HP xw6600 Intel® Xeon® Quad Core 5410 2.33GHz 4GB/80GB DVD-ROM WVST Bus Workstation
Model xw6600 Intel® Xeon® Quad Core 5410 2.33GHz 4GB/80GB DVD-ROM WVST Bus WorkstationPart no. FE022AWEAN 883585979707
117 specifications
- ProcessorIntel® Xeon® 5000 Sequence
- Memory4 GB
- Storage80 GB
- TypeWorkstation
- Weight18.1 kg
- ColourBlack
Overview
- Processor
- Intel® Xeon® 5000 Sequence
- Memory
- 4 GB
- Storage
- 80 GB
- Type
- Workstation
- Weight
- 18.1 kg
- Colour
- Black
- Brand
- HP
- Category
- PCs/Workstations
- Model
- xw6600 Intel® Xeon® Quad Core 5410 2.33GHz 4GB/80GB DVD-ROM WVST Bus Workstation
- Part number
- FE022AW
- EAN / UPC
- 883585979707, 883585979516, 883585979523, 883585979530 +16 more
- Also known as
- HP xw6600 Intel® Xeon® Quad Core 5410 2.33GHz 4GB/80GB DVD-ROM WVST Bus Workstation Intel® Xeon® 5000 Sequence E5410 DDR2-SDRAM Mini Tower Black
Specifications
117 specifications in 17 groups
Processor
| Specification | Value |
|---|---|
| Processor manufacturer | Intel |
| Processor family | Intel® Xeon® 5000 Sequence |
| Processor model | E5410 |
| Processor cores | 4 |
| Processor threads | 4 |
| Processor frequency | 2.33 GHz |
| Processor cache | 12 MB |
| Processor cache type | L2 |
| Processor front side bus | 1333 MHz |
| Bus type | FSB |
| FSB Parity | Yes |
| Processor lithography | 45 nm |
| Processor operating modes | 64-bit |
| Processor series | Intel Xeon 5400 Series |
| Processor codename | Harpertown |
| Processor system type | DP |
| Thermal Design Power (TDP) | 80 W |
| Tcase | 67 °C |
| Number of processors installed | 1 |
| Processor socket | LGA 771 (Socket J) |
| Number of Processing Die Transistors | 820 M |
| Processing Die size | 214 mm² |
| CPU multiplier (bus/core ratio) | 7 |
| Stepping | E0 |
| ECC supported by processor | No |
Memory
| Specification | Value |
|---|---|
| Internal memory | 4 GB |
| Maximum internal memory | 32 GB |
| Internal memory type | DDR2-SDRAM |
| Memory layout (slots x size) | 4 x 1 GB |
| Memory clock speed | 667 MHz |
| ECC | Yes |
Storage
| Specification | Value |
|---|---|
| Optical drive type | DVD-ROM |
| HDD capacity | 80 GB |
| HDD interface | SATA |
| HDD speed | 7200 RPM |
| Storage drive controller | SATA 3GB/s NCQ |
| Disk subsystem controller | Integrated SATA 3 Gb/s controller with RAID (0, 1,5) capability |
| Diskette drive | No |
| Storage drive type | 80 GB |
Graphics
| Specification | Value |
|---|---|
| Maximum graphics card memory | 0.256 GB |
| Graphics card | Quadro NVS 290 |
| Video card features | NVIDIA Quadro NVS 290 |
Performance
| Specification | Value |
|---|---|
| Product type | Workstation |
| Motherboard chipset | Intel® 5400 |
Ports & interfaces
| Specification | Value |
|---|---|
| USB 2.0 ports quantity | 7 |
| Ethernet LAN (RJ-45) ports | 1 |
| Headphone outputs | 1 |
| Microphone in | Yes |
| VGA (D-Sub) ports quantity | 1 |
| PS/2 ports quantity | 2 |
| Serial ports quantity | 0 |
| Parallel ports quantity | 0 |
| I/O ports | Front: headphone, microphone, 2 USB 2.0 and 1 optional IEEE 1394A; Rear: 5 USB 2.0, 1 optional serial port, 2 PS/2 keyboard and mouse, 1 RJ-45 to integrated Gigabit LAN, audio In, audio Out, microphone; 1 USB 2.0 (internal) |
| Rear ports note | 5 USB 2.0; 2 PS/2; 1 RJ-45 to integrated Gigabit LAN; 1 audio in; 1 audio out; 1 microphone in |
Expansion slots
| Specification | Value |
|---|---|
| PCI Express x4 slots | 1 |
| PCI Express x8 slots | 1 |
| PCI Express x16 slots | 2 |
| Expansion slots | 6 full length slots: 2 PCI Express (x16) Gen2 Graphics slots, 2 PCI Express (x8 mechanically, x4 electrically) slots, 2 legacy PCI slots |
Power
| Specification | Value |
|---|---|
| Power requirements | 650 watts wide-ranging, active Power Factor Correction, 80 Plus Efficient |
| Power supply | 650 W |
Design
| Specification | Value |
|---|---|
| Chassis type | Mini Tower |
| Product colour | Black |
| Country of origin | China |
Software
| Specification | Value |
|---|---|
| Compatible operating systems | Genuine Windows Vista Business 32; Genuine Windows Vista Business 64; Genuine Windows XP Professional x64 Edition; Genuine Windows Vista Business 32 with downgrade to Windows XP Professional 32 custom installed; Genuine Windows Vista Business 64 with downgrade to Windows XP Professional 64 custom in |
Display
| Specification | Value |
|---|---|
| Display included | No |
| Display | HP LP3065 30in Flat Panel Monitor, HP LP2465 24in Flat Panel Monitor, HP LP2065 20.1in Flat Panel Monitor, HP LP1965 19in Flat Panel Monitor (all sold separately) |
Processor special features
| Specification | Value |
|---|---|
| Embedded options available | No |
| Enhanced Intel SpeedStep Technology | Yes |
| Execute Disable Bit | Yes |
| Idle States | Yes |
| Intel 64 | Yes |
| Intel Clear Video Technology | No |
| Intel Demand Based Switching | Yes |
| Intel Dual Display Capable Technology | No |
| Intel Enhanced Halt State | Yes |
| Intel FDI Technology | No |
| Intel Fast Memory Access | No |
| Intel Flex Memory Access | No |
| Intel Rapid Storage Technology | No |
| Intel Trusted Execution Technology | No |
| Intel VT-x with Extended Page Tables (EPT) | No |
| Intel Virtualization Technology (VT-x) | Yes |
| Intel Virtualization Technology for Directed I/O (VT-d) | No |
| Intel® AES New Instructions (Intel® AES-NI) | No |
| Intel® Clear Video HD Technology (Intel® CVT HD) | No |
| Intel® Clear Video Technology for Mobile Internet Devices (Intel CVT for MID) | No |
| Intel® InTru™ 3D Technology | No |
| Intel® Insider™ | No |
| Intel® Wireless Display (Intel® WiDi) | No |
| Processor ARK ID | 33080 |
| Processor code | SLBBC |
| Processor package size | 37.5 x 37.5 mm |
| Thermal Monitoring Technologies | Yes |
| Intel® Turbo Boost Technology | No |
| Intel® Hyper Threading Technology (Intel® HT Technology) | No |
| Intel® Quick Sync Video Technology | No |
| Intel® My WiFi Technology (Intel® MWT) | No |
| Intel® Anti-Theft Technology (Intel® AT) | No |
| Conflict-Free processor | No |
Audio
| Specification | Value |
|---|---|
| Audio system | High Definition Audio |
| Audio included | High Definition Integrated Realtek ALC262 Audio. Optional Sound Blaster X-Fi XtremeGamer Audio Card |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 5 - 35 °C |
| Storage temperature (T-T) | -40 - 60 °C |
| Operating relative humidity (H-H) | 8 - 85% |
| Storage relative humidity (H-H) | 8 - 90% |
| Relative humidity | 8 - 85% |
| Non-operating altitude | 9100 |
| Non-operating relative humidity (non-condensing) | 8 - 90% |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 165 mm |
| Depth | 440 mm |
| Height | 441 mm |
| Weight | 18.1 kg |
| Size (imperial) | 16.5 cm (6.5") |
Keyboard
| Specification | Value |
|---|---|
| Pointing device | PS/2 Optical Scroll Mouse |
| Keyboard type | HP Standard (USB, PS/2) |
Other features
| Specification | Value |
|---|---|
| Drive bays | 2 external 5.25" bays and 1 external 3.5" bay for optional floppy drive 2 internal 3.5” bays or 3 internal 2.5" bays |
| UNSPSC-code | 43211507 |
