HP Mini G9
HP

Mini G9

Model Mini G9Part no. 86D02EAEAN 198828297945

96 specifications
  • ProcessorIntel® Core™ i5
  • Memory16 GB
  • Storage512 GB
  • GraphicsNot available
  • SpeedWi-Fi 6E (802.11ax)
  • TypeWorkstation
See all specifications

Overview

Processor
Intel® Core™ i5
Memory
16 GB
Storage
512 GB
Graphics
Not available
Speed
Wi-Fi 6E (802.11ax)
Type
Workstation
Brand
HP
Model
Mini G9
Part numbers
86D02EA, 86D01EA, 86D03EA
EAN / UPC
198828297945, 197498782430, 197498782447, 197498782584 +2 more
Also known as
HP Z2 Mini G9 Intel® Core™ i5 i5-13400 16 GB DDR5-SDRAM 512 GB SSD Windows 11 Pro Mini PC Workstation Black

Specifications

96 specifications in 21 groups

Processor

Processor manufacturerIntel
Processor familyIntel® Core™ i5
Processor generation13th gen Intel® Core™ i5
Processor modeli5-13400
Processor cores10
Processor threads16
Processor boost frequency4.6 GHz
Performance cores6
Efficient cores4
Performance-core Max Turbo Frequency4.6 GHz
Efficient-core Max Turbo Frequency3.3 GHz
Performance-core base frequency2.5 GHz
Efficient-core base frequency1.8 GHz
Processor cache20 MB
Processor cache typeL3
Maximum turbo power154 W
Processor base power65 W

Memory

Internal memory16 GB
Maximum internal memory64 GB
Internal memory typeDDR5-SDRAM
Memory layout (slots x size)1 x 16 GB
Memory slots2x SO-DIMM
Memory clock speed5600 MHz
ECCNo
Non-ECCYes

Storage

Total storage capacity512 GB
Optical drive typeNo
Storage mediaSSD
Number of storage drives installed1
Total SSDs capacity512 GB
Number of SSDs installed1
SSD capacity512 GB
SSD interfacePCI Express
SSD form factorM.2

Graphics

Discrete graphics cardNo
On-board graphics cardYes
Discrete graphics card modelNot available
On-board GPU manufacturerIntel
On-board graphics card familyIntel® UHD Graphics
On-board graphics card modelIntel UHD Graphics 730

Performance

Product typeWorkstation
Market positioningPerformance
Password protectionYes
Password protection typeBIOS, Power on, User
Built-in speaker(s)Yes

Network

Ethernet LANYes
Wi-FiYes
Top Wi-Fi standardWi-Fi 6E (802.11ax)
WLAN controller manufacturerIntel
Wi-Fi standardsWi-Fi 6E (802.11ax)
WLAN controller modelIntel Wi-Fi 6E AX211
Antenna type2x2
BluetoothYes
Bluetooth version5.3

Ports & interfaces

USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity4
USB 3.2 Gen 2x2 Type-C ports quantity2
DisplayPorts quantity2
DisplayPort version1.4
Combo headphone/mic portYes

Expansion slots

PCI Express x4 (Gen 4.x) slots2
PCI Express x8 (Gen 4.x) slots1

Power

Power supply280 W
Power supply input voltage100 - 240 V
Power supply input frequency50 - 60 Hz

Design

Chassis typeMini PC
Placement supportedHorizontal/Vertical
Product colourBlack
Introduction year2023

Software

Operating system installedWindows 11 Pro
Pre-installed softwareHP PC Hardware Diagnostics UEFI; HP Support Assistant; HP PC Hardware Diagnostics Windows; HP Privacy Settings; HP Desktop Support Utilities; HP Image Assistant; HP Manageability Integration Kit; HP Notifications; Performance Advisor 3.0; HP Data Science Stack; myHP
Bundled softwareHP Wolf Pro Security Edition (1 year)

Display

Display includedNo

Brand-specific features

HP Support AssistantYes
HP Security toolsHP Secure Erase; HP Sure Click; HP BIOSphere Gen6; HP Sure Admin; Hood Sensor Optional Kit; HP Client Security Manager Gen6; HP Sure Start Gen7; HP Sure Recover Gen4; HP Tamper Lock; HP Sure Sense Gen2; HP Sure Run Gen5
HP Management toolsHP BIOS Configuration Utility (download)
HP Software providedHP PC Hardware Diagnostics UEFI; HP PC Hardware Diagnostics Windows; ZCentral Remote Boost; HP Image Assistant; HP Manageability Integration Kit; Performance Advisor 3.0
HP segmentBusiness
HP GTIN (EAN/UPC)197498782430

Audio

Audio chipRealtek ALC3205-VA2-CG
Number of speakers1

Weight & dimensions

Width211 mm
Depth218 mm
Height69 mm
Weight2.4 kg

Packaging data

Package width499 mm
Package depth170 mm
Package height298 mm
Package weight4.8 kg

Packaging content

Mouse connectivityWired
Mouse includedYes
Keyboard includedYes

Sustainability

Sustainable technologies and materials80 Plus® Gold power supplies available; Bulk packaging available; Molded paper pulp cushion inside box is 100% sustainably sourced and recyclable; Outside box and corrugated cushions are 100% sustainably sourced and recyclable; 55% post-consumer recycled plastic; 15% ITE-derived closed loop plastic;

Keyboard

Keyboard connectivityWired
Keyboard typeUSB

Logistics data

Harmonized System (HS) code8471500000

Technical details

General Product Safety Regulation (GPSR) URLhttps://support.hp.com/us-en/document/ish_6126692-6126777-16?openCLC=true https://h10032.www1.hp.com/ctg/Manual/c08200880.pdf
