ProDesk 4 G1i
Model ProDesk 4 G1iPart no. C86HPESEAN 199642074187
116 specifications
- ProcessorIntel Core Ultra 5
- Memory16 GB
- Storage512 GB
- GraphicsNot available
- TypePC
- OSFreeDOS
Overview
- Processor
- Intel Core Ultra 5
- Memory
- 16 GB
- Storage
- 512 GB
- Graphics
- Not available
- Type
- PC
- OS
- FreeDOS
- Brand
- HP
- Category
- PCs/Workstations
- Model
- ProDesk 4 G1i
- Part numbers
- C86HPES, C10Y2EC#ABA, 9H7D2ET, 9H7W0ET, 9H7V1ET, C21FHEC +7 more
- EAN / UPC
- 199642074187, 199642074194, 199642191044, 199642191068 +6 more
- Also known as
- HP ProDesk 4 G1i Intel Core Ultra 5 225 16 GB DDR5-SDRAM 512 GB SSD FreeDOS Tower PC AI PC Black
Specifications
116 specifications in 26 groups
Processor
| Specification | Value |
|---|---|
| Processor manufacturer | Intel |
| Processor family | Intel Core Ultra 5 |
| Processor generation | Intel Core Ultra (Series 2) |
| Processor model | 225 |
| Processor cores | 10 |
| Processor threads | 10 |
| Processor boost frequency | 4.9 GHz |
| Performance cores | 6 |
| Efficient cores | 4 |
| Performance-core Max Turbo Frequency | 4.9 GHz |
| Efficient-core Max Turbo Frequency | 4.4 GHz |
| Performance-core base frequency | 3.3 GHz |
| Efficient-core base frequency | 2.7 GHz |
| Processor cache | 20 MB |
| Processor cache type | L3 |
| Maximum turbo power | 121 W |
| Processor base power | 65 W |
Neural processor unit (NPU)
| Specification | Value |
|---|---|
| Neural processor unit (NPU) | Intel AI Boost |
| Sparsity support | Yes |
| Windows Studio effects support | Yes |
| AI software frameworks supported by NPU | DirectML, OpenVINO, Windows ML, ONNX RT, WebNN |
| Total processor performance up to | 23 TOPs |
| NPU performance up to | 13 TOPs |
| GPU performance up to | 4 TOPs |
Memory
| Specification | Value |
|---|---|
| Internal memory | 16 GB |
| Maximum internal memory | 16 GB |
| Internal memory type | DDR5-SDRAM |
| Memory layout (slots x size) | 1 x 16 GB |
| Memory slots | 4x DIMM |
| Memory clock speed | 5600 MHz |
| Memory module type | UDIMM |
Storage
| Specification | Value |
|---|---|
| Total storage capacity | 512 GB |
| Optical drive type | No |
| Storage media | SSD |
| Number of storage drives installed | 1 |
| Total SSDs capacity | 512 GB |
| Number of SSDs installed | 1 |
| SSD capacity | 512 GB |
| NVMe | Yes |
| SSD interface | PCI Express |
| SSD form factor | M.2 |
Graphics
| Specification | Value |
|---|---|
| Discrete graphics card | No |
| On-board graphics card | Yes |
| Discrete graphics card model | Not available |
| On-board GPU manufacturer | Intel |
| On-board graphics card family | Intel® Graphics |
| On-board graphics card model | Intel® Graphics |
Performance
| Specification | Value |
|---|---|
| Product type | PC |
| Market positioning | Proven productivity |
| Motherboard chipset | Intel® Q870 |
| Password protection | Yes |
| Password protection type | BIOS, Power on |
Network
| Specification | Value |
|---|---|
| Ethernet LAN | Yes |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| Cabling technology | 10/100/1000Base-T(X) |
| Wi-Fi | No |
Ports & interfaces
| Specification | Value |
|---|---|
| USB 2.0 ports quantity | 3 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 2 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity | 0 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity | 3 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity | 1 |
| Thunderbolt 3 ports quantity | 0 |
| DisplayPorts quantity | 1 |
| DisplayPort version | 2.1 |
| HDMI ports quantity | 1 |
| HDMI version | 2.1 |
| Ethernet LAN (RJ-45) ports | 1 |
| Combo headphone/mic port | Yes |
| Line-out | Yes |
| Line-in | Yes |
| Microphone in | Yes |
Expansion slots
| Specification | Value |
|---|---|
| Number of 3.5" bays | 2 |
| PCI Express x1 (Gen 3.x) slots | 2 |
| PCI Express x16 (Gen 4.x) slots | 1 |
Power
| Specification | Value |
|---|---|
| Power supply | 280 W |
| Power supply input voltage | 100 - 240 V |
| Power supply input frequency | 50 - 60 Hz |
Design
| Specification | Value |
|---|---|
| Chassis type | Tower |
| Colour name | Jack black |
| Placement supported | Vertical |
| Product colour | Black |
| Country of origin | Czech Republic |
Software
| Specification | Value |
|---|---|
| Operating system installed | FreeDOS |
| Pre-installed software | HP Notifications; HP PC Hardware Diagnostics UEFI; HP PC Hardware Diagnostics Windows |
Display
| Specification | Value |
|---|---|
| Display included | No |
Processor special features
| Specification | Value |
|---|---|
| Intel® Turbo Boost Technology | Yes |
Brand-specific features
| Specification | Value |
|---|---|
| HP Artificial Intelligence | AI PC |
| HP segment | Business |
| HP GTIN (EAN/UPC) | 199642191068 |
Audio
| Specification | Value |
|---|---|
| Audio chip | Realtek ALC3252 |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 10 - 35 °C |
| Operating relative humidity (H-H) | 10 - 90% |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 337 mm |
| Depth | 308 mm |
| Height | 337 mm |
| Weight | 5.58 kg |
Packaging data
| Specification | Value |
|---|---|
| Package width | 287 mm |
| Package depth | 400 mm |
| Package height | 499 mm |
| Package weight | 8.09 kg |
Packaging content
| Specification | Value |
|---|---|
| Mouse included | Yes |
| Keyboard included | Yes |
| Numeric keypad | No |
| Input device model | HP 125 Wired Mouse |
Sustainability
| Specification | Value |
|---|---|
| Sustainability certificates | TCO10 |
| Sustainable technologies and materials | At least 10% ITE-derived closed loop plastic; Ocean-bound plastic in speaker enclosure and I/O strip; 100% recycled rare earth elements in speaker; Molded paper pulp cushion inside box is made of 100% recycled or certified sources; Bulk packaging available; 80 Plus Platinum power supplies available; |
Keyboard
| Specification | Value |
|---|---|
| Keyboard connectivity | Wired |
Carbon footprint
| Specification | Value |
|---|---|
| Carbon emissions, end-of-life (kg of CO2e) | 1.633 |
| Carbon emissions, logistics (kg of CO2e) | 2.041 |
| Carbon emissions, manufacturing (kg of CO2e) | 172.984 |
| Total carbon emissions, w/o use phase (kg of CO2e) | 32.986 |
| Total carbon footprint (kg of CO2e) | 209.644 |
Supplier features
| Specification | Value |
|---|---|
| Manufacturer warranty | 1 year (1/1/1) limited warranty includes 1 year of parts, labor and on-site repair. Terms and conditions vary by country. Certain restrictions and exclusions apply. |
| Support service included | HP 3 year Next Business Day Onsite Desktop HardwareSupport. For terms and conditions, please visit https://h20195.www2.hp.com/v2/GetPDF.aspx/4AA5-6385EEE & https://www8.hp.com/h20195/v2/getpdf.aspx/4AA5-7123EEGB.pdf |
Technical details
| Specification | Value |
|---|---|
| General Product Safety Regulation (GPSR) URL | https://support.hp.com/us-en/document/ish_6126692-6126777-16?openCLC=true |
Other features
| Specification | Value |
|---|---|
| UNSPSC-code | 43211507 |
