HP Compaq dx2200 Minitower PC
Model Compaq dx2200 Minitower PCPart no. BEU376ET1AB
101 specifications
- Display43.2 cm (17")
- Resolution1280 x 1024 pixels
- ProcessorIntel® Pentium® 4
- Memory1 GB
- Storage160 GB
- GraphicsAMD Radeon Xpress 200
Overview
- Display
- 43.2 cm (17")
- Resolution
- 1280 x 1024 pixels
- Processor
- Intel® Pentium® 4
- Memory
- 1 GB
- Storage
- 160 GB
- Graphics
- AMD Radeon Xpress 200
- Brand
- HP
- Category
- PCs/Workstations
- Model
- Compaq dx2200 Minitower PC
- Part number
- BEU376ET1AB
- Also known as
- HP Compaq dx2200 Minitower PC Intel® Pentium® 4 651 1 GB DDR2-SDRAM 160 GB AMD Radeon Xpress 200 Windows XP Professional
Specifications
101 specifications in 16 groups
Processor
| Specification | Value |
|---|---|
| Processor manufacturer | Intel |
| Processor family | Intel® Pentium® 4 |
| Processor model | 651 |
| Processor cores | 1 |
| Processor threads | 2 |
| Processor frequency | 3.4 GHz |
| Processor cache | 2 MB |
| Processor cache type | L2 |
| Processor front side bus | 800 MHz |
| Bus type | FSB |
| FSB Parity | No |
| Processor lithography | 65 nm |
| Processor operating modes | 64-bit |
| Processor series | Intel Pentium 4 600 Series supporting Hyper-Threading Technology |
| Processor codename | Cedarmill |
| Thermal Design Power (TDP) | 80, 86 |
| Scenario Design Power (SDP) | 0 W |
| Tcase | 69.2 °C |
| Processor socket | LGA 775 (Socket T) |
| Number of Processing Die Transistors | 188 M |
| Processing Die size | 81 mm² |
| CPU multiplier (bus/core ratio) | 17 |
| Stepping | C1 |
| ECC supported by processor | No |
| Processor technology | Hyper-Threading |
Memory
| Specification | Value |
|---|---|
| Internal memory | 1 GB |
| Maximum internal memory | 2 GB |
| Internal memory type | DDR2-SDRAM |
| Memory layout (slots x size) | 2 x 0.5 GB |
| Memory slots | 2x DIMM |
Storage
| Specification | Value |
|---|---|
| Total storage capacity | 160 GB |
| Optical drive type | DVD±RW |
| HDD interface | SATA |
| HDD speed | 7200 RPM |
| Storage drive controller | SATA 3.0 Gb/s |
Graphics
| Specification | Value |
|---|---|
| Discrete graphics card model | AMD Radeon Xpress 200 |
| Video adapter, bus | PCI Express x16 |
Performance
| Specification | Value |
|---|---|
| Product type | PC |
Optical drive
| Specification | Value |
|---|---|
| LightScribe | Yes |
Network
| Specification | Value |
|---|---|
| Networking features | Ethernet/Fast Ethernet |
Ports & interfaces
| Specification | Value |
|---|---|
| USB 2.0 ports quantity | 6 |
| Ethernet LAN (RJ-45) ports | 1 |
| Line-out | Yes |
| Line-in | Yes |
| Microphone in | Yes |
| VGA (D-Sub) ports quantity | 1 |
| PS/2 ports quantity | 2 |
| Serial ports quantity | 1 |
| Parallel ports quantity | 1 |
Expansion slots
| Specification | Value |
|---|---|
| Expansion slots | 2 x full-height PCI 2.3 1 x full-height PCI Express x1 1 x full-height PCI-Express x16 |
Design
| Specification | Value |
|---|---|
| Chassis type | Mini Tower |
| Country of origin | China |
Software
| Specification | Value |
|---|---|
| Operating system installed | Windows XP Professional |
| Bundled software | Roxio DigitalMedia Plus (by SONIC), Roxio CinePlayer, Dantz Retrospect Express 7, Sun Java Runtime Environment, Norton Antivirus 2005, ABILITY PRO |
Display
| Specification | Value |
|---|---|
| Display included | Yes |
| Display diagonal | 43.2 cm (17") |
| Display resolution | 1280 x 1024 pixels |
Processor special features
| Specification | Value |
|---|---|
| Embedded options available | Yes |
| Enhanced Intel SpeedStep Technology | Yes |
| Execute Disable Bit | Yes |
| Idle States | Yes |
| Intel 64 | Yes |
| Intel Clear Video Technology | No |
| Intel Demand Based Switching | No |
| Intel Dual Display Capable Technology | No |
| Intel Enhanced Halt State | Yes |
| Intel FDI Technology | No |
| Intel Fast Memory Access | No |
| Intel Flex Memory Access | No |
| Intel Rapid Storage Technology | No |
| Intel Trusted Execution Technology | No |
| Intel VT-x with Extended Page Tables (EPT) | No |
| Intel Virtualization Technology (VT-x) | No |
| Intel Virtualization Technology for Directed I/O (VT-d) | No |
| Intel® AES New Instructions (Intel® AES-NI) | No |
| Intel® Clear Video HD Technology (Intel® CVT HD) | No |
| Intel® Clear Video Technology for Mobile Internet Devices (Intel CVT for MID) | No |
| Intel® InTru™ 3D Technology | No |
| Intel® Insider™ | No |
| Intel® Wireless Display (Intel® WiDi) | No |
| Physical Address Extension (PAE) | 32 bit |
| Physical Address Extension (PAE) | Yes |
| Processor ARK ID | 27483 |
| Processor code | SL96J |
| Processor package size | 37.5 x 37.5 mm |
| Thermal Monitoring Technologies | Yes |
| Intel® Turbo Boost Technology | No |
| Intel® Hyper Threading Technology (Intel® HT Technology) | Yes |
| Intel® Quick Sync Video Technology | No |
| Intel® My WiFi Technology (Intel® MWT) | No |
| Intel® Anti-Theft Technology (Intel® AT) | No |
| Conflict-Free processor | No |
Audio
| Specification | Value |
|---|---|
| Audio system | Realtek ALC861 High Definition audio codec |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 10 - 35 °C |
| Operating relative humidity (H-H) | 10 - 90% |
| Relative humidity | 10 - 90% |
| Non-operating relative humidity (non-condensing) | 10 - 95% |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 175 mm |
| Depth | 416 mm |
| Height | 353 mm |
| Weight | 9.6 kg |
