HP Z2 G5 - 3,8 GHz - Intel® Core™ i7 - i7-10700K - 16 GB - 512 GB - Windows 10 Pro for Workstations

HP Z2 G5 - 3,8 GHz - Intel® Core™ i7 - i7-10700K - 16 GB - 512 GB - Windows 10 Pro for Workstations

Model Z2 G5 - 3,8 GHz - Intel® Core™ i7 - i7-10700K - 16 GB - 512 GB - Windows 10 Pro for WorkstationsPart no. 259L6EA#UUG

130 specifications
  • ProcessorIntel® Core™ i7
  • Memory16 GB
  • Storage512 GB
  • GraphicsNVIDIA Quadro P2200
  • TypeWorkstation
  • OSWindows 10 Pro for Workstations
See all specifications

Overview

Processor
Intel® Core™ i7
Memory
16 GB
Storage
512 GB
Graphics
NVIDIA Quadro P2200
Type
Workstation
OS
Windows 10 Pro for Workstations
Brand
HP
Model
Z2 G5 - 3,8 GHz - Intel® Core™ i7 - i7-10700K - 16 GB - 512 GB - Windows 10 Pro for Workstations
Part number
259L6EA#UUG
Also known as
HP Z2 G5 - 3,8 GHz - Intel® Core™ i7 - i7-10700K - 16 GB - 512 GB - Windows 10 Pro for Workstations Intel® Core™ i7 DDR4-SDRAM SSD NVIDIA Quadro P2200 Tower Wor

Specifications

130 specifications in 18 groups

Processor

Processor manufacturerIntel
Processor familyIntel® Core™ i7
Processor generation9th gen Intel® Core™ i7
Processor modeli7-10700K
Processor cores8
Processor threads16
Processor boost frequency5.1 GHz
Processor frequency3.8 GHz
Processor cache16 MB
Processor cache typeL3
System bus rate8 GT/s
Processor lithography14 nm
Processor operating modes64-bit
Processor codenameCoffee Lake
Thermal Design Power (TDP)95 W
Configurable TDP-down95 W
Configurable TDP-down frequency3.5 GHz
Tjunction100 °C
Maximum number of PCI Express lanes16
PCI Express configurations1x16, 2x8, 1x8+2x4
PCI Express slots version3.0
Processor socketLGA 1151 (Socket H4)
Maximum internal memory supported by processor128 GB
Memory types supported by processorDDR4-SDRAM
Memory clock speeds supported by processor2666 MHz
Memory bandwidth supported by processor (max)41.6 GB/s

Memory

Internal memory16 GB
Maximum internal memory128 GB
Internal memory typeDDR4-SDRAM
Memory layout (slots x size)1 x 16 GB
Memory slots4x DIMM
Memory clock speed3200 MHz
ECCNo

Storage

Total storage capacity512 GB
Optical drive typeNo
Storage mediaSSD
Total SSDs capacity512 GB
Number of SSDs installed1
SSD capacity512 GB
SSD memory typeTLC
NVMeYes
Card reader integratedNo

Graphics

Discrete graphics cardYes
On-board graphics cardYes
Discrete GPU manufacturerNVIDIA
Discrete graphics card modelNVIDIA Quadro P2200
Discrete graphics card memory5 GB
Discrete graphics memory typeGDDR5X
On-board GPU manufacturerIntel
On-board graphics card modelIntel® HD Graphics 630
Maximum on-board graphics card memory64 GB
Number of displays supported (on-board graphics)3
On-board graphics card base frequency350 MHz
On-board graphics card dynamic frequency (max)1200 MHz
On-board graphics card DirectX version12.0
On-board graphics card ID0x3E98
On-board graphics card OpenGL version4.5
Graphics card interfacePCIe x16

Performance

Product typeWorkstation
Market positioningPerformance
Motherboard chipsetIntel W480

Network

Ethernet LANYes
Ethernet LAN data rates10,100,1000 Mbit/s
Cabling technology10/100/1000Base-T(X)
LAN controllerIntel® I219-LM
Wi-FiNo
BluetoothNo

Ports & interfaces

USB 2.0 ports quantity2
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity4
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity0
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity4
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity0
Thunderbolt 3 ports quantity0
DisplayPorts quantity2
Ethernet LAN (RJ-45) ports1
Combo headphone/mic portYes
Headphone outputs1
Line-outYes
Line-inYes
Microphone inNo
DVI portNo

Expansion slots

PCI Express x1 (Gen 3.x) slots2
PCI Express x4 (Gen 3.x) slots1
PCI Express x16 (Gen 3.x) slots1
Mini PCI Express slots3

Design

Chassis typeTower
Placement supportedVertical
Product colourBlack

Software

Operating system installedWindows 10 Pro for Workstations
Operating system architecture64-bit

Display

Display includedNo

Processor special features

CPU configuration (max)1
Embedded options availableNo
Enhanced Intel SpeedStep TechnologyYes
Execute Disable BitYes
Idle StatesYes
Intel 64Yes
Intel Clear Video TechnologyYes
Intel Software Guard Extensions (Intel SGX)Yes
Intel Stable Image Platform Program (SIPP)Yes
Intel TSX-NIYes
Intel Trusted Execution TechnologyYes
Intel VT-x with Extended Page Tables (EPT)Yes
Intel Virtualization Technology (VT-x)Yes
Intel Virtualization Technology for Directed I/O (VT-d)Yes
Intel® AES New Instructions (Intel® AES-NI)Yes
Intel® Clear Video HD Technology (Intel® CVT HD)Yes
Intel® InTru™ 3D TechnologyYes
Intel® OS GuardYes
Intel® Secure KeyYes
Processor ARK ID186604
Processor package size37.5 x 37.5 mm
Scalability1S
Supported instruction setsSSE4.1, SSE4.2, AVX 2.0
Thermal Monitoring TechnologiesYes
Thermal solution specificationPCG 2015D
Intel® Turbo Boost Technology2.0
Intel® Hyper Threading Technology (Intel® HT Technology)No
Intel® Quick Sync Video TechnologyYes
Intel® Identity Protection Technology (Intel® IPT)Yes

Brand-specific features

HP Support AssistantYes
HP segmentBusiness

Weight & dimensions

Width169 mm
Depth385 mm
Height356 mm
Weight7 kg

Certificates

Low halogenYes

Sustainability

Sustainability certificatesENERGY STAR

Logistics data

Harmonized System (HS) code84715000

Keyboard

Keyboard typeUSB
