ThinkCentre M77 AMD Athlon II X2 B24
4 GB DDR3-SDRAM 320 GB Windows 7 Professional SFF PC Black
Model M77Part no. SQMA1MDEAN 886605995824
76 specifications
- ProcessorAMD Athlon II X2
- Memory4 GB
- Storage320 GB
- TypePC
- OSWindows 7 Professional
- Weight7.5 kg
Overview
- Processor
- AMD Athlon II X2
- Memory
- 4 GB
- Storage
- 320 GB
- Type
- PC
- OS
- Windows 7 Professional
- Weight
- 7.5 kg
- Brand
- Lenovo
- Category
- PCs/Workstations
- Model
- M77
- Part numbers
- SQMA1MD, SQBA1MD, 2227A2U, 1995A2U, 1995A3U, 2227A3U +27 more
- EAN / UPC
- 886605995824, 886605995923, 886843353851, 886843209554 +6 more
- Also known as
- Lenovo ThinkCentre M77 AMD Athlon II X2 B24 4 GB DDR3-SDRAM 320 GB Windows 7 Professional SFF PC Black
Specifications
76 specifications in 19 groups
Processor
| Specification | Value |
|---|---|
| Processor manufacturer | AMD |
| Processor family | AMD Athlon II X2 |
| Processor model | B24 |
| Processor cores | 2 |
| Processor threads | 2 |
| Processor frequency | 3 GHz |
| Processor cache | 2 MB |
| Processor cache type | L2 |
| Processor front side bus | 1066 MHz |
| Number of processors installed | 1 |
| Processor socket | Socket AM3+ |
Memory
| Specification | Value |
|---|---|
| Internal memory | 4 GB |
| Maximum internal memory | 16 GB |
| Internal memory type | DDR3-SDRAM |
| Memory slots | 4x DIMM |
| Memory clock speed | 1333 MHz |
Storage
| Specification | Value |
|---|---|
| Total storage capacity | 320 GB |
| Optical drive type | DVD-ROM |
| Number of HDDs installed | 1 |
| HDD capacity | 320 GB |
| HDD interface | SATA |
| HDD speed | 7200 RPM |
| Card reader integrated | Yes |
Graphics
| Specification | Value |
|---|---|
| On-board graphics card | Yes |
| On-board graphics card family | AMD Radeon HD 4000 |
| On-board graphics card model | AMD Radeon HD 4250 |
| Graphics card family | ATI |
Performance
| Specification | Value |
|---|---|
| Product type | PC |
| Motherboard chipset | AMD 980G |
| Audio output channels | 5.1 channels |
Network
| Specification | Value |
|---|---|
| Ethernet LAN | Yes |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| Cabling technology | 10/100/1000Base-T(X) |
| Wi-Fi | No |
| Wake-on-LAN ready | Yes |
| Networking features | Gigabit Ethernet |
Ports & interfaces
| Specification | Value |
|---|---|
| USB 2.0 ports quantity | 8 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 0 |
| DisplayPorts quantity | 1 |
| HDMI ports quantity | 0 |
| Ethernet LAN (RJ-45) ports | 1 |
| Headphone outputs | 1 |
| Line-out | Yes |
| Line-in | Yes |
| Microphone in | Yes |
| VGA (D-Sub) ports quantity | 1 |
| DVI port | No |
| PS/2 ports quantity | 0 |
| Firewire (IEEE 1394) ports | 0 |
| DC-in jack | Yes |
| Serial ports quantity | 1 |
| Parallel ports quantity | 0 |
Expansion slots
| Specification | Value |
|---|---|
| Number of 3.5" bays | 1 |
| PCI Express x1 slots | 2 |
| PCI Express x16 slots | 1 |
Power
| Specification | Value |
|---|---|
| Power supply | 240 W |
Design
| Specification | Value |
|---|---|
| Chassis type | SFF |
| Number of 5.25" bays | 1 |
| Cable lock slot | Yes |
| Cable lock slot type | Kensington |
| Product colour | Black |
Software
| Specification | Value |
|---|---|
| Operating system installed | Windows 7 Professional |
| Operating system architecture | 32-bit |
Display
| Specification | Value |
|---|---|
| Display included | No |
Audio
| Specification | Value |
|---|---|
| Audio system | HD |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 337 mm |
| Depth | 369 mm |
| Height | 99.7 mm |
| Weight | 7.5 kg |
Packaging content
| Specification | Value |
|---|---|
| Mouse included | Yes |
| Keyboard included | Yes |
Certificates
| Specification | Value |
|---|---|
| Compliance certificates | RoHS |
| Compliance industry standards | IEEE 802.3, IEEE 802.3u, IEEE 802.3ab |
Sustainability
| Specification | Value |
|---|---|
| Sustainability certificates | EPEAT Gold, ENERGY STAR |
Keyboard
| Specification | Value |
|---|---|
| Keyboard number of keys | 104 |
Other features
| Specification | Value |
|---|---|
| Intel segment tagging | Enterprise, Professional |
