HP Pavilion p6101f AMD Athlon II X2 7550

6 GB DDR2-SDRAM 500 GB HDD Windows Vista Home Premium Mini Tower PC Black

Model p6101fPart no. NY534AA

98 specifications

ProcessorAMD Athlon II X2
Memory6 GB
Storage500 GB
GraphicsNot available
SpeedWi-Fi 4 (802.11n)
TypePC

See all specifications

Overview

Processor: AMD Athlon II X2
Memory: 6 GB
Storage: 500 GB
Graphics: Not available
Speed: Wi-Fi 4 (802.11n)
Type: PC

Brand: HP
Category: PCs/Workstations
Model: p6101f
Part number: NY534AA
Also known as: HP Pavilion p6101f AMD Athlon II X2 7550 6 GB DDR2-SDRAM 500 GB HDD Windows Vista Home Premium Mini Tower PC Black

Specifications

98 specifications in 19 groups

Processor

Specification	Value
Processor manufacturer	AMD
Processor family	AMD Athlon II X2
Processor model	7550
Processor cores	2
Processor threads	2
Processor frequency	2.5 GHz
Processor cache	1 MB
Processor cache type	L2
Number of processors installed	1
Processor socket	Socket AM2

Memory

Specification	Value
Internal memory	6 GB
Maximum internal memory	16 GB
Internal memory type	DDR2-SDRAM
Memory slots	4x DIMM
Memory clock speed	800 MHz
Non-ECC	Yes

Storage

Specification	Value
Total storage capacity	500 GB
Optical drive type	DVD Super Multi DL
Storage media	HDD
Number of HDDs installed	1
HDD capacity	500 GB
HDD interface	SATA
HDD speed	7200 RPM
HDD size	3.5"
Card reader integrated	Yes
Compatible memory cards	CF, CF+, Memory Stick (MS), MicroDrive, MiniSD, MMC, MMC Mobile, MMC+, MS Duo, MS PRO, MS PRO Duo, RS-MMC, SD, SmartMedia, xD

Graphics

Specification	Value
On-board graphics card	Yes
Discrete graphics card model	Not available
Number of discrete graphics cards	0
On-board graphics card family	NVIDIA GeForce
On-board graphics card model	NVIDIA GeForce 9100

Performance

Specification	Value
Product type	PC
Motherboard form factor	micro ATX
Password protection	Yes
Audio output channels	7.1 channels

Optical drive

Specification	Value
Optical drives quantity	1

Network

Specification	Value
Ethernet LAN	Yes
Ethernet LAN data rates	10,100 Mbit/s
Wi-Fi	Yes
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
Wi-Fi standards	802.11a, 802.11b, 802.11g

Ports & interfaces

Specification	Value
USB 2.0 ports quantity	6
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	0
HDMI ports quantity	0
Ethernet LAN (RJ-45) ports	1
Headphone outputs	1
Line-out	Yes
Line-in	Yes
Microphone in	Yes
VGA (D-Sub) ports quantity	1
DVI port	Yes
PS/2 ports quantity	2
Firewire (IEEE 1394) ports	1
S/PDIF out port	Yes

Expansion slots

Specification	Value
Number of 3.5" bays	3

Power

Specification	Value
Power supply	300 W
Power supply input voltage	100 - 240 V
Power supply input frequency	50 - 60 Hz

Design

Specification	Value
Chassis type	Mini Tower
Placement supported	Vertical
Number of 5.25" bays	2
Liquid cooling system	No
Product colour	Black
Country of origin	China

Software

Specification	Value
Operating system installed	Windows Vista Home Premium
Operating system architecture	64-bit
Drivers included	Yes

Display

Specification	Value
Display included	No

Processor special features

Specification	Value
Intel 64	No
Intel® Active Management Technology (Intel® AMT)	No
Intel® High Definition Audio (Intel® HD Audio)	No
Intel® Matrix Storage Technology (Intel® MST)	No
Intel® Small Business Advantage (Intel® SBA)	No
Intel® Wireless Display (Intel® WiDi)	No
Intel® Smart Response Technology	No
Intel® Rapid Start Technology	No
Intel® Turbo Boost Technology	No
Intel Smart Connect Technology	No
Intel® Hyper Threading Technology (Intel® HT Technology)	No
Intel® Quick Sync Video Technology	No
Intel® My WiFi Technology (Intel® MWT)	No
Intel® Identity Protection Technology (Intel® IPT)	No
Intel® Anti-Theft Technology (Intel® AT)	No

Audio

Specification	Value
Audio system	HD

Weight & dimensions

Specification	Value
Width	175 mm
Depth	414 mm
Height	387 mm
Weight	9.6 kg

Packaging data

Specification	Value
Package width	498 mm
Package depth	599 mm
Package height	245 mm
Package weight	14 kg

Packaging content

Specification	Value
Mouse included	Yes
Keyboard included	Yes
Numeric keypad	Yes
Cables included	AC
Manual	Yes

Keyboard

Specification	Value
Windows keys	Yes
