WS Silent X10DAI-O
Model WS Silent X10DAI-OPart no. ISY-W-X10DAIEAN 8055681887275
117 specifications
- ProcessorIntel® Xeon® E5 v4
- Memory64 GB
- Storage400 GB
- GraphicsNVIDIA® Quadro® M5000
- TypePC
- ColourBlack
Overview
- Processor
- Intel® Xeon® E5 v4
- Memory
- 64 GB
- Storage
- 400 GB
- Graphics
- NVIDIA® Quadro® M5000
- Type
- PC
- Colour
- Black
- Brand
- ISY
- Category
- PCs/Workstations
- Model
- WS Silent X10DAI-O
- Part numbers
- ISY-W-X10DAI, ISY-W-X10DAI-2640-4, ISY-W-X10DAI-2640-5
- EAN / UPC
- 8055681887275, 8055681887282, 8055681887268
- Also known as
- ISY WS Silent X10DAI-O Intel® Xeon® E5 v4 E5-2640V4 64 GB DDR4-SDRAM 400 GB SSD NVIDIA® Quadro® M5000 Midi Tower PC Black
Specifications
117 specifications in 18 groups
Processor
| Specification | Value |
|---|---|
| Processor manufacturer | Intel |
| Processor family | Intel® Xeon® E5 v4 |
| Processor model | E5-2640V4 |
| Processor cores | 10 |
| Processor threads | 20 |
| Processor boost frequency | 3.4 GHz |
| Processor frequency | 2.4 GHz |
| Processor cache | 25 MB |
| Processor cache type | Smart Cache |
| Bus type | QPI |
| System bus rate | 8 GT/s |
| Processor lithography | 14 nm |
| Processor operating modes | 64-bit |
| Processor series | Intel Xeon E5-2600 v4 |
| Processor codename | Broadwell |
| Thermal Design Power (TDP) | 90 W |
| Tcase | 76 °C |
| Maximum number of PCI Express lanes | 40 |
| PCI Express configurations | 1x4, 1x8, 1x16 |
| PCI Express slots version | 3.0 |
| Number of QPI links | 2 |
| Number of processors installed | 2 |
| Processor socket | LGA 2011-v3 |
| Stepping | R0 |
| Maximum internal memory supported by processor | 1.53 TB |
| Memory types supported by processor | DDR4-SDRAM |
| Memory clock speeds supported by processor | 1600,1866,2133 MHz |
| Memory bandwidth supported by processor (max) | 68.3 GB/s |
| ECC supported by processor | Yes |
Memory
| Specification | Value |
|---|---|
| Internal memory | 64 GB |
| Maximum internal memory | 1 TB |
| Internal memory type | DDR4-SDRAM |
| Memory layout (slots x size) | 8 x 8 GB |
| Memory slots | 16x DIMM |
| Memory clock speed | 2400 MHz |
| ECC | Yes |
| Memory channels | Quad-channel |
Storage
| Specification | Value |
|---|---|
| Total storage capacity | 400 GB |
| Storage media | SSD |
| Number of SSDs installed | 1 |
| SSD capacity | 400 GB |
| NVMe | Yes |
| SSD interface | NVMe 3.0, PCI Express 3.0 |
| RAID support | Yes |
| RAID levels | 0, 1, 5, 10 |
Graphics
| Specification | Value |
|---|---|
| On-board graphics card | No |
| Discrete graphics card model | NVIDIA® Quadro® M5000 |
| Discrete graphics card memory | 8 GB |
| Discrete graphics memory type | GDDR5 |
| Number of discrete graphics cards | 1 |
| On-board graphics card model | Not available |
Performance
| Specification | Value |
|---|---|
| Product type | PC |
| Motherboard chipset | Intel® C612 |
| Motherboard form factor | Extended ATX |
| Compatible processor series | Intel® Xeon® |
| BIOS type | AMI |
| Audio output channels | 7.1 channels |
Network
| Specification | Value |
|---|---|
| Ethernet LAN | Yes |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| Cabling technology | 10/100/1000Base-T(X) |
| Wi-Fi | No |
| Wake-on-LAN ready | Yes |
Ports & interfaces
| Specification | Value |
|---|---|
| USB 2.0 ports quantity | 5 |
| Ethernet LAN (RJ-45) ports | 2 |
| Number of SATA III connectors | 10 |
Expansion slots
| Specification | Value |
|---|---|
| PCI Express x4 (Gen 2.x) slots | 1 |
| PCI Express x8 (Gen 3.x) slots | 3 |
| PCI Express x16 (Gen 3.x) slots | 3 |
Power
| Specification | Value |
|---|---|
| Power supply | 1000 W |
Design
| Specification | Value |
|---|---|
| Chassis type | Midi Tower |
| Placement supported | Vertical |
| Product colour | Black |
Display
| Specification | Value |
|---|---|
| Display included | No |
Processor special features
| Specification | Value |
|---|---|
| CPU configuration (max) | 2 |
| Embedded options available | Yes |
| Enhanced Intel SpeedStep Technology | Yes |
| Execute Disable Bit | Yes |
| Idle States | Yes |
| Intel 64 | Yes |
| Intel Demand Based Switching | Yes |
| Intel Flex Memory Access | No |
| Intel TSX-NI | Yes |
| Intel Trusted Execution Technology | Yes |
| Intel VT-x with Extended Page Tables (EPT) | Yes |
| Intel Virtualization Technology (VT-x) | Yes |
| Intel Virtualization Technology for Directed I/O (VT-d) | Yes |
| Intel® AES New Instructions (Intel® AES-NI) | Yes |
| Intel® OS Guard | Yes |
| Intel® Secure Key | Yes |
| Physical Address Extension (PAE) | 46 bit |
| Physical Address Extension (PAE) | Yes |
| Processor ARK ID | 92984 |
| Processor package size | 52.5 x 51 mm |
| Scalability | 2S |
| Supported instruction sets | AVX 2.0 |
| Thermal Monitoring Technologies | Yes |
| Intel® Turbo Boost Technology | 2.0 |
| Intel® Hyper Threading Technology (Intel® HT Technology) | Yes |
| Intel® Identity Protection Technology (Intel® IPT) | No |
| Conflict-Free processor | Yes |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 10 - 35 °C |
| Storage temperature (T-T) | -40 - 70 °C |
| Operating relative humidity (H-H) | 8 - 90% |
| Storage relative humidity (H-H) | 5 - 95% |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 305 mm |
| Depth | 330 mm |
Packaging data
| Specification | Value |
|---|---|
| Package width | 630 mm |
| Package depth | 350 mm |
| Package height | 750 mm |
| Package weight | 20 kg |
Packaging content
| Specification | Value |
|---|---|
| Mouse included | Yes |
| Keyboard included | Yes |
| Cables included | AC |
| AC adapter included | Yes |
| Manual | Yes |
Certificates
| Specification | Value |
|---|---|
| Certification | CE |
Keyboard
| Specification | Value |
|---|---|
| Keyboard language | Italian |
