MSI Cubi 3 (Silent) S-004

Model Cubi 3 (Silent) S-004Part no. 9S6-B15921-004EAN 4719072543068

78 specifications

Overview

Brand: MSI
Category: PCs/Workstations
Model: Cubi 3 (Silent) S-004
Part number: 9S6-B15921-004
EAN / UPC: 4719072543068
Also known as: MSI Cubi 3 (Silent) S-004 Intel® Pentium® 4 GB DDR4-SDRAM 32 GB SSD Windows 10 Home PC Black

78 specifications in 13 groups

Specification	Value
Processor manufacturer	Intel
Processor family	Intel® Pentium®
Processor cores	2
Processor threads	4
Processor frequency	2.3 GHz
Processor cache	2 MB
Processor cache type	Smart Cache
Bus type	OPI
System bus rate	4 GT/s
Processor lithography	14 nm
Processor operating modes	64-bit
Thermal Design Power (TDP)	15 W
Configurable TDP-down	10 W
Tjunction	100 °C
Maximum number of PCI Express lanes	10
PCI Express configurations	1x2+2x1, 1x4, 2x2, 4x1
PCI Express slots version	2.0
Number of processors installed	1
Processor socket	BGA 1356
Maximum internal memory supported by processor	32 GB
Memory types supported by processor	DDR3L-SDRAM, DDR4-SDRAM, LPDDR3-SDRAM
Memory clock speeds supported by processor	1600,1866,2133 MHz
Memory bandwidth supported by processor (max)	34.1 GB/s
ECC supported by processor	No

Specification	Value
Discrete graphics card	No
On-board graphics card	Yes
Discrete graphics card model	Not available
On-board graphics card family	Intel® HD Graphics
On-board graphics card model	Intel® HD Graphics 610
Number of displays supported (on-board graphics)	3
On-board graphics card base frequency	300 MHz
On-board graphics card dynamic frequency (max)	950 MHz
On-board graphics card DirectX version	12.0
On-board graphics card OpenGL version	4.4

Specification	Value
Product type	PC

Specification	Value
USB 2.0 ports quantity	0
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	4
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity	0
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity	0
Thunderbolt 3 ports quantity	0
DisplayPorts quantity	1
HDMI ports quantity	1
Ethernet LAN (RJ-45) ports	1
Headphone outputs	1
Microphone in	Yes
VGA (D-Sub) ports quantity	0
DVI port	No
DC-in jack	Yes

Specification	Value
Power supply	65 W

Specification	Value
Operating system installed	Windows 10 Home

Specification	Value
Display included	No

Specification	Value
Conflict-Free processor	Yes
