HP Z2 G4 (4RW94EA) + NVIDIA Quadro P400 (1ME43AT)

Model Z2 G4 (4RW94EA) + NVIDIA Quadro P400 (1ME43AT)Part no. B4RW94EA09

118 specifications

ProcessorIntel® Xeon®
Memory16 GB
Storage256 GB
GraphicsNVIDIA® Quadro® P400
TypeWorkstation
OSWindows 10 Pro for Workstations

See all specifications

Overview

Processor: Intel® Xeon®
Memory: 16 GB
Storage: 256 GB
Graphics: NVIDIA® Quadro® P400
Type: Workstation
OS: Windows 10 Pro for Workstations

Brand: HP
Category: PCs/Workstations
Model: Z2 G4 (4RW94EA) + NVIDIA Quadro P400 (1ME43AT)
Part number: B4RW94EA09
Also known as: HP Z2 G4 (4RW94EA) + NVIDIA Quadro P400 (1ME43AT) Intel® Xeon® E-2136 16 GB DDR4-SDRAM 256 GB SSD NVIDIA® Quadro® P400 Windows 10 Pro for Workstations SFF Works

Specifications

118 specifications in 19 groups

Processor

Specification	Value
Processor manufacturer	Intel
Processor family	Intel® Xeon®
Processor model	E-2136
Processor cores	6
Processor threads	12
Processor boost frequency	4.5 GHz
Processor frequency	3.3 GHz
Processor cache	12 MB
Processor cache type	Smart Cache
Bus type	DMI3
System bus rate	8 GT/s
Processor lithography	14 nm
Processor operating modes	64-bit
Processor codename	Coffee Lake
Thermal Design Power (TDP)	80 W
Tjunction	100 °C
Maximum number of PCI Express lanes	16
PCI Express configurations	1x16, 2x8, 1x8+2x4
PCI Express slots version	3.0
Number of processors installed	1
Processor socket	LGA 1151 (Socket H4)
Maximum internal memory supported by processor	128 GB
Memory types supported by processor	DDR4-SDRAM
Memory clock speeds supported by processor	2666 MHz
Memory bandwidth supported by processor (max)	41.6 GB/s

Memory

Specification	Value
Internal memory	16 GB
Maximum internal memory	64 GB
Internal memory type	DDR4-SDRAM
Memory layout (slots x size)	2 x 8 GB
Memory slots	4x DIMM
Memory clock speed	2666 MHz
ECC	Yes

Storage

Specification	Value
Total storage capacity	256 GB
Optical drive type	DVD±RW
Storage media	SSD
Total SSDs capacity	256 GB
Number of SSDs installed	1
SSD capacity	256 GB
SSD interface	PCI Express
Card reader integrated	No

Graphics

Specification	Value
Discrete graphics card	Yes
On-board graphics card	No
Discrete graphics card model	NVIDIA® Quadro® P400
Discrete graphics card memory	2 GB
Discrete graphics memory type	GDDR5
On-board graphics card model	Not available

Performance

Specification	Value
Product type	Workstation
Motherboard chipset	Intel C246
Audio output channels	5.1 channels

Optical drive

Specification	Value
Optical drives quantity	1

Network

Specification	Value
Ethernet LAN	Yes
Ethernet LAN data rates	10,100,1000 Mbit/s
Wi-Fi	No

Ports & interfaces

Specification	Value
USB 2.0 ports quantity	2
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	4
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity	0
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity	0
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity	1
Thunderbolt 3 ports quantity	0
DisplayPorts quantity	2
HDMI ports quantity	0
Ethernet LAN (RJ-45) ports	1
Combo headphone/mic port	Yes
Headphone outputs	0
Line-out	Yes
Line-in	Yes
Microphone in	No
VGA (D-Sub) ports quantity	0
DVI port	Yes
Serial ports quantity	1

Expansion slots

Specification	Value
Number of 3.5" bays	1
PCI Express x1 (Gen 3.x) slots	2
PCI Express x4 (Gen 3.x) slots	2
PCI Express x16 (Gen 3.x) slots	1

Power

Specification	Value
Power supply	310 W
Power supply input voltage	100 - 240 V
Power supply input frequency	50 - 60 Hz

Design

Specification	Value
Chassis type	SFF
Number of 2.5" bays	1
Product colour	Black
Country of origin	China

Software

Specification	Value
Operating system installed	Windows 10 Pro for Workstations
Operating system architecture	64-bit

Display

Specification	Value
Display included	No

Processor special features

Specification	Value
CPU configuration (max)	1
Embedded options available	No
Enhanced Intel SpeedStep Technology	Yes
Execute Disable Bit	Yes
Idle States	Yes
Intel 64	Yes
Intel Enhanced Halt State	Yes
Intel Secure Key Technology version	1.00
Intel Software Guard Extensions (Intel SGX)	Yes
Intel TSX-NI	Yes
Intel TSX-NI version	1.00
Intel Trusted Execution Technology	Yes
Intel VT-x with Extended Page Tables (EPT)	Yes
Intel Virtualization Technology (VT-x)	Yes
Intel Virtualization Technology for Directed I/O (VT-d)	Yes
Intel® AES New Instructions (Intel® AES-NI)	Yes
Intel® OS Guard	Yes
Intel® Secure Key	Yes
Processor ARK ID	134857
Processor package size	37.5 x 37.5 mm
Scalability	1S
Supported instruction sets	AVX 2.0, SSE4.1, SSE4.2
Thermal Monitoring Technologies	Yes
Intel® Turbo Boost Technology	2.0
Intel® Hyper Threading Technology (Intel® HT Technology)	Yes

Audio

Specification	Value
Audio chip	Conexant CX20632

Weight & dimensions

Specification	Value
Width	338 mm
Depth	381 mm
Height	100 mm
Weight	5.7 kg

Packaging content

Specification	Value
Mouse included	Yes
Keyboard included	Yes

Sustainability

Specification	Value
Sustainability certificates	ENERGY STAR

Logistics data

Specification	Value
Harmonized System (HS) code	84715000
