Lenovo C20 + NVIDIA Quadro 2000

Model C20 + NVIDIA Quadro 2000Part no. SSD1JIX+57Y4479

109 specifications

Overview

Brand: Lenovo
Category: PCs/Workstations
Model: C20 + NVIDIA Quadro 2000
Part number: SSD1JIX+57Y4479
Also known as: Lenovo ThinkStation C20 + NVIDIA Quadro 2000 Intel® Xeon® 5000 Sequence E5649 6 GB DDR3-SDRAM Windows 7 Professional SFF Workstation Black

109 specifications in 15 groups

Specification	Value
Processor manufacturer	Intel
Processor family	Intel® Xeon® 5000 Sequence
Processor model	E5649
Processor cores	6
Processor threads	12
Processor boost frequency	2.93 GHz
Processor frequency	2.53 GHz
Processor cache	12 MB
Processor cache type	Smart Cache
Processor front side bus	1333 MHz
Bus type	QPI
FSB Parity	No
System bus rate	5.86 GT/s
Processor lithography	32 nm
Processor operating modes	64-bit
Processor series	Intel Xeon 5600 Series
Processor codename	Westmere EP
Thermal Design Power (TDP)	80 W
Tcase	76.2 °C
Number of QPI links	2
Number of processors installed	1
Processor socket	Socket B (LGA 1366)
CPU multiplier (bus/core ratio)	19
Stepping	B1
Maximum internal memory supported by processor	288 GB
Memory types supported by processor	DDR3 800/1066/1333
Memory bandwidth supported by processor (max)	32 GB/s
ECC supported by processor	Yes

Specification	Value
Maximum graphics card memory	1.024 GB
Graphics card	Quadro 2000
Graphics card family	NVIDIA

Specification	Value
Product type	Workstation
Motherboard chipset	Intel® 5520

Specification	Value
Networking features	Gigabit Ethernet (10/100/1000)

Specification	Value
USB 2.0 ports quantity	10
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	0
DisplayPorts quantity	2
Ethernet LAN (RJ-45) ports	1
Headphone outputs	1
Microphone in	Yes
VGA (D-Sub) ports quantity	1
PS/2 ports quantity	0
eSATA ports quantity	1
Serial ports quantity	0
Parallel ports quantity	0
DVI-I ports quantity	1

Specification	Value
Power supply	800 W

Specification	Value
Operating system installed	Windows 7 Professional
Operating system architecture	64-bit

Specification	Value
Display included	No

Specification	Value
Embedded options available	No
Enhanced Intel SpeedStep Technology	Yes
Execute Disable Bit	Yes
Idle States	Yes
Intel 64	Yes
Intel Clear Video Technology	No
Intel Demand Based Switching	Yes
Intel Dual Display Capable Technology	No
Intel Enhanced Halt State	Yes
Intel FDI Technology	No
Intel Fast Memory Access	No
Intel Flex Memory Access	No
Intel Rapid Storage Technology	No
Intel Trusted Execution Technology	Yes
Intel VT-x with Extended Page Tables (EPT)	Yes
Intel Virtualization Technology (VT-x)	Yes
Intel Virtualization Technology for Directed I/O (VT-d)	Yes
Intel® AES New Instructions (Intel® AES-NI)	Yes
Intel® Clear Video HD Technology (Intel® CVT HD)	No
Intel® Clear Video Technology for Mobile Internet Devices (Intel CVT for MID)	No
Intel® InTru™ 3D Technology	No
Intel® Insider™	No
Intel® Wireless Display (Intel® WiDi)	No
Physical Address Extension (PAE)	40 bit
Processor ARK ID	52581
Processor code	SLBZ8
Processor package size	42.5 X 45 mm
Supported instruction sets	SSE4.2
Thermal Monitoring Technologies	No
Intel® Turbo Boost Technology	1.0
Intel® Hyper Threading Technology (Intel® HT Technology)	Yes
Intel® Quick Sync Video Technology	No
Intel® My WiFi Technology (Intel® MWT)	No
Intel® Anti-Theft Technology (Intel® AT)	No
Conflict-Free processor	No

Specification	Value
Audio system	HD

Specification	Value
Compliance industry standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab
