Lenovo Gaming 5
Lenovo

Gaming 5

Model Gaming 5Part no. 90RE00HLMHEAN 195477811591

146 specifications
  • ProcessorIntel® Core™ i5
  • Memory8 GB
  • Storage1.25 TB
  • GraphicsNVIDIA GeForce GTX 1660 SUPER
  • SpeedWi-Fi 6 (802.11ax)
  • TypePC
See all specifications

Overview

Processor
Intel® Core™ i5
Memory
8 GB
Storage
1.25 TB
Graphics
NVIDIA GeForce GTX 1660 SUPER
Speed
Wi-Fi 6 (802.11ax)
Type
PC
Brand
Lenovo
Model
Gaming 5
Part numbers
90RE00HLMH, 90N9003NIX, 90Q1001GGE, 90Q1001HGE, 90Q1002VGE, 90RE00HMMH +34 more
EAN / UPC
195477811591, 195042507324, 195235584521, 195235584538 +56 more
Also known as
Lenovo IdeaCentre Gaming 5 Intel® Core™ i5 i5-10400 8 GB DDR4-SDRAM 1.25 TB HDD+SSD NVIDIA GeForce GTX 1660 SUPER Windows 10 Home Tower PC Black, Blue

Specifications

146 specifications in 18 groups

Processor

Processor manufacturerIntel
Processor familyIntel® Core™ i5
Processor generation10th gen Intel® Core™ i5
Processor modeli5-10400
Processor cores6
Processor threads12
Processor boost frequency4.3 GHz
Processor frequency2.9 GHz
Processor cache12 MB
Processor cache typeSmart Cache
System bus rate8 GT/s
Processor lithography14 nm
Processor operating modes64-bit
Processor codenameComet Lake
Thermal Design Power (TDP)65 W
Tjunction100 °C
Maximum number of PCI Express lanes16
PCI Express configurations1x16, 2x8, 1x8+2x4
PCI Express slots version3.0
Number of processors installed1
Processor socketLGA 1200 (Socket H5)
Maximum internal memory supported by processor128 GB
Memory types supported by processorDDR4-SDRAM
Memory clock speeds supported by processor2666 MHz
Memory bandwidth supported by processor (max)41.6 GB/s

Memory

Internal memory8 GB
Maximum internal memory32 GB
Internal memory typeDDR4-SDRAM
Memory layout (slots x size)1 x 8 GB
Memory slots2x DIMM
Memory clock speed2933 MHz
Memory channelsDual-channel

Storage

Total storage capacity1.25 TB
Optical drive typeNo
Storage mediaHDD+SSD
Number of storage drives installed2
Total HDDs capacity1 TB
Number of HDDs installed1
HDD capacity1 TB
HDD interfaceSATA III
HDD speed7200 RPM
HDD size3.5"
Total SSDs capacity256 GB
Number of SSDs installed1
SSD capacity256 GB
NVMeYes
SSD interfaceNVMe
SSD form factorM.2
Card reader integratedYes
Compatible memory cardsSD, SDHC, SDXC

Graphics

Discrete graphics cardYes
On-board graphics cardYes
Discrete graphics card modelNVIDIA GeForce GTX 1660 SUPER
Discrete graphics card memory6 GB
Discrete graphics memory typeGDDR6
Number of discrete graphics cards1
On-board GPU manufacturerIntel
On-board graphics card familyIntel® UHD Graphics
On-board graphics card modelIntel® UHD Graphics 630
Maximum on-board graphics card memory64 GB
Number of displays supported (on-board graphics)3
On-board graphics card base frequency350 MHz
On-board graphics card dynamic frequency (max)1100 MHz
On-board graphics card DirectX version12.0
On-board graphics card ID0x9BC8/0x9BC5
On-board graphics card OpenGL version4.5

Performance

Product typePC
Market positioningGaming
Motherboard chipsetIntel B460
Password protectionYes
Password protection typeHDD, Supervisor

Network

Ethernet LANYes
Ethernet LAN data rates10,100,1000 Mbit/s
Cabling technology10/100/1000Base-T(X)
Wi-FiYes
Top Wi-Fi standardWi-Fi 6 (802.11ax)
Wi-Fi standards802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax)
Antenna type2x2
BluetoothYes
Bluetooth version5.0

Ports & interfaces

USB 2.0 ports quantity4
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity2
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity1
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity0
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity0
Thunderbolt 3 ports quantity0
HDMI ports quantity1
HDMI version1.4b
Ethernet LAN (RJ-45) ports1
Combo headphone/mic portYes
Headphone outputs1
Line-outYes
Microphone inYes
VGA (D-Sub) ports quantity1
DVI portNo
DC-in jackYes

Power

Power supply310 W

Design

Chassis typeTower
Colour nameRaven Black
Volume13.6 L
Placement supportedVertical
Product colourBlack, Blue

Software

Operating system installedWindows 10 Home
Operating system architecture64-bit
Operating system languageEnglish, Italian

Display

Display includedNo

Processor special features

CPU configuration (max)1
Embedded options availableNo
Enhanced Intel SpeedStep TechnologyYes
Execute Disable BitYes
Idle StatesYes
Intel 64Yes
Intel Clear Video TechnologyYes
Intel Software Guard Extensions (Intel SGX)Yes
Intel Stable Image Platform Program (SIPP)No
Intel Trusted Execution TechnologyNo
Intel VT-x with Extended Page Tables (EPT)Yes
Intel Virtualization Technology (VT-x)Yes
Intel Virtualization Technology for Directed I/O (VT-d)Yes
Intel® AES New Instructions (Intel® AES-NI)Yes
Intel® Clear Video HD Technology (Intel® CVT HD)Yes
Intel® InTru™ 3D TechnologyYes
Intel® OS GuardYes
Intel® Secure KeyYes
Processor ARK ID199271
Processor package size37.5 x 37.5 mm
Scalability1S
Supported instruction setsSSE4.1, SSE4.2, AVX 2.0
Thermal Monitoring TechnologiesYes
Thermal solution specificationPCG 2015C
Intel® Turbo Boost Technology2.0
Intel® Hyper Threading Technology (Intel® HT Technology)Yes
Intel® Quick Sync Video TechnologyYes
Intel® Identity Protection Technology (Intel® IPT)Yes

Audio

Audio chipRealtek ALC222-CG
Audio systemHigh Definition Audio

Weight & dimensions

Width145 mm
Depth292.2 mm
Height365 mm
Weight5.8 kg

Packaging content

Mouse includedYes
Keyboard includedYes

Certificates

Compliance certificatesRoHS
CertificationErP Lot 3

Sustainability

Sustainability certificatesENERGY STAR

Keyboard

Keyboard layoutQWERTY
