P920 Rack
Model P920 RackPart no. 7X06WJHL00
63 specifications
- ProcessorIntel Xeon Silver
- Memory64 GB
- Storage1.96 TB
- GraphicsNVIDIA Quadro RTX 4000
- TypeWorkstation
- OSNo
Overview
- Processor
- Intel Xeon Silver
- Memory
- 64 GB
- Storage
- 1.96 TB
- Graphics
- NVIDIA Quadro RTX 4000
- Type
- Workstation
- OS
- No
- Brand
- Lenovo
- Category
- PCs/Workstations
- Model
- P920 Rack
- Part numbers
- 7X06WJHL00, 7X06WJHN00, 7X06WJHQ00, 7X06WJHS00, 7X06WJHY00, 7X06WJHT00
- Also known as
- Lenovo ThinkStation P920 Rack Intel Xeon Silver 4208 64 GB DDR4-SDRAM 1.96 TB HDD+SSD NVIDIA Quadro RTX 4000 Rack-mounted chassis Workstation Black
Specifications
63 specifications in 13 groups
Processor
| Specification | Value |
|---|---|
| Processor manufacturer | Intel |
| Processor family | Intel Xeon Silver |
| Processor generation | 2nd Generation Intel® Xeon® Scalable |
| Processor model | 4208 |
| Processor cores | 8 |
| Processor threads | 16 |
| Processor boost frequency | 3.2 GHz |
| Processor frequency | 2.1 GHz |
| Processor cache | 11 MB |
| Number of processors installed | 2 |
Memory
| Specification | Value |
|---|---|
| Internal memory | 64 GB |
| Maximum internal memory | 768 GB |
| Internal memory type | DDR4-SDRAM |
| Memory slots | 24x DIMM |
| Memory clock speed | 2933 MHz |
| ECC | Yes |
Storage
| Specification | Value |
|---|---|
| Total storage capacity | 1.96 TB |
| Optical drive type | No |
| Storage media | HDD+SSD |
| Number of storage drives installed | 3 |
| Total HDDs capacity | 1 TB |
| Number of HDDs installed | 1 |
| HDD interface | SATA III |
| HDD speed | 7200 RPM |
| HDD size | 3.5" |
| Total SSDs capacity | 960 GB |
| Number of SSDs installed | 2 |
| SSD capacity | 480 GB |
| SSD form factor | M.2 |
| Card reader integrated | No |
| RAID support | Yes |
| RAID levels | 0, 1, 50, 5, 10 |
Graphics
| Specification | Value |
|---|---|
| Discrete graphics card | Yes |
| On-board graphics card | No |
| Discrete graphics card model | NVIDIA Quadro RTX 4000 |
| Discrete graphics card memory | 8 GB |
| Number of discrete graphics cards | 1 |
| On-board graphics card model | Not available |
| Graphics card DisplayPorts quantity | 3 |
Performance
| Specification | Value |
|---|---|
| Product type | Workstation |
| Motherboard chipset | Intel® C624 |
| Password protection | Yes |
| Password protection type | Power on, Supervisor |
| Trusted Platform Module (TPM) | Yes |
Network
| Specification | Value |
|---|---|
| Ethernet LAN | Yes |
| Wi-Fi | No |
| Bluetooth | No |
Ports & interfaces
| Specification | Value |
|---|---|
| USB 2.0 ports quantity | 1 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 3 |
| Ethernet LAN (RJ-45) ports | 1 |
| VGA (D-Sub) ports quantity | 1 |
Power
| Specification | Value |
|---|---|
| Power supply | 1100 W |
Design
| Specification | Value |
|---|---|
| Chassis type | Rack-mounted chassis |
| Placement supported | Horizontal |
| Product colour | Black |
Software
| Specification | Value |
|---|---|
| Operating system installed | No |
Display
| Specification | Value |
|---|---|
| Display included | No |
Operational conditions
| Specification | Value |
|---|---|
| Storage temperature (T-T) | -10 - 60 °C |
| Storage relative humidity (H-H) | 8 - 90% |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 445 mm |
| Depth | 720 mm |
| Height | 87 mm |
| Weight | 32 kg |
