Lenovo ThinkCentre A58 + ThinkVision L197w

Model ThinkCentre A58 + ThinkVision L197wPart no. SMKP1FR+T44HNEU

114 specifications

Display48.3 cm (19")
Resolution1440 x 900 pixels
ProcessorIntel® Pentium®
Memory2 GB
Storage320 GB
GraphicsIntel® GMA X4500

See all specifications

Overview

Display: 48.3 cm (19")
Resolution: 1440 x 900 pixels
Processor: Intel® Pentium®
Memory: 2 GB
Storage: 320 GB
Graphics: Intel® GMA X4500

Brand: Lenovo
Category: PCs/Workstations
Model: ThinkCentre A58 + ThinkVision L197w
Part number: SMKP1FR+T44HNEU
Also known as: Lenovo ThinkCentre A58 + ThinkVision L197w Intel® Pentium® E5400 2 GB DDR2-SDRAM 320 GB Intel® GMA X4500 Windows 7 Professional Tower PC Black

Specifications

114 specifications in 18 groups

Processor

Specification	Value
Processor manufacturer	Intel
Processor family	Intel® Pentium®
Processor model	E5400
Processor cores	2
Processor threads	2
Processor frequency	2.7 GHz
Processor cache	2 MB
Processor cache type	L2
Processor front side bus	800 MHz
Bus type	FSB
FSB Parity	No
Processor lithography	45 nm
Processor operating modes	64-bit
Processor series	Intel Pentium E5000 Series for Desktop
Processor codename	Wolfdale
Thermal Design Power (TDP)	45, 65
Tcase	74.1 °C
Number of processors installed	1
Processor socket	LGA 775 (Socket T)
Number of Processing Die Transistors	228 M
Processing Die size	82 mm²
CPU multiplier (bus/core ratio)	13.5
Stepping	R0
ECC supported by processor	No

Memory

Specification	Value
Internal memory	2 GB
Maximum internal memory	4 GB
Internal memory type	DDR2-SDRAM
Memory layout (slots x size)	1 x 2 GB
Memory clock speed	667 MHz

Storage

Specification	Value
Total storage capacity	320 GB
Optical drive type	DVD-RW
HDD interface	SATA
HDD speed	7200 RPM
Card reader integrated	No
Floppy drive installed	No

Graphics

Specification	Value
On-board graphics card	Yes
Discrete graphics card model	Intel® GMA X4500
Graphics card family	Intel

Performance

Specification	Value
Product type	PC

Network

Specification	Value
Ethernet LAN	Yes
Wi-Fi	No
Networking features	Gigabit Ethernet

Ports & interfaces

Specification	Value
USB 2.0 ports quantity	8
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	0
HDMI ports quantity	0
Ethernet LAN (RJ-45) ports	1
Headphone outputs	1
Line-out	Yes
Line-in	Yes
Microphone in	Yes
VGA (D-Sub) ports quantity	1
DVI port	No
PS/2 ports quantity	2
Firewire (IEEE 1394) ports	0
Serial ports quantity	1
Parallel ports quantity	1

Expansion slots

Specification	Value
PCI Express x1 slots	1
PCI Express x16 slots	1

Power

Specification	Value
Power supply	450 W

Design

Specification	Value
Chassis type	Tower
Product colour	Black

Software

Specification	Value
Operating system installed	Windows 7 Professional
Optional operating system supplied	Windows XP Professional

Display

Specification	Value
Display included	Yes
Display diagonal	48.3 cm (19")
Display resolution	1440 x 900 pixels
Contrast ratio (typical)	1000:1
Touchscreen	No

Processor special features

Specification	Value
CPU configuration (max)	1
Embedded options available	No
Enhanced Intel SpeedStep Technology	Yes
Execute Disable Bit	Yes
Idle States	Yes
Intel 64	Yes
Intel Clear Video Technology	No
Intel Demand Based Switching	No
Intel Dual Display Capable Technology	No
Intel Enhanced Halt State	Yes
Intel FDI Technology	No
Intel Fast Memory Access	No
Intel Flex Memory Access	No
Intel Rapid Storage Technology	No
Intel Trusted Execution Technology	No
Intel VT-x with Extended Page Tables (EPT)	No
Intel Virtualization Technology (VT-x)	2
Intel Virtualization Technology for Directed I/O (VT-d)	No
Intel® AES New Instructions (Intel® AES-NI)	No
Intel® Clear Video HD Technology (Intel® CVT HD)	No
Intel® Clear Video Technology for Mobile Internet Devices (Intel CVT for MID)	No
Intel® InTru™ 3D Technology	No
Intel® Insider™	No
Intel® Wireless Display (Intel® WiDi)	No
Processor ARK ID	40478
Processor code	SLGH7
Processor package size	37.5 x 37.5 mm
Thermal Monitoring Technologies	Yes
Intel® Turbo Boost Technology	No
Intel® Hyper Threading Technology (Intel® HT Technology)	No
Intel® Quick Sync Video Technology	No
Intel® My WiFi Technology (Intel® MWT)	No
Intel® Anti-Theft Technology (Intel® AT)	No
Conflict-Free processor	No

Audio

Specification	Value
Audio system	Realtek ALC662

Operational conditions

Specification	Value
Operating temperature (T-T)	10 - 35 °C
Storage temperature (T-T)	-10 - 60 °C
Operating relative humidity (H-H)	10 - 80%
Non-operating relative humidity (non-condensing)	10 - 90%

Weight & dimensions

Specification	Value
Width	175 mm
Depth	442 mm
Height	412 mm
Weight	11.2 kg

Packaging content

Specification	Value
Remote control included	No

Other features

Specification	Value
TV tuner integrated	No
Drive bays	3x 3.5", 2x 5.25"
