HP Pavilion Elite m9567it

Model Pavilion Elite m9567itPart no. M9567IT

116 specifications

ProcessorIntel® Core™2 Quad
Memory4 GB
Storage1 TB
GraphicsNVIDIA® GeForce® 9800 GT
TypePC
OSWindows Vista Home Premium

See all specifications

Overview

Processor: Intel® Core™2 Quad
Memory: 4 GB
Storage: 1 TB
Graphics: NVIDIA® GeForce® 9800 GT
Type: PC
OS: Windows Vista Home Premium

Brand: HP
Category: PCs/Workstations
Model: Pavilion Elite m9567it
Part number: M9567IT
Also known as: HP Pavilion Elite m9567it Intel® Core™2 Quad Q9400 4 GB DDR2-SDRAM 1 TB NVIDIA® GeForce® 9800 GT Windows Vista Home Premium Desktop PC

Specifications

116 specifications in 19 groups

Processor

Specification	Value
Processor manufacturer	Intel
Processor family	Intel® Core™2 Quad
Processor model	Q9400
Processor cores	4
Processor threads	4
Processor frequency	2.66 GHz
Processor cache	6 MB
Processor cache type	L2
Processor front side bus	1333 MHz
Bus type	FSB
FSB Parity	No
Processor lithography	45 nm
Processor operating modes	64-bit
Processor series	Intel Core 2 Quad Q9000 Series for Desktop
Processor codename	Yorkfield
Thermal Design Power (TDP)	95 W
Tcase	71.4 °C
Processor socket	LGA 775 (Socket T)
Number of Processing Die Transistors	456 M
Processing Die size	164 mm²
CPU multiplier (bus/core ratio)	8
Stepping	R0
ECC supported by processor	No

Memory

Specification	Value
Internal memory	4 GB
Maximum internal memory	8 GB
Internal memory type	DDR2-SDRAM

Storage

Specification	Value
Total storage capacity	1 TB
Number of HDDs installed	1
HDD interface	SATA
HDD speed	5400 RPM
Card reader integrated	Yes
Compatible memory cards	MMC, SD, SmartMedia
Drive device, transfer rate	3072 MB/s
RAID levels	0, 1

Graphics

Specification	Value
Discrete graphics card model	NVIDIA® GeForce® 9800 GT
Discrete graphics card memory	1 GB
Discrete graphics memory type	GDDR3
Maximum graphics card memory	2.815 GB
Graphics card family	NVIDIA

Performance

Specification	Value
Product type	PC
Audio output channels	7.1 channels

Optical drive

Specification	Value
CD read speed	40x
CD write speed	40x
CD rewrite speed	24x
DVD read speed	16x
DVD rewrite speed	8x
DVD write speed	16x
Double Layer DVD write speed	4x

Network

Specification	Value
Ethernet LAN data rates	1000 Mbit/s
Networking features	10/100/1000 Base-T
Wireless technology	LAN 802.11 b/g/n

Ports & interfaces

Specification	Value
USB 2.0 ports quantity	6
HDMI ports quantity	1
Ethernet LAN (RJ-45) ports	1
Headphone outputs	1
Microphone in	Yes
VGA (D-Sub) ports quantity	1
DVI port	Yes
PS/2 ports quantity	2
Firewire (IEEE 1394) ports	2
S/PDIF out port	Yes
Serial ports quantity	0
Parallel ports quantity	0

Expansion slots

Specification	Value
PCI Express x1 slots	2
PCI Express x16 slots	1

Power

Specification	Value
Power supply	460 W

Design

Specification	Value
Chassis type	Desktop
Country of origin	China

Software

Specification	Value
Operating system installed	Windows Vista Home Premium
Trial software	Microsoft Office Home & Student Edition 2007 Norton Internet Security 2009
Bundled software	Windows Media Center Vista Service Pack 1 MediaSmart DVD Premium BD Windows Movie Maker Windows DVD Maker CyberLink DVD Suite 6 My HP Games HP MediaSmart Software Suite Muvee Reveal Premium Microsoft Works 9 EasyBits Magic Desktop HP Total Care Advisor HP Hardware Diagnostic Tools Help & Support Cen

Display

Specification	Value
Display included	No

Processor special features

Specification	Value
Embedded options available	Yes
Enhanced Intel SpeedStep Technology	Yes
Execute Disable Bit	Yes
Idle States	Yes
Intel 64	Yes
Intel Clear Video Technology	No
Intel Demand Based Switching	No
Intel Dual Display Capable Technology	No
Intel Enhanced Halt State	Yes
Intel FDI Technology	No
Intel Fast Memory Access	No
Intel Flex Memory Access	No
Intel Rapid Storage Technology	No
Intel Trusted Execution Technology	Yes
Intel VT-x with Extended Page Tables (EPT)	No
Intel Virtualization Technology (VT-x)	Yes
Intel Virtualization Technology for Directed I/O (VT-d)	Yes
Intel® AES New Instructions (Intel® AES-NI)	No
Intel® Clear Video HD Technology (Intel® CVT HD)	No
Intel® Clear Video Technology for Mobile Internet Devices (Intel CVT for MID)	No
Intel® InTru™ 3D Technology	No
Intel® Insider™	No
Intel® Wireless Display (Intel® WiDi)	No
Processor ARK ID	35365
Processor code	SLB6B
Processor package size	37.5 x 37.5 mm
Thermal Monitoring Technologies	Yes
Intel® Turbo Boost Technology	No
Intel® Hyper Threading Technology (Intel® HT Technology)	No
Intel® Quick Sync Video Technology	No
Intel® My WiFi Technology (Intel® MWT)	No
Intel® Anti-Theft Technology (Intel® AT)	No
Conflict-Free processor	No

Audio

Specification	Value
Audio system direct 3D sound	Yes
Audio drivers	Realtek ALC 888S

Weight & dimensions

Specification	Value
Width	178 mm
Depth	422 mm
Height	394 mm
Weight	15 kg

Packaging content

Specification	Value
Mouse included	Yes
Remote control included	Yes

Features

Specification	Value
TV tuner type	DVB-T
Motherboard manufacturer	Asus

Other features

Specification	Value
TV tuner integrated	Yes
