Lenovo ThinkStation P920 Intel® Xeon® Gold 5118

32 GB DDR4-SDRAM 1.51 TB HDD+SSD Windows 10 Pro Desktop Workstation Black

Model P920Part no. 30BC002FUSEAN 193124251967

123 specifications

ProcessorIntel® Xeon® Gold
Memory32 GB
Storage1.51 TB
TypeWorkstation
OSWindows 10 Pro
ColourBlack

See all specifications

Overview

Processor: Intel® Xeon® Gold
Memory: 32 GB
Storage: 1.51 TB
Type: Workstation
OS: Windows 10 Pro
Colour: Black

Brand: Lenovo
Category: PCs/Workstations
Model: P920
Part numbers: 30BC002FUS, 30BC000DUS, 30BC000EUS, 30BC000FUS, 30BC000VUS, 30BC000WUS +34 more
EAN / UPC: 193124251967, 192076218233, 192076218189, 192076218127 +47 more
Also known as: Lenovo ThinkStation P920 Intel® Xeon® Gold 5118 32 GB DDR4-SDRAM 1.51 TB HDD+SSD Windows 10 Pro Desktop Workstation Black

Specifications

123 specifications in 19 groups

Processor

Specification	Value
Processor manufacturer	Intel
Processor family	Intel® Xeon® Gold
Processor generation	1st Generation Intel® Xeon® Scalable
Processor model	5118
Processor cores	12
Processor threads	24
Processor boost frequency	3.2 GHz
Processor frequency	2.3 GHz
Processor cache	16.5 MB
Processor cache type	L3
Bus type	UPI
Processor lithography	14 nm
Processor operating modes	64-bit
Processor codename	Skylake
Thermal Design Power (TDP)	105 W
Tcase	81 °C
Maximum number of PCI Express lanes	48
PCI Express slots version	3.0
Number of QPI links	2
Number of processors installed	2
Processor socket	LGA 3647 (Socket P)
Stepping	M0
Maximum internal memory supported by processor	768 GB
Memory types supported by processor	DDR4-SDRAM
Memory clock speeds supported by processor	2666 MHz
ECC supported by processor	Yes

Memory

Specification	Value
Internal memory	32 GB
Maximum internal memory	512 GB
Internal memory type	DDR4-SDRAM
Memory layout (slots x size)	2 x 16 GB
Memory slots	8x DIMM
Memory clock speed	2666 MHz
ECC	Yes
Memory channels	Hexa-channel
Non-ECC	No

Storage

Specification	Value
Total storage capacity	1.51 TB
Optical drive type	DVD±RW
Storage media	HDD+SSD
Number of storage drives installed	2
Number of HDDs installed	1
HDD capacity	1 TB
HDD interface	SATA III
HDD speed	7200 RPM
HDD size	3.5"
Number of SSDs installed	1
SSD capacity	512 GB
SSD interface	M.2
Card reader integrated	Yes
Intel® Optane™ Memory module installed	No
RAID support	Yes
RAID levels	0, 1, 5, 10

Performance

Specification	Value
Product type	Workstation
Motherboard chipset	Intel® C621
Password protection	Yes
Password protection type	Supervisor
BIOS type	UEFI
Trusted Platform Module (TPM)	Yes
Audio output channels	5.1 channels

Optical drive

Specification	Value
Optical drives quantity	1

Network

Specification	Value
Ethernet LAN	Yes
Ethernet LAN data rates	1000 Mbit/s
Cabling technology	10/100/1000Base-T(X)

Ports & interfaces

Specification	Value
USB 2.0 ports quantity	2
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	8
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity	0
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity	0
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity	0
Thunderbolt 3 ports quantity	0
Ethernet LAN (RJ-45) ports	2
Line-out	Yes
Line-in	Yes
Microphone in	Yes
PS/2 ports quantity	2
Number of speaker outputs	3
On/off button	Yes

Expansion slots

Specification	Value
Number of 3.5" bays	4
PCI Express x4 (Gen 3.x) slots	3
PCI Express x16 (Gen 3.x) slots	5

Power

Specification	Value
Power supply	1400 W
80 PLUS certification	80 PLUS Platinum

Design

Specification	Value
Chassis type	Desktop
Volume	55 L
Placement supported	Vertical
Number of 5.25" bays	3
Cable lock slot	Yes
Cable lock slot type	Kensington
Product colour	Black
Viewing window	No

Software

Specification	Value
Operating system installed	Windows 10 Pro
Operating system architecture	64-bit

Display

Specification	Value
Display included	No

Processor special features

Specification	Value
Embedded options available	Yes
Enhanced Intel SpeedStep Technology	Yes
Execute Disable Bit	Yes
Intel 64	Yes
Intel TSX-NI	Yes
Intel TSX-NI version	1.00
Intel Trusted Execution Technology	Yes
Intel VT-x with Extended Page Tables (EPT)	Yes
Intel Virtualization Technology (VT-x)	Yes
Intel Virtualization Technology for Directed I/O (VT-d)	Yes
Intel® AES New Instructions (Intel® AES-NI)	Yes
Processor ARK ID	120473
Processor code	SR3GF
Processor package size	76.0 x 56.5 mm
Scalability	4S
Supported instruction sets	AVX, AVX 2.0, AVX-512, SSE4.2
Intel® Turbo Boost Technology	2.0
Intel® Hyper Threading Technology (Intel® HT Technology)	Yes
Conflict-Free processor	Yes

Audio

Specification	Value
Audio chip	Realtek ALC662

Operational conditions

Specification	Value
Operating temperature (T-T)	10 - 35 °C
Storage temperature (T-T)	-10 - 60 °C
Operating relative humidity (H-H)	10 - 80%
Storage relative humidity (H-H)	10 - 90%
Operating altitude	0 - 3048 m

Weight & dimensions

Specification	Value
Width	200 mm
Depth	620 mm
Height	446 mm

Packaging content

Specification	Value
Mouse included	Yes
Keyboard included	Yes

Certificates

Specification	Value
Compliance certificates	RoHS

Sustainability

Specification	Value
Sustainability certificates	EPEAT Gold, ENERGY STAR
