-RW WXP Pro Microtower PC

Model Compaq dx2200 P4 630 HT 512M/160G DVD+/-RW WXP Pro Microtower PCPart no. EU282ET#ABH

116 specifications

ProcessorIntel® Pentium® 4
Memory0.5 GB
Storage160 GB
GraphicsAMD Radeon X300
TypePC
OSWindows XP Professional

See all specifications

Overview

Processor: Intel® Pentium® 4
Memory: 0.5 GB
Storage: 160 GB
Graphics: AMD Radeon X300
Type: PC
OS: Windows XP Professional

Brand: HP
Category: PCs/Workstations
Model: Compaq dx2200 P4 630 HT 512M/160G DVD+/-RW WXP Pro Microtower PC
Part number: EU282ET#ABH
Also known as: HP Compaq dx2200 P4 630 HT 512M/160G DVD+/-RW WXP Pro Microtower PC Intel® Pentium® 4 0.5 GB DDR2-SDRAM 160 GB AMD Radeon X300 Windows XP Professional

Specifications

116 specifications in 18 groups

Processor

Specification	Value
Processor manufacturer	Intel
Processor family	Intel® Pentium® 4
Processor model	630
Processor cores	1
Processor threads	2
Processor frequency	3 GHz
Processor cache	2 MB
Processor cache type	L2
Processor front side bus	800 MHz
Bus type	FSB
FSB Parity	No
Processor lithography	90 nm
Processor operating modes	64-bit
Processor series	Intel Pentium 4 600 Series supporting Hyper-Threading Technology
Processor codename	Prescott
Thermal Design Power (TDP)	84 W
Tcase	66.6 °C
Processor socket	LGA 775 (Socket T)
Number of Processing Die Transistors	169 M
Processing Die size	135 mm²
CPU multiplier (bus/core ratio)	15
ECC supported by processor	No
Cache external	2048 KB

Memory

Specification	Value
Internal memory	0.5 GB
Maximum internal memory	2 GB
Internal memory type	DDR2-SDRAM
Memory slots	2x DIMM
Memory upgrade	2 GB

Storage

Specification	Value
Total storage capacity	160 GB
Optical drive type	DVD±RW
HDD interface	SATA
HDD speed	7200 RPM
Storage drive controller	Serial ATA 3.0 Gb/s
Disk subsystem controller	Serial ATA 1.5
Diskette drive	Optional N
Storage drive type	160 GB

Graphics

Specification	Value
Discrete graphics card model	AMD Radeon X300
Maximum graphics card memory	0.128 GB
Video adapter resolution	2048 x 1536 @ 32 bpp
Video card features	ATI RADEON X1300 256MB full-height PCIe Card Supports resolutions up to 2048 x 1536 @ 32 bpp
Video adapter, bus	PCI Express x16
Video card resolution	Supports resolutions up to 2048 x 1536 @ 32 bpp

Performance

Specification	Value
Product type	PC
Acoustic power emissions	IDLE: LWAd = 4.3 Bels; FIXED DISK: LWAd = 4.8 Bels; CD-ROM: LWAd = 5.0 Bels

Network

Specification	Value
Modem type	No
Networking features	Fast Ethernet
Networking speed	10/100 Mbps Base-TX

Ports & interfaces

Specification	Value
USB 2.0 ports quantity	6
Ethernet LAN (RJ-45) ports	1
Headphone outputs	1
Microphone in	Yes
VGA (D-Sub) ports quantity	1
PS/2 ports quantity	2
Serial ports quantity	1
Parallel ports quantity	1
I/O ports	Rear: 4 USB 2.0 ports, 1 serial port, 1 parallel port, 2 PS/2, 1 RJ-45, 1 VGA, 1 audio in, 1 audio out, 1 MIC; Front: 2 USB 2.0

Expansion slots

Specification	Value
Expansion slots	2x PCI 2.3 (FH) 1x PCI Express x1 (FH) 1x PCI-Express x16 (FH)

Power

Specification	Value
Power supply type	ATX
Power requirements	90 – 140 / 180 – 264 VAC, 50/60 Hz
Power consumption (typical)	250 W
Power availability	250 W

Design

Specification	Value
Chassis type	Micro Tower
External drive bays	2x 5.25" 1x 3.5"
Internal drive bays	2x 3.5"
Country of origin	China

Software

Specification	Value
Operating system installed	Windows XP Professional
Bundled software	Roxio DigitalMedia Plus Roxio CinePlayer Dantz Retrospect Express 7 Sun Java Runtime Environment
Driver LAN	Integrated Realtek 8100C Fast Ethernet Network Controller 10/100

Display

Specification	Value
Display included	No

Processor special features

Specification	Value
Embedded options available	No
Enhanced Intel SpeedStep Technology	Yes
Execute Disable Bit	Yes
Idle States	No
Intel 64	Yes
Intel Clear Video Technology	No
Intel Demand Based Switching	No
Intel Dual Display Capable Technology	No
Intel Enhanced Halt State	No
Intel FDI Technology	No
Intel Fast Memory Access	No
Intel Flex Memory Access	No
Intel Rapid Storage Technology	No
Intel Trusted Execution Technology	No
Intel VT-x with Extended Page Tables (EPT)	No
Intel Virtualization Technology (VT-x)	No
Intel Virtualization Technology for Directed I/O (VT-d)	No
Intel® AES New Instructions (Intel® AES-NI)	No
Intel® Clear Video HD Technology (Intel® CVT HD)	No
Intel® Clear Video Technology for Mobile Internet Devices (Intel CVT for MID)	No
Intel® InTru™ 3D Technology	No
Intel® Insider™	No
Intel® Wireless Display (Intel® WiDi)	No
Processor ARK ID	27478
Processor package size	37.5 x 37.5 mm
Thermal Monitoring Technologies	No
Intel® Turbo Boost Technology	No
Intel® Hyper Threading Technology (Intel® HT Technology)	Yes
Intel® Quick Sync Video Technology	No
Intel® My WiFi Technology (Intel® MWT)	No
Intel® Anti-Theft Technology (Intel® AT)	No
Conflict-Free processor	No

Audio

Specification	Value
Audio system	Realtek ALC861 HDA
Audio included	Realtek ALC861 High Definition audio codec, 3D audio compliant with AC'97 rev. 2.3 and HD Audio compatible

Operational conditions

Specification	Value
Operating temperature (T-T)	10 - 35 °C
Storage temperature (T-T)	-30 - 60 °C
Operating relative humidity (H-H)	10 - 90%
Storage relative humidity (H-H)	10 - 95%
Relative humidity	10 - 90%
Non-operating relative humidity (non-condensing)	10 - 95%

Weight & dimensions

Specification	Value
Width	175 mm
Depth	416 mm
Height	353 mm
Weight	9.6 kg

Keyboard

Specification	Value
Pointing device	USB optical mouse PS/2 2-Button scroll mouse, USB 2-Button optical scroll mouse or USB 2-Button scroll mouse
Keyboard type	2004 standard PS/2 HP PS/2 or USB Standard Keyboard

Other features

Specification	Value
Drive bays	2 internal 3.5 inch 2 external 5.25 inch and 1 external 3.5 inch
