Compaq dx2420 Microtower PC
Model Compaq dx2420 Microtower PCPart no. VC485EAEAN 884962210291
109 specifications
- ProcessorIntel® Celeron®
- Memory1 GB
- Storage160 GB
- GraphicsIntel® GMA 3100
- TypePC
- OSWindows Vista Home Basic
Overview
- Processor
- Intel® Celeron®
- Memory
- 1 GB
- Storage
- 160 GB
- Graphics
- Intel® GMA 3100
- Type
- PC
- OS
- Windows Vista Home Basic
- Brand
- HP
- Category
- PCs/Workstations
- Model
- Compaq dx2420 Microtower PC
- Part numbers
- VC485EA, NN656EA#ABH, NN642EA#ABH, VC467EA, VC466EA, VC482EA#ABH +34 more
- EAN / UPC
- 884962210291, 884962208243, 884962208236, 884962208533 +56 more
- Also known as
- HP Compaq dx2420 Microtower PC Intel® Celeron® 450 1 GB DDR2-SDRAM 160 GB Intel® GMA 3100 Windows Vista Home Basic
Specifications
109 specifications in 17 groups
Processor
| Specification | Value |
|---|---|
| Processor manufacturer | Intel |
| Processor family | Intel® Celeron® |
| Processor model | 450 |
| Processor cores | 1 |
| Processor threads | 1 |
| Processor frequency | 2.2 GHz |
| Processor cache | 0.512 MB |
| Processor cache type | L2 |
| Processor front side bus | 800 MHz |
| Bus type | FSB |
| FSB Parity | No |
| Processor lithography | 65 nm |
| Processor operating modes | 64-bit |
| Processor codename | Conroe |
| Thermal Design Power (TDP) | 35 W |
| Tcase | 60.4 °C |
| Tjunction | 100 °C |
| Number of processors installed | 1 |
| Processor socket | LGA 775 (Socket T) |
| Number of Processing Die Transistors | 105 M |
| Processing Die size | 77 mm² |
| CPU multiplier (bus/core ratio) | 11 |
| Stepping | A1 |
| ECC supported by processor | No |
Memory
| Specification | Value |
|---|---|
| Internal memory | 1 GB |
| Maximum internal memory | 4 GB |
| Internal memory type | DDR2-SDRAM |
| Memory layout (slots x size) | 1 x 1 GB |
| Memory slots | 2x DIMM |
| Memory clock speed | 800 MHz |
Storage
| Specification | Value |
|---|---|
| Total storage capacity | 160 GB |
| Optical drive type | DVD-ROM |
| HDD interface | SATA |
| HDD speed | 7200 RPM |
| Card reader integrated | No |
| Storage drive controller | SATA 3-Gb/s NCQ SMART IV |
Graphics
| Specification | Value |
|---|---|
| Discrete graphics card model | Intel® GMA 3100 |
| Maximum graphics card memory | 0.256 GB |
| Graphics card family | Intel |
Performance
| Specification | Value |
|---|---|
| Product type | PC |
Optical drive
| Specification | Value |
|---|---|
| CD read speed | 48x |
Network
| Specification | Value |
|---|---|
| Networking features | Realtek 8101E-GR GbE Ethernet |
Ports & interfaces
| Specification | Value |
|---|---|
| USB 2.0 ports quantity | 6 |
| Ethernet LAN (RJ-45) ports | 1 |
| Headphone outputs | 1 |
| Line-out | Yes |
| Line-in | Yes |
| Microphone in | Yes |
| VGA (D-Sub) ports quantity | 1 |
| PS/2 ports quantity | 2 |
| Serial ports quantity | 0 |
| Parallel ports quantity | 0 |
Expansion slots
| Specification | Value |
|---|---|
| PCI Express x1 slots | 2 |
| PCI Express x16 slots | 1 |
| Expansion slots | 1 x PCI |
Power
| Specification | Value |
|---|---|
| Power requirements | 90 – 264 V / 100 – 240 V, 50/60 Hz, 47 – 63 Hz |
| Power consumption (typical) | 300 W |
Design
| Specification | Value |
|---|---|
| Chassis type | Micro Tower |
| External drive bays | 2 x 5.25”, 1 x 3.5” |
| Internal drive bays | 2 x 3.5” |
| Country of origin | China |
Software
| Specification | Value |
|---|---|
| Operating system installed | Windows Vista Home Basic |
Display
| Specification | Value |
|---|---|
| Display included | No |
Processor special features
| Specification | Value |
|---|---|
| Embedded options available | No |
| Enhanced Intel SpeedStep Technology | No |
| Execute Disable Bit | Yes |
| Idle States | Yes |
| Intel 64 | Yes |
| Intel Clear Video Technology | No |
| Intel Demand Based Switching | No |
| Intel Dual Display Capable Technology | No |
| Intel Enhanced Halt State | Yes |
| Intel FDI Technology | No |
| Intel Fast Memory Access | No |
| Intel Flex Memory Access | No |
| Intel Rapid Storage Technology | No |
| Intel Trusted Execution Technology | No |
| Intel VT-x with Extended Page Tables (EPT) | No |
| Intel Virtualization Technology (VT-x) | No |
| Intel Virtualization Technology for Directed I/O (VT-d) | No |
| Intel® AES New Instructions (Intel® AES-NI) | No |
| Intel® Clear Video HD Technology (Intel® CVT HD) | No |
| Intel® Clear Video Technology for Mobile Internet Devices (Intel CVT for MID) | No |
| Intel® InTru™ 3D Technology | No |
| Intel® Insider™ | No |
| Intel® Wireless Display (Intel® WiDi) | No |
| Physical Address Extension (PAE) | 32 bit |
| Physical Address Extension (PAE) | Yes |
| Processor ARK ID | 35239 |
| Processor code | SLAFZ |
| Processor package size | 37.5 mm |
| Thermal Monitoring Technologies | Yes |
| Intel® Turbo Boost Technology | No |
| Intel® Hyper Threading Technology (Intel® HT Technology) | No |
| Intel® Quick Sync Video Technology | No |
| Intel® My WiFi Technology (Intel® MWT) | No |
| Intel® Anti-Theft Technology (Intel® AT) | No |
| Conflict-Free processor | No |
Audio
| Specification | Value |
|---|---|
| Audio system direct 3D sound | Yes |
| Audio system | Realtek ALC662 HD |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 10 - 35 °C |
| Storage temperature (T-T) | -30 - 60 °C |
| Operating relative humidity (H-H) | 10 - 90% |
| Storage relative humidity (H-H) | 5 - 95% |
| Non-operating altitude | 9000 |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 165 mm |
| Depth | 373 mm |
| Height | 365 mm |
| Weight | 10.2 kg |
