E66P3EA PC/workstation 285
32 GB DDR5-SDRAM 1 TB SSD Windows 11 Pro Tower AI Workstation, AI PC Black
Model E66P3EAEAN 885981545821
78 specifications
- Processor285
- Memory32 GB
- Storage1 TB
- SpeedWi-Fi 7 (802.11be)
- TypeWorkstation
- OSWindows 11 Pro
Overview
- Processor
- 285
- Memory
- 32 GB
- Storage
- 1 TB
- Speed
- Wi-Fi 7 (802.11be)
- Type
- Workstation
- OS
- Windows 11 Pro
- Brand
- HP
- Category
- PCs/Workstations
- Model
- E66P3EA
- Part number
- E66P3EA
- EAN / UPC
- 885981545821
- Also known as
- HP E66P3EA PC/workstation 285 32 GB DDR5-SDRAM 1 TB SSD Windows 11 Pro Tower AI Workstation, AI PC Black
Specifications
78 specifications in 20 groups
Processor
| Specification | Value |
|---|---|
| Processor manufacturer | Intel |
| Processor model | 285 |
| Processor cores | 24 |
| Processor threads | 24 |
| Processor boost frequency | 5.6 GHz |
| Processor cache | 36 MB |
| Processor cache type | L3 |
Neural processor unit (NPU)
| Specification | Value |
|---|---|
| Neural processor unit (NPU) | Intel AI Boost |
| NPU performance up to | 13 TOPs |
Memory
| Specification | Value |
|---|---|
| Internal memory | 32 GB |
| Internal memory type | DDR5-SDRAM |
| Memory layout (slots x size) | 1 x 32 GB |
| Memory slots | 4x DIMM |
| Memory clock speed | 5600 MHz |
| Non-ECC | Yes |
| Memory module type | UDIMM |
Storage
| Specification | Value |
|---|---|
| Total storage capacity | 1 TB |
| Storage media | SSD |
| Number of storage drives installed | 1 |
| Total SSDs capacity | 1 TB |
| Number of SSDs installed | 1 |
| SSD capacity | 1 TB |
| SSD memory type | TLC |
| NVMe | Yes |
| SSD interface | PCI Express 4.0 |
| SSD form factor | M.2 |
Graphics
| Specification | Value |
|---|---|
| On-board graphics card | Yes |
| On-board GPU manufacturer | Intel |
| On-board graphics card family | Intel® Graphics |
| On-board graphics card model | Intel® Graphics |
Performance
| Specification | Value |
|---|---|
| Product type | Workstation |
| Market positioning | Performance |
| Motherboard chipset | Intel® Q870 |
| Password protection | Yes |
| Password protection type | BIOS, Power on |
Network
| Specification | Value |
|---|---|
| Ethernet LAN | Yes |
| Wi-Fi | Yes |
| Top Wi-Fi standard | Wi-Fi 7 (802.11be) |
| WLAN controller manufacturer | Intel |
| Wi-Fi standards | Wi-Fi 7 (802.11be) |
| WLAN controller model | Intel Wi-Fi 7 BE200 |
| Antenna type | 2x2 |
| Bluetooth | Yes |
| Bluetooth version | 5.4 |
Ports & interfaces
| Specification | Value |
|---|---|
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 2 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity | 4 |
| USB 3.2 Gen 2x2 Type-C ports quantity | 2 |
| HDMI ports quantity | 1 |
| HDMI version | 2.1 |
| Microphone in | Yes |
Expansion slots
| Specification | Value |
|---|---|
| Number of 3.5" bays | 2 |
| PCI Express x1 (Gen 3.x) slots | 2 |
| PCI Express x16 (Gen 5.x) slots | 1 |
Power
| Specification | Value |
|---|---|
| Power supply | 400 W |
Design
| Specification | Value |
|---|---|
| Chassis type | Tower |
| Colour name | Black |
| Product colour | Black |
| Intel® vPro™ Platform Eligibility | Yes |
Software
| Specification | Value |
|---|---|
| Operating system installed | Windows 11 Pro |
| Bundled software | HP Wolf Pro Security Edition (1 year) |
Processor special features
| Specification | Value |
|---|---|
| Intel® Turbo Boost Technology | Yes |
Brand-specific features
| Specification | Value |
|---|---|
| HP Artificial Intelligence | AI Workstation, AI PC |
| HP segment | Business |
| HP GTIN (EAN/UPC) | 885981545821 |
Audio
| Specification | Value |
|---|---|
| Audio chip | Realtek ALC3252 |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 337 mm |
| Depth | 308 mm |
| Height | 337 mm |
| Weight | 5.51 kg |
Packaging data
| Specification | Value |
|---|---|
| Package width | 287 mm |
| Package depth | 400 mm |
| Package height | 499 mm |
| Package weight | 7.67 kg |
Certificates
| Specification | Value |
|---|---|
| Low halogen | Yes |
Sustainability
| Specification | Value |
|---|---|
| Sustainability certificates | ENERGY STAR, EPEAT, TCO |
| Sustainable technologies and materials | Bulk packaging available; Molded paper pulp cushion inside box is made of 100% recycled or certified sources; At least 10% ITE-derived closed loop plastic; 80 Plus Platinum power supplies available; At least 60% post-consumer recycled plastic; Outside box and corrugated cushions are made of 100% rec |
| Sustainability compliance | Yes |
Other features
| Specification | Value |
|---|---|
| UNSPSC-code | 43211515 |
