HP Pro SFF 400 G9 + P24 G5 Monitor

Model Pro SFF 400 G9 + P24 G5 MonitorPart no. B6U492EADISPL

94 specifications

Display60.5 cm (23.8")
Resolution1920 x 1080 pixels
ProcessorIntel® Core™ i5
Memory16 GB
Storage512 GB
GraphicsNot available

See all specifications

Overview

Display: 60.5 cm (23.8")
Resolution: 1920 x 1080 pixels
Processor: Intel® Core™ i5
Memory: 16 GB
Storage: 512 GB
Graphics: Not available

Brand: HP
Category: PCs/Workstations
Model: Pro SFF 400 G9 + P24 G5 Monitor
Part numbers: B6U492EADISPL, B6U4G3EADISPL
Also known as: HP Pro SFF 400 G9 + P24 G5 Monitor Intel® Core™ i5 i5-12500 16 GB DDR4-SDRAM 512 GB SSD Windows 11 Pro PC Black

Specifications

94 specifications in 18 groups

Processor

Specification	Value
Processor manufacturer	Intel
Processor family	Intel® Core™ i5
Processor generation	12th gen Intel® Core™ i5
Processor model	i5-12500
Processor cores	6
Processor threads	12
Processor boost frequency	4.6 GHz
Processor frequency	3 GHz
Processor cache	18 MB
Processor cache type	L3
Bus type	DMI4
Number of processors installed	1

Memory

Specification	Value
Internal memory	16 GB
Maximum internal memory	64 GB
Internal memory type	DDR4-SDRAM
Memory layout (slots x size)	1 x 16 GB
Memory slots	2x DIMM
Memory clock speed	3200 MHz
Non-ECC	Yes

Storage

Specification	Value
Total storage capacity	512 GB
Optical drive type	No
Storage media	SSD
Number of storage drives installed	1
Total SSDs capacity	512 GB
Number of SSDs installed	1
SSD capacity	512 GB
NVMe	Yes
SSD interface	PCI Express

Graphics

Specification	Value
Discrete graphics card	No
On-board graphics card	Yes
Discrete graphics card model	Not available
On-board GPU manufacturer	Intel
On-board graphics card family	Intel® UHD Graphics
On-board graphics card model	Intel UHD Graphics 770

Performance

Specification	Value
Product type	PC
Market positioning	Proven productivity
Motherboard chipset	Intel Q670
Password protection	Yes
Trusted Platform Module (TPM)	Yes

Network

Specification	Value
Ethernet LAN	Yes
Wi-Fi	Yes
Top Wi-Fi standard	Wi-Fi 6E (802.11ax)
WLAN controller manufacturer	Intel
Wi-Fi standards	Wi-Fi 6E (802.11ax)
WLAN controller model	Intel Wi-Fi 6E AX211
Antenna type	2x2
Bluetooth	Yes
Bluetooth version	5.3

Ports & interfaces

Specification	Value
USB 2.0 ports quantity	2
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	3
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity	0
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity	3
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity	1
Thunderbolt 3 ports quantity	0
DisplayPorts quantity	1
HDMI ports quantity	1
HDMI version	1.4
Ethernet LAN (RJ-45) ports	1
Combo headphone/mic port	Yes
Line-out	Yes

Expansion slots

Specification	Value
Number of 3.5" bays	1
PCI Express x1 (Gen 3.x) slots	1
PCI Express x16 (Gen 4.x) slots	1

Design

Specification	Value
Chassis type	SFF
Product colour	Black
Introduction year	2023

Software

Specification	Value
Operating system installed	Windows 11 Pro

Display

Specification	Value
Display included	Yes
Display diagonal	60.5 cm (23.8")
Display resolution	1920 x 1080 pixels
Panel type	IPS
Native aspect ratio	16:9
Contrast ratio (typical)	1000:1
Display number of colours	16.78 million colours
Display brightness	250 cd/m²
Viewing angle, horizontal	178°
Viewing angle, vertical	178°

Processor special features

Specification	Value
CPU configuration (max)	1

Brand-specific features

Specification	Value
HP Support Assistant	Yes
HP Security tools	HP Secure Erase; HP Sure Click; HP Tamper Lock; HP Sure Start Gen7; HP Sure Sense2
HP Software provided	HP Notifications; HP PC Hardware Diagnostics UEFI; HP Connection Optimizer; HP Privacy Settings; HP Desktop Support Utilities; MyHP; HP QuickDrop; HP Easy Clean; HP Easy Clean Keyboard Driver
HP segment	Business

Audio

Specification	Value
Audio chip	Realtek ALC3252

Operational conditions

Specification	Value
Operating temperature (T-T)	10 - 35 °C
Operating relative humidity (H-H)	10 - 90%

Weight & dimensions

Specification	Value
Width	270 mm
Depth	95 mm
Height	308 mm
Weight	4.2 kg

Packaging data

Specification	Value
Package width	394 mm
Package depth	205 mm
Package height	499 mm
Package weight	7.25 kg

Sustainability

Specification	Value
Sustainability certificates	ENERGY STAR
