3Y Intel® Core™ i7 DDR4-SDRAM

256 GB SSD Mini PC Black

Model DT/M90n/i7-8665U/16gb/256SSD/SHD/DOS/3YPart no. 11AES0TV00

117 specifications

Overview

Brand: Lenovo
Category: PCs/Workstations
Model: DT/M90n/i7-8665U/16gb/256SSD/SHD/DOS/3Y
Part number: 11AES0TV00
Also known as: Lenovo ThinkCentre DT/M90n/i7-8665U/16gb/256SSD/SHD/DOS/3Y Intel® Core™ i7 DDR4-SDRAM 256 GB SSD Mini PC Black

117 specifications in 15 groups

Specification	Value
Processor manufacturer	Intel
Processor family	Intel® Core™ i7
Processor generation	8th gen Intel® Core™ i7
Processor model	i7-8665U
Processor cores	4
Processor threads	8
Processor boost frequency	4.8 GHz
Processor frequency	1.9 GHz
Processor cache	8 MB
Processor cache type	Smart Cache
System bus rate	4 GT/s
Processor lithography	14 nm
Processor operating modes	64-bit
Processor codename	Whiskey Lake
Thermal Design Power (TDP)	15 W
Configurable TDP-up	25 W
Configurable TDP-up frequency	2.1 GHz
Configurable TDP-down	10 W
Configurable TDP-down frequency	0.8 GHz
Tjunction	100 °C
Maximum number of PCI Express lanes	16
PCI Express configurations	1x4, 2x2, 1x2+2x1, 4x1
PCI Express slots version	3.0
Number of processors installed	1
Processor socket	BGA 1528
Maximum internal memory supported by processor	32 GB
Memory types supported by processor	DDR4-SDRAM, LPDDR3-SDRAM
Memory clock speeds supported by processor	2400,2133 MHz
Memory bandwidth supported by processor (max)	37.5 GB/s

Specification	Value
Total storage capacity	256 GB
Optical drive type	No
Storage media	SSD
Number of storage drives installed	1
Total SSDs capacity	256 GB
Number of SSDs installed	1
SSD capacity	256 GB
Card reader integrated	No

Specification	Value
Discrete graphics card	No
On-board graphics card	Yes
Discrete graphics card model	Not available
On-board GPU manufacturer	Intel
On-board graphics card model	Intel® UHD Graphics 620
Maximum on-board graphics card memory	32 GB
Number of displays supported (on-board graphics)	3
On-board graphics card base frequency	300 MHz
On-board graphics card dynamic frequency (max)	1150 MHz
On-board graphics card DirectX version	12.0
On-board graphics card ID	0x3EA0
On-board graphics card OpenGL version	4.5

Specification	Value
USB 2.0 ports quantity	0
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	0
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity	0
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity	4
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity	2
Thunderbolt 3 ports quantity	0
DisplayPorts quantity	1
HDMI ports quantity	0
Ethernet LAN (RJ-45) ports	1
Combo headphone/mic port	Yes
Headphone outputs	1
Microphone in	No
VGA (D-Sub) ports quantity	0
DVI port	No

Specification	Value
Power supply	65 W

Specification	Value
Display included	No

Specification	Value
CPU configuration (max)	1
Embedded options available	No
Enhanced Intel SpeedStep Technology	Yes
Execute Disable Bit	Yes
Idle States	Yes
Intel 64	Yes
Intel Clear Video Technology	Yes
Intel Flex Memory Access	Yes
Intel Software Guard Extensions (Intel SGX)	Yes
Intel Stable Image Platform Program (SIPP)	Yes
Intel TSX-NI	Yes
Intel Trusted Execution Technology	Yes
Intel VT-x with Extended Page Tables (EPT)	Yes
Intel Virtualization Technology (VT-x)	Yes
Intel Virtualization Technology for Directed I/O (VT-d)	Yes
Intel® AES New Instructions (Intel® AES-NI)	Yes
Intel® Clear Video HD Technology (Intel® CVT HD)	Yes
Intel® OS Guard	Yes
Intel® Secure Key	Yes
Processor ARK ID	193563
Processor package size	46x24 mm
Supported instruction sets	SSE4.1, SSE4.2, AVX 2.0
Thermal Monitoring Technologies	Yes
Intel® Smart Response Technology	Yes
Intel® Turbo Boost Technology	2.0
Intel® Hyper Threading Technology (Intel® HT Technology)	Yes
Intel® Quick Sync Video Technology	Yes
Intel® My WiFi Technology (Intel® MWT)	Yes
Intel® Identity Protection Technology (Intel® IPT)	Yes

Specification	Value
Mouse included	Yes
Keyboard included	Yes

Specification	Value
Compliance certificates	RoHS
Certification	ErP Lot 3 TCO 8.0 WEEE REACH MIL-STD-810H

Specification	Value
Sustainability certificates	EPEAT Silver
