WS Silent
Model WS SilentPart no. ISY-W-SM-X10DAI-2630-5EAN 8055681886834
120 specifications
- ProcessorIntel® Xeon® E5 v4
- Memory64 GB
- Storage400 GB
- GraphicsNVIDIA® Quadro® M2000
- TypeWorkstation
- OSWindows 10 Pro
Overview
- Processor
- Intel® Xeon® E5 v4
- Memory
- 64 GB
- Storage
- 400 GB
- Graphics
- NVIDIA® Quadro® M2000
- Type
- Workstation
- OS
- Windows 10 Pro
- Brand
- ISY
- Category
- PCs/Workstations
- Model
- WS Silent
- Part numbers
- ISY-W-SM-X10DAI-2630-5, ISY-W-S2600CWT-2699-2, ISY-W-S2600CWT-2697-2, ISY-W-S2600CWT-2690-2, ISY-W-S2600CWT-2687-5, ISY-W-S2600CWT-2687-2 +3 more
- EAN / UPC
- 8055681886834, 8055681886544, 8055681886537, 8055681886520 +5 more
- Also known as
- ISY WS Silent Intel® Xeon® E5 v4 E5-2699V4 64 GB DDR4-SDRAM 400 GB SSD NVIDIA® Quadro® M2000 Windows 10 Pro Tower Workstation Black
Specifications
120 specifications in 15 groups
Processor
| Specification | Value |
|---|---|
| Processor manufacturer | Intel |
| Processor family | Intel® Xeon® E5 v4 |
| Processor model | E5-2699V4 |
| Processor cores | 22 |
| Processor threads | 44 |
| Processor boost frequency | 3.6 GHz |
| Processor frequency | 2.2 GHz |
| Processor cache | 55 MB |
| Processor cache type | Smart Cache |
| Bus type | QPI |
| System bus rate | 9.6 GT/s |
| Processor lithography | 14 nm |
| Processor operating modes | 64-bit |
| Processor series | Intel Xeon E5-2600 v4 |
| Processor codename | Broadwell |
| Thermal Design Power (TDP) | 145 W |
| Tcase | 79 °C |
| Maximum number of PCI Express lanes | 40 |
| PCI Express configurations | 1x16, 1x4, 1x8 |
| PCI Express slots version | 3.0 |
| Number of QPI links | 2 |
| Number of processors installed | 2 |
| Processor socket | LGA 2011-v3 |
| Stepping | B0 |
| Maximum internal memory supported by processor | 1.53 TB |
| Memory types supported by processor | DDR4-SDRAM |
| Memory clock speeds supported by processor | 1600,1866,2133,2400 MHz |
| Memory bandwidth supported by processor (max) | 76.8 GB/s |
| ECC supported by processor | Yes |
Memory
| Specification | Value |
|---|---|
| Internal memory | 64 GB |
| Maximum internal memory | 64 GB |
| Internal memory type | DDR4-SDRAM |
| Memory slots | 16x DIMM |
| Memory clock speed | 2133 MHz |
| Memory channels | Quad-channel |
Storage
| Specification | Value |
|---|---|
| Total storage capacity | 400 GB |
| Optical drive type | No |
| Storage media | SSD |
| Number of SSDs installed | 1 |
| SSD capacity | 400 GB |
| Card reader integrated | No |
| RAID levels | 0, 1, 10 |
Graphics
| Specification | Value |
|---|---|
| On-board graphics card | No |
| Discrete graphics card model | NVIDIA® Quadro® M2000 |
| Discrete graphics card memory | 4 GB |
| Discrete graphics memory type | GDDR5 |
| On-board graphics card model | Not available |
| Graphics card | Quadro M2000 |
| Graphics card family | NVIDIA |
| Graphics card memory type | GDDR5 |
Performance
| Specification | Value |
|---|---|
| Product type | Workstation |
| Motherboard chipset | Intel® C612 |
| Motherboard form factor | SSI EEB |
| Compatible processor series | Intel® Xeon® |
| Trusted Platform Module (TPM) | Yes |
Network
| Specification | Value |
|---|---|
| Ethernet LAN | Yes |
| Wi-Fi | No |
Ports & interfaces
| Specification | Value |
|---|---|
| USB 2.0 ports quantity | 2 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 2 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity | 0 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity | 0 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity | 0 |
| Thunderbolt 3 ports quantity | 0 |
| HDMI ports quantity | 0 |
| Ethernet LAN (RJ-45) ports | 2 |
| Headphone outputs | 0 |
| Microphone in | No |
| VGA (D-Sub) ports quantity | 1 |
| DVI port | No |
| DC-in jack | Yes |
| Serial ports quantity | 1 |
Expansion slots
| Specification | Value |
|---|---|
| PCI Express x4 slots | 1 |
| PCI Express x8 slots | 1 |
| PCI Express x16 slots | 4 |
Power
| Specification | Value |
|---|---|
| Power supply type | Internal power supply unit |
| Power supply | 1000 W |
Design
| Specification | Value |
|---|---|
| Chassis type | Tower |
| Placement supported | Vertical |
| Product colour | Black |
Software
| Specification | Value |
|---|---|
| Operating system installed | Windows 10 Pro |
Display
| Specification | Value |
|---|---|
| Display included | No |
Processor special features
| Specification | Value |
|---|---|
| CPU configuration (max) | 2 |
| Embedded options available | No |
| Enhanced Intel SpeedStep Technology | Yes |
| Execute Disable Bit | Yes |
| Idle States | Yes |
| Intel 64 | Yes |
| Intel Demand Based Switching | Yes |
| Intel Enhanced Halt State | Yes |
| Intel Flex Memory Access | No |
| Intel Identity Protection Technology version | 0.00 |
| Intel Secure Key Technology version | 1.00 |
| Intel TSX-NI | Yes |
| Intel TSX-NI version | 1.00 |
| Intel Trusted Execution Technology | Yes |
| Intel VT-x with Extended Page Tables (EPT) | Yes |
| Intel Virtualization Technology (VT-x) | Yes |
| Intel Virtualization Technology for Directed I/O (VT-d) | Yes |
| Intel® AES New Instructions (Intel® AES-NI) | Yes |
| Intel® OS Guard | Yes |
| Intel® Secure Key | Yes |
| Physical Address Extension (PAE) | 46 bit |
| Processor ARK ID | 91317 |
| Processor code | SR30Y |
| Processor package size | 45 x 52.5 mm |
| Scalability | 2S |
| Supported instruction sets | AVX 2.0 |
| Thermal Monitoring Technologies | Yes |
| Intel® Turbo Boost Technology | 2.0 |
| Intel® Hyper Threading Technology (Intel® HT Technology) | Yes |
| Intel® Identity Protection Technology (Intel® IPT) | No |
| Conflict-Free processor | Yes |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 230 mm |
| Depth | 577 mm |
| Height | 525 mm |
| Weight | 12.7 kg |
Packaging data
| Specification | Value |
|---|---|
| Package width | 285 mm |
| Package depth | 690 mm |
| Package height | 543 mm |
| Package weight | 20 kg |
