolt 3 ports quantity	0
HDMI ports quantity	1
HDMI version	2.0
Ethernet LAN (RJ-45) ports	1
Combo headphone/mic port	Yes
Headphone outputs	0
Microphone in	No
VGA (D-Sub) ports quantity	1
DVI port	No

Specification	Value
Power supply	40 W

Specification	Value
Chassis type	Mini PC
Product colour	Black

Specification	Value
Operating system installed	No

Specification	Value
Display included	No

Specification	Value
CPU configuration (max)	1
Embedded options available	No
Enhanced Intel SpeedStep Technology	Yes
Execute Disable Bit	Yes
Idle States	Yes
Intel 64	Yes
Intel Enhanced Halt State	Yes
Intel Identity Protection Technology version	1.00
Intel Secure Key Technology version	1.00
Intel Smart Response Technology version	0.00
Intel Software Guard Extensions (Intel SGX)	Yes
Intel VT-x with Extended Page Tables (EPT)	Yes
Intel Virtualization Technology (VT-x)	Yes
Intel Virtualization Technology for Directed I/O (VT-d)	Yes
Intel® AES New Instructions (Intel® AES-NI)	Yes
Intel® OS Guard	Yes
Intel® Secure Key	Yes
Processor ARK ID	128988
Processor package size	25 x 24 mm
Thermal Monitoring Technologies	Yes
UART	Yes
Intel® Smart Response Technology	No
Intel® Turbo Boost Technology	No
Intel® Hyper Threading Technology (Intel® HT Technology)	No
Intel® Quick Sync Video Technology	Yes
Intel® Identity Protection Technology (Intel® IPT)	Yes
Intel® Anti-Theft Technology (Intel® AT)	No
Conflict-Free processor	Yes

Specification	Value
Package weight	1.36 kg

Specification	Value
AC adapter included	Yes
