MSI Wind Box 9A19-2716 Intel Pentium Mobile N270

1 GB DDR2-SDRAM 160 GB HDD SFF Mini PC Black

Model 9A19-2716Part no. 009A19-010REAN 4719072171353

120 specifications

ProcessorIntel Pentium Mobile
Memory1 GB
Storage160 GB
GraphicsNot available
TypeMini PC
OSNo

See all specifications

Overview

Processor: Intel Pentium Mobile
Memory: 1 GB
Storage: 160 GB
Graphics: Not available
Type: Mini PC
OS: No

Brand: MSI
Category: PCs/Workstations
Model: 9A19-2716
Part number: 009A19-010R
EAN / UPC: 4719072171353
Also known as: MSI Wind Box 9A19-2716 Intel Pentium Mobile N270 1 GB DDR2-SDRAM 160 GB HDD SFF Mini PC Black

Specifications

120 specifications in 17 groups

Processor

Specification	Value
Processor manufacturer	Intel
Processor family	Intel Pentium Mobile
Processor model	N270
Processor cores	1
Processor threads	2
Processor frequency	1.6 GHz
Processor cache	0.512 MB
Processor cache type	L2
Processor front side bus	533 MHz
Bus type	FSB
FSB Parity	No
Processor lithography	45 nm
Processor operating modes	32-bit
Processor series	Intel Atom N200 Series
Processor codename	Diamondville
Thermal Design Power (TDP)	2.5 W
Tjunction	90 °C
Number of processors installed	1
Processor socket	Socket F (1207)
Number of Processing Die Transistors	47 M
Processing Die size	26 mm²
CPU multiplier (bus/core ratio)	12
Stepping	C0
ECC supported by processor	No

Memory

Specification	Value
Internal memory	1 GB
Maximum internal memory	2 GB
Internal memory type	DDR2-SDRAM
Memory layout (slots x size)	1 x 1 GB
Memory slots	1x SO-DIMM

Storage

Specification	Value
Total storage capacity	160 GB
Optical drive type	No
Storage media	HDD
HDD capacity	160 GB
HDD interface	SATA II
HDD size	2.5"

Graphics

Specification	Value
On-board graphics card	Yes
Discrete graphics card model	Not available
On-board graphics card family	Intel® GMA
On-board graphics card model	Intel® GMA 950
Graphics card family	Intel

Performance

Specification	Value
Product type	Mini PC
Motherboard chipset	Intel G945GC Express
Motherboard southbridge	Intel ICH7

Network

Specification	Value
Ethernet LAN	Yes
Ethernet LAN data rates	10,100,1000 Mbit/s
Cabling technology	10/100/1000Base-T(X)
Wi-Fi	No
Ethernet interface type	Gigabit Ethernet

Ports & interfaces

Specification	Value
USB 2.0 ports quantity	2
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	0
HDMI ports quantity	0
Ethernet LAN (RJ-45) ports	2
Combo headphone/mic port	No
Headphone outputs	0
Microphone in	No
VGA (D-Sub) ports quantity	0
DVI port	Yes
PS/2 ports quantity	0
Firewire (IEEE 1394) ports	0
S/PDIF out port	No
DC-in jack	Yes
SmartCard slot	No
Serial ports quantity	0
Parallel ports quantity	0
COM ports quantity	4

Expansion slots

Specification	Value
PCI Express x1 slots	1

Power

Specification	Value
Power supply	36 W
Power supply input voltage	12 V

Design

Specification	Value
Chassis type	SFF
Product colour	Black
Cooling type	Passive

Software

Specification	Value
Operating system installed	No

Display

Specification	Value
Display included	No

Processor special features

Specification	Value
Embedded options available	Yes
Enhanced Intel SpeedStep Technology	Yes
Execute Disable Bit	Yes
Idle States	No
Intel 64	No
Intel Clear Video Technology	No
Intel Demand Based Switching	No
Intel Dual Display Capable Technology	No
Intel Enhanced Halt State	No
Intel FDI Technology	No
Intel Fast Memory Access	No
Intel Flex Memory Access	No
Intel Rapid Storage Technology	No
Intel Trusted Execution Technology	No
Intel VT-x with Extended Page Tables (EPT)	No
Intel Virtualization Technology (VT-x)	No
Intel Virtualization Technology for Directed I/O (VT-d)	No
Intel® AES New Instructions (Intel® AES-NI)	No
Intel® Clear Video HD Technology (Intel® CVT HD)	No
Intel® Clear Video Technology for Mobile Internet Devices (Intel CVT for MID)	No
Intel® InTru™ 3D Technology	No
Intel® Insider™	No
Intel® Small Business Advantage (Intel® SBA)	No
Intel® Wireless Display (Intel® WiDi)	No
Processor ARK ID	36331
Processor code	SLB73
Processor package size	22 x 22 mm
Supported instruction sets	SSE2, SSE3
Thermal Monitoring Technologies	Yes
Intel® Smart Response Technology	No
Intel® Turbo Boost Technology	No
Intel® Hyper Threading Technology (Intel® HT Technology)	Yes
Intel® Quick Sync Video Technology	No
Intel® My WiFi Technology (Intel® MWT)	No
Intel® Identity Protection Technology (Intel® IPT)	No
Intel® Anti-Theft Technology (Intel® AT)	No
Conflict-Free processor	No

Operational conditions

Specification	Value
Operating temperature (T-T)	0 - 40 °C
Storage temperature (T-T)	-20 - 80 °C

Weight & dimensions

Specification	Value
Width	210 mm
Depth	100 mm
Height	50 mm
Weight	1.17 kg

Packaging content

Specification	Value
Cables included	AC
AC adapter included	Yes

Certificates

Specification	Value
Compliance certificates	RoHS
Certification	CE, FCC, BSMI, VCCI,C-tick
