Z4 Rack G5
Model Z4 Rack G5Part no. 5E8U8EA#ABHEAN 198415718570
73 specifications
- ProcessorIntel Xeon W
- Memory64 GB
- Storage2 TB
- GraphicsNVIDIA RTX 2000 Ada
- TypeWorkstation
- OSWindows 11 Pro
Overview
- Processor
- Intel Xeon W
- Memory
- 64 GB
- Storage
- 2 TB
- Graphics
- NVIDIA RTX 2000 Ada
- Type
- Workstation
- OS
- Windows 11 Pro
- Brand
- HP
- Category
- PCs/Workstations
- Model
- Z4 Rack G5
- Part numbers
- 5E8U8EA#ABH, D4YD9UC#ABA, D4XH8UC#ABA, 5E8R5EA, 5E8R3EA, 82F49ET +4 more
- EAN / UPC
- 198415718570, 199896820585, 199896815451, 197961076134 +26 more
- Also known as
- HP Z4 Rack G5 Intel Xeon W W3-2525 64 GB DDR5-SDRAM 2 TB SSD NVIDIA RTX 2000 Ada Windows 11 Pro Rack-mounted chassis Workstation Black
Specifications
73 specifications in 14 groups
Processor
| Specification | Value |
|---|---|
| Processor manufacturer | Intel |
| Processor family | Intel Xeon W |
| Processor model | W3-2525 |
| Processor cores | 8 |
| Processor threads | 16 |
| Processor boost frequency | 4.5 GHz |
| Processor frequency | 3.5 GHz |
| Performance cores | 8 |
| Efficient cores | 0 |
| Processor cache | 22.5 MB |
| Processor cache type | Smart Cache |
| Number of processors installed | 1 |
| Processor socket | LGA 4677 (Socket E) |
| Maximum turbo power | 210 W |
| Processor base power | 175 W |
Memory
| Specification | Value |
|---|---|
| Internal memory | 64 GB |
| Maximum internal memory | 256 GB |
| Internal memory type | DDR5-SDRAM |
| Memory layout (slots x size) | 4 x 16 GB |
| Memory slots | 4x DIMM |
| ECC | Yes |
| Memory data transfer rate | 4800 MT/s |
Storage
| Specification | Value |
|---|---|
| Total storage capacity | 2 TB |
| Optical drive type | No |
| Storage media | SSD |
| Number of storage drives installed | 2 |
| Total SSDs capacity | 2 TB |
| Number of SSDs installed | 2 |
| SSD capacity | 1 TB |
| SSD memory type | TLC |
| SSD interface | PCI Express 4.0 |
| SSD form factor | M.2 |
Graphics
| Specification | Value |
|---|---|
| Discrete graphics card | Yes |
| On-board graphics card | No |
| Discrete GPU manufacturer | NVIDIA |
| Discrete graphics card model | NVIDIA RTX 2000 Ada |
| Discrete graphics card memory | 16 GB |
| Discrete graphics memory type | GDDR6 |
| Number of discrete graphics cards | 1 |
| On-board graphics card model | Not available |
Performance
| Specification | Value |
|---|---|
| Product type | Workstation |
| Market positioning | Performance |
| Motherboard chipset | Intel W790 |
| Password protection | Yes |
| Password protection type | BIOS, Power on, User |
| Trusted Platform Module (TPM) | Yes |
| Trusted Platform Module (TPM) version | 2.0 |
Network
| Specification | Value |
|---|---|
| Ethernet LAN | Yes |
| Ethernet LAN data rates | 10,1000,2500,100 Mbit/s |
| Wi-Fi | No |
Ports & interfaces
| Specification | Value |
|---|---|
| USB 2.0 ports quantity | 0 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 6 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity | 0 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity | 0 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity | 0 |
| Thunderbolt 3 ports quantity | 0 |
| HDMI ports quantity | 0 |
| Ethernet LAN (RJ-45) ports | 1 |
| Combo headphone/mic port | Yes |
Power
| Specification | Value |
|---|---|
| Power supply | 675 W |
Design
| Specification | Value |
|---|---|
| Chassis type | Rack-mounted chassis |
| Cable lock slot | Yes |
| Cable lock slot type | Kensington |
| Product colour | Black |
Software
| Specification | Value |
|---|---|
| Operating system installed | Windows 11 Pro |
Display
| Specification | Value |
|---|---|
| Display included | No |
Brand-specific features
| Specification | Value |
|---|---|
| HP Support Assistant | Yes |
| HP segment | Business |
Audio
| Specification | Value |
|---|---|
| Audio chip | Realtek ALC3205-CG |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 438 mm |
| Depth | 656 mm |
| Height | 43 mm |
| Weight | 9.5 kg |
