ThinkCentre M625
Model ThinkCentre M625Part no. 10UYS1RA16
51 specifications
- ProcessorA4-9120e
- Memory8 GB
- Storage128 GB
- TypeMini PC
- OSWindows 10 IoT Enterprise
- Weight1.3 kg
Overview
- Processor
- A4-9120e
- Memory
- 8 GB
- Storage
- 128 GB
- Type
- Mini PC
- OS
- Windows 10 IoT Enterprise
- Weight
- 1.3 kg
- Brand
- Lenovo
- Category
- PCs/Workstations
- Model
- ThinkCentre M625
- Part number
- 10UYS1RA16
- Also known as
- Lenovo ThinkCentre M625 A4-9120e 8 GB DDR4-SDRAM 128 GB SSD Windows 10 IoT Enterprise Mini PC Black
Specifications
51 specifications in 15 groups
Processor
| Specification | Value |
|---|---|
| Processor manufacturer | AMD |
| Processor model | A4-9120e |
| Processor cores | 2 |
| Processor boost frequency | 2.2 GHz |
| Processor frequency | 1.5 GHz |
| L2 cache | 1 MB |
Memory
| Specification | Value |
|---|---|
| Internal memory | 8 GB |
| Maximum internal memory | 8 GB |
| Internal memory type | DDR4-SDRAM |
| Memory layout (slots x size) | 1 x 8 GB |
| Memory slots | 1x SO-DIMM |
| Memory clock speed | 2666 MHz |
Storage
| Specification | Value |
|---|---|
| Total storage capacity | 128 GB |
| Storage media | SSD |
| SSD memory type | TLC |
| SSD form factor | M.2 |
| Card reader integrated | No |
Graphics
| Specification | Value |
|---|---|
| On-board graphics card model | AMD Radeon R3 |
Performance
| Specification | Value |
|---|---|
| Product type | Mini PC |
| Built-in speaker(s) | Yes |
Network
| Specification | Value |
|---|---|
| Ethernet LAN | Yes |
| Cabling technology | 10/100/1000Base-T(X) |
| Wi-Fi | Yes |
| Wi-Fi standards | Wi-Fi 5 (802.11ac) |
| Bluetooth | Yes |
| Bluetooth version | 5.0 |
Ports & interfaces
| Specification | Value |
|---|---|
| USB 2.0 ports quantity | 3 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 3 |
| DisplayPorts quantity | 2 |
| Ethernet LAN (RJ-45) ports | 1 |
| Combo headphone/mic port | Yes |
| Headphone outputs | 1 |
| Microphone in | Yes |
Power
| Specification | Value |
|---|---|
| Power supply | 65 W |
Design
| Specification | Value |
|---|---|
| Panel mounting interface | 75 x 100 mm |
| VESA mounting | Yes |
| Product colour | Black |
Software
| Specification | Value |
|---|---|
| Operating system installed | Windows 10 IoT Enterprise |
Display
| Specification | Value |
|---|---|
| Display included | No |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 5 - 35 °C |
| Storage temperature (T-T) | -40 - 60 °C |
| Operating relative humidity (H-H) | 20 - 80% |
| Storage relative humidity (H-H) | 10 - 90% |
| Operating altitude | 0 - 3048 m |
| Non-operating altitude | 0 - 12192 m |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 179 mm |
| Depth | 182.9 mm |
| Height | 34.5 mm |
| Weight | 1.3 kg |
Packaging content
| Specification | Value |
|---|---|
| Mouse included | Yes |
Certificates
| Specification | Value |
|---|---|
| Certification | ENERGY STAR® 8.0 ErP Lot 3 TCO RoHS compliant WEEE |
