dc73 Blade Workstation Client
Model dc73 Blade Workstation ClientPart no. KD109AWEAN 883585817481
86 specifications
- ProcessorIntel® Itanium®
- Memory0.5 GB
- GraphicsNVIDIA® Quadro® NVS 290
- TypePC
- Weight8.5 kg
- Processor manufacturerIntel
Overview
- Processor
- Intel® Itanium®
- Memory
- 0.5 GB
- Graphics
- NVIDIA® Quadro® NVS 290
- Type
- PC
- Weight
- 8.5 kg
- Processor manufacturer
- Intel
- Brand
- HP
- Category
- PCs/Workstations
- Model
- dc73 Blade Workstation Client
- Part numbers
- KD109AW, KD109AW#ABH
- EAN / UPC
- 883585817481, 883585610075, 883585610082, 883585610099 +16 more
- Also known as
- HP dc73 Blade Workstation Client Intel® Itanium® E2160 0.5 GB DDR2-SDRAM NVIDIA® Quadro® NVS 290 PC
Specifications
86 specifications in 19 groups
Processor
| Specification | Value |
|---|---|
| Processor manufacturer | Intel |
| Processor family | Intel® Itanium® |
| Processor model | E2160 |
| Processor cores | 2 |
| Processor threads | 2 |
| Processor frequency | 1.8 GHz |
| Processor cache | 1 MB |
| Processor cache type | L2 |
| Processor front side bus | 800 MHz |
| Bus type | FSB |
| FSB Parity | No |
| Processor lithography | 65 nm |
| Processor operating modes | 64-bit |
| Processor series | Intel Pentium E2000 Series for Desktop |
| Processor codename | Conroe |
| Thermal Design Power (TDP) | 65 W |
| Tcase | 73.3 °C |
| Number of processors installed | 1 |
| Processor socket | LGA 775 (Socket T) |
| Number of Processing Die Transistors | 105 M |
| Processing Die size | 77 mm² |
| CPU multiplier (bus/core ratio) | 9 |
| Stepping | M0 |
| ECC supported by processor | No |
Memory
| Specification | Value |
|---|---|
| Internal memory | 0.5 GB |
| Internal memory type | DDR2-SDRAM |
| Minimum RAM | 512 MB |
Storage
| Specification | Value |
|---|---|
| Storage drive type | 512 MB SATA Flash Disk-On-Memory |
Graphics
| Specification | Value |
|---|---|
| Discrete graphics card model | NVIDIA® Quadro® NVS 290 |
| Video card features | NVIDIA Quadro 290 NVS 256 MB PCIe x 1 or 16 dual display |
Performance
| Specification | Value |
|---|---|
| Product type | PC |
Network
| Specification | Value |
|---|---|
| Networking features | Intel 82566DM Gigabit Network Connection (integrated on system board) |
Ports & interfaces
| Specification | Value |
|---|---|
| I/O ports | USB (2 front, 6 rear); headphone; microphone; two PS/2; RJ-45; audio in/out |
| Rear ports note | 6 USB 2.0; 1 line-in; 1 line-out |
Expansion slots
| Specification | Value |
|---|---|
| Expansion slots | 1 low profile PCI slot, 2 low profile PCI Express x1 slot, 1 low profile PCI Express x16 slot |
Power
| Specification | Value |
|---|---|
| Power supply type | 240W 80 PLUS power supply - Active PFC |
| Power requirements | 240W 80 PLUS power supply – Active PFC |
Design
| Specification | Value |
|---|---|
| Country of origin | China |
Software
| Specification | Value |
|---|---|
| Bundled software | HP Remote Graphics Software (Receiver); HP Session Allocation Manager Connection Client; Altiris Deployment Solution Agent |
Processor special features
| Specification | Value |
|---|---|
| Embedded options available | Yes |
| Enhanced Intel SpeedStep Technology | Yes |
| Execute Disable Bit | Yes |
| Idle States | Yes |
| Intel 64 | Yes |
| Intel Clear Video Technology | No |
| Intel Demand Based Switching | No |
| Intel Dual Display Capable Technology | No |
| Intel Enhanced Halt State | Yes |
| Intel FDI Technology | No |
| Intel Fast Memory Access | No |
| Intel Flex Memory Access | No |
| Intel Rapid Storage Technology | No |
| Intel Trusted Execution Technology | No |
| Intel VT-x with Extended Page Tables (EPT) | No |
| Intel Virtualization Technology (VT-x) | No |
| Intel Virtualization Technology for Directed I/O (VT-d) | No |
| Intel® AES New Instructions (Intel® AES-NI) | No |
| Intel® Clear Video HD Technology (Intel® CVT HD) | No |
| Intel® Clear Video Technology for Mobile Internet Devices (Intel CVT for MID) | No |
| Intel® InTru™ 3D Technology | No |
| Intel® Insider™ | No |
| Intel® Wireless Display (Intel® WiDi) | No |
| Processor ARK ID | 29739 |
| Processor code | SLA8Z |
| Processor package size | 37.5 x 37.5 mm |
| Thermal Monitoring Technologies | Yes |
| Intel® Turbo Boost Technology | No |
| Intel® Hyper Threading Technology (Intel® HT Technology) | No |
| Intel® Quick Sync Video Technology | No |
| Intel® My WiFi Technology (Intel® MWT) | No |
| Intel® Anti-Theft Technology (Intel® AT) | No |
| Conflict-Free processor | No |
Audio
| Specification | Value |
|---|---|
| Audio included | Integrated High Definition audio with ADI1884 codec (all ports are stereo), Microphone and Headphone front ports, Line-out and Line-In rear ports, Multistreaming capable, Internal Speaker |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 10 - 35 °C |
| Storage temperature (T-T) | -30 - 60 °C |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 337.8 mm |
| Depth | 378.5 mm |
| Height | 100.3 mm |
| Weight | 8.5 kg |
| Size (imperial) | 10 cm (3.95") |
| Weight (imperial) | 8.5 kg (18.8 lbs) |
Keyboard
| Specification | Value |
|---|---|
| Pointing device | USB 2-button optical scroll mouse |
| Keyboard type | USB standard keyboard |
Multimedia
| Specification | Value |
|---|---|
| Multimedia | Integrated high definition with Realtek 4-channel ADI1884 codec |
Features
| Specification | Value |
|---|---|
| Security management description | Power-On Password (via BIOS); Setup Password (via BIOS) |
Other features
| Specification | Value |
|---|---|
| Drive bays | 1 - 3.5-in; 1 – 5.25-in 1 – 3.5-in |
