ISY WS Silent X299

Model WS Silent X299Part no. ISY-W-X299SLI+280TI

109 specifications

Overview

Brand: ISY
Category: PCs/Workstations
Model: WS Silent X299
Part number: ISY-W-X299SLI+280TI
Also known as: ISY WS Silent X299 Intel® Core™ i9 X-series i9-7900X 16 GB DDR4-SDRAM 500 GB SSD NVIDIA® GeForce® GTX 1080 Ti Midi Tower PC Black

109 specifications in 15 groups

Specification	Value
Processor manufacturer	Intel
Processor family	Intel® Core™ i9 X-series
Processor generation	7th gen Intel® Core™ i9
Processor model	i9-7900X
Processor cores	10
Processor threads	20
Processor boost frequency	4.3 GHz
Processor frequency	3.3 GHz
Processor cache	13.75 MB
Processor cache type	L3
Bus type	DMI3
System bus rate	8 GT/s
Processor lithography	14 nm
Processor operating modes	64-bit
Processor codename	Skylake
Thermal Design Power (TDP)	140 W
Tjunction	95 °C
Maximum number of PCI Express lanes	44
PCI Express slots version	3.0
Number of QPI links	0
Number of processors installed	1
Processor socket	LGA 2066 (Socket R4)
Stepping	U0
Maximum internal memory supported by processor	128 GB
Memory types supported by processor	DDR4-SDRAM
Memory clock speeds supported by processor	2666 MHz
ECC supported by processor	No

Specification	Value
Total storage capacity	500 GB
Optical drive type	No
Storage media	SSD
Number of storage drives installed	1
Number of SSDs installed	1
SSD capacity	500 GB
SSD interface	PCI Express

Specification	Value
Discrete graphics card	Yes
On-board graphics card	No
Discrete graphics card model	NVIDIA® GeForce® GTX 1080 Ti
Discrete graphics card memory	11 GB
Discrete graphics memory type	GDDR5X
Number of discrete graphics cards	2
On-board graphics card model	Not available
CUDA	Yes
CUDA cores	3584
NVIDIA G-SYNC	Yes
NVIDIA GameWorks VR	Yes
Graphics card DisplayPorts quantity	3
Graphics card HDMI ports quantity	1

Specification	Value
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity	0
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity	1
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity	1
Thunderbolt 3 ports quantity	0
HDMI ports quantity	0
Ethernet LAN (RJ-45) ports	2
Headphone outputs	1
Line-out	Yes
Line-in	Yes
Microphone in	Yes
VGA (D-Sub) ports quantity	0
DVI port	No
PS/2 ports quantity	1
S/PDIF out port	Yes
Number of SATA III connectors	8

Specification	Value
PCI Express x1 (Gen 3.x) slots	2
PCI Express x16 (Gen 3.x) slots	4

Specification	Value
Power supply	850 W
80 PLUS certification	80 PLUS Silver

Specification	Value
Display included	No

Specification	Value
CPU configuration (max)	1
Embedded options available	No
Enhanced Intel SpeedStep Technology	Yes
Execute Disable Bit	Yes
Intel 64	Yes
Intel Virtualization Technology (VT-x)	Yes
Intel Virtualization Technology for Directed I/O (VT-d)	Yes
Intel® AES New Instructions (Intel® AES-NI)	Yes
Processor ARK ID	123613
Processor code	SR3L2
Scalability	1S
Supported instruction sets	AVX 2.0, AVX-512, SSE4.1, SSE4.2
Thermal solution specification	PCG 2017X
Intel® Turbo Boost Technology	2.0
Intel® Hyper Threading Technology (Intel® HT Technology)	Yes
Conflict-Free processor	Yes

Specification	Value
Audio chip	Realtek ALC1220
Audio system	High Definition Audio

Specification	Value
Width	243 mm
Depth	305 mm

Specification	Value
Mouse included	Yes
Cables included	AC
