Lenovo ThinkStation P910 Intel® Xeon® E5 v4 E5-2630V4

32 GB DDR4-SDRAM 512 GB SSD Windows 10 Pro Tower Workstation Black

Model P910Part no. 30B9002YUSEAN 4058154084304

119 specifications

ProcessorIntel® Xeon® E5 v4
Memory32 GB
Storage512 GB
GraphicsNot available
TypeWorkstation
OSWindows 10 Pro

See all specifications

Overview

Processor: Intel® Xeon® E5 v4
Memory: 32 GB
Storage: 512 GB
Graphics: Not available
Type: Workstation
OS: Windows 10 Pro

Brand: Lenovo
Category: PCs/Workstations
Model: P910
Part numbers: 30B9002YUS, 30B90034GE, 30B9S0GE00, 30B90006GE, 30B90006MZ, 30B9000EUS +26 more
EAN / UPC: 4058154084304, 190404923217, 190404920117, 190404920148 +26 more
Also known as: Lenovo ThinkStation P910 Intel® Xeon® E5 v4 E5-2630V4 32 GB DDR4-SDRAM 512 GB SSD Windows 10 Pro Tower Workstation Black

Specifications

119 specifications in 19 groups

Processor

Specification	Value
Processor manufacturer	Intel
Processor family	Intel® Xeon® E5 v4
Processor model	E5-2630V4
Processor cores	10
Processor threads	20
Processor boost frequency	3.1 GHz
Processor frequency	2.2 GHz
Processor cache	25 MB
Processor cache type	Smart Cache
Bus type	QPI
System bus rate	8 GT/s
Processor lithography	14 nm
Processor operating modes	64-bit
Processor series	Intel Xeon E5-2600 v4
Processor codename	Broadwell
Thermal Design Power (TDP)	85 W
Tcase	74 °C
Maximum number of PCI Express lanes	40
PCI Express slots version	3.0
Number of QPI links	2
Number of processors installed	2
Processor socket	LGA 2011-v3
Stepping	R0
Maximum internal memory supported by processor	1.53 TB
Memory types supported by processor	DDR4-SDRAM
Memory clock speeds supported by processor	1600,1866,2133 MHz
Memory bandwidth supported by processor (max)	68.3 GB/s
ECC supported by processor	Yes

Memory

Specification	Value
Internal memory	32 GB
Internal memory type	DDR4-SDRAM
Memory layout (slots x size)	4 x 8 GB
Memory slots	16x DIMM
ECC	Yes
Memory channels	Quad-channel

Storage

Specification	Value
Total storage capacity	512 GB
Optical drive type	DVD±RW
Storage media	SSD
Number of SSDs installed	1
SSD capacity	512 GB
SSD interface	SATA III
Card reader integrated	Yes

Graphics

Specification	Value
On-board graphics card	No
Discrete graphics card model	Not available
On-board graphics card model	Not available

Performance

Specification	Value
Product type	Workstation
Motherboard chipset	Intel® C612

Optical drive

Specification	Value
Optical drives quantity	1

Network

Specification	Value
Ethernet LAN	Yes
Ethernet LAN data rates	10,100,1000 Mbit/s
Cabling technology	10/100/1000Base-T(X)
Wi-Fi	No

Ports & interfaces

Specification	Value
USB 2.0 ports quantity	4
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	8
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity	0
HDMI ports quantity	0
Ethernet LAN (RJ-45) ports	2
Combo headphone/mic port	Yes
Headphone outputs	0
Line-out	Yes
Line-in	Yes
Microphone in	Yes
VGA (D-Sub) ports quantity	0
DVI port	No
PS/2 ports quantity	2
Serial ports quantity	2

Expansion slots

Specification	Value
Number of 3.5" bays	4
PCI Express x1 (Gen 2.x) slots	2
PCI Express x4 (Gen 2.x) slots	2
PCI Express x16 (Gen 3.x) slots	4

Power

Specification	Value
Power supply	1300 W

Design

Specification	Value
Chassis type	Tower
Number of 5.25" bays	3
Product colour	Black

Software

Specification	Value
Operating system installed	Windows 10 Pro
Operating system architecture	64-bit

Display

Specification	Value
Display included	No

Processor special features

Specification	Value
CPU configuration (max)	2
Embedded options available	No
Enhanced Intel SpeedStep Technology	Yes
Execute Disable Bit	Yes
Idle States	Yes
Intel 64	Yes
Intel Demand Based Switching	Yes
Intel Enhanced Halt State	Yes
Intel Flex Memory Access	No
Intel Identity Protection Technology version	0.00
Intel Secure Key Technology version	1.00
Intel TSX-NI	Yes
Intel TSX-NI version	1.00
Intel Trusted Execution Technology	Yes
Intel VT-x with Extended Page Tables (EPT)	Yes
Intel Virtualization Technology (VT-x)	Yes
Intel Virtualization Technology for Directed I/O (VT-d)	Yes
Intel® AES New Instructions (Intel® AES-NI)	Yes
Intel® OS Guard	Yes
Intel® Secure Key	Yes
Physical Address Extension (PAE)	46 bit
Physical Address Extension (PAE)	Yes
Processor ARK ID	92981
Processor code	SR2R7
Processor package size	45 x 52.5 mm
Scalability	2S
Supported instruction sets	AVX 2.0
Thermal Monitoring Technologies	Yes
Intel® Turbo Boost Technology	2.0
Intel® Hyper Threading Technology (Intel® HT Technology)	Yes
Intel® Identity Protection Technology (Intel® IPT)	No
Conflict-Free processor	Yes

Audio

Specification	Value
Audio chip	Realtek ALC662
Audio system	HD

Weight & dimensions

Specification	Value
Width	200 mm
Depth	620 mm
Height	446 mm

Packaging content

Specification	Value
Mouse included	Yes
Keyboard included	Yes
Cables included	AC

Certificates

Specification	Value
Compliance certificates	RoHS
Certification	GREENGUARD

Sustainability

Specification	Value
Sustainability certificates	EPEAT Gold, ENERGY STAR
