HP Compaq dc5850 AMD Athlon Dual-Core 4450B 1G/160G DVD-ROM WVST Bus Small Form Factor PC

Model Compaq dc5850 AMD Athlon Dual-Core 4450B 1G/160G DVD-ROM WVST Bus Small Form Factor PCPart no. AL194AW#ABH

75 specifications

ProcessorAMD Athlon
Memory1 GB
Storage160 GB
GraphicsAMD Radeon HD 3100
TypePC
OSWindows Vista Business

See all specifications

Overview

Processor: AMD Athlon
Memory: 1 GB
Storage: 160 GB
Graphics: AMD Radeon HD 3100
Type: PC
OS: Windows Vista Business

Brand: HP
Category: PCs/Workstations
Model: Compaq dc5850 AMD Athlon Dual-Core 4450B 1G/160G DVD-ROM WVST Bus Small Form Factor PC
Part number: AL194AW#ABH
Also known as: HP Compaq dc5850 AMD Athlon Dual-Core 4450B 1G/160G DVD-ROM WVST Bus Small Form Factor PC 1 GB DDR2-SDRAM 160 GB AMD Radeon HD 3100 Windows Vista Business

Specifications

75 specifications in 18 groups

Processor

Specification	Value
Processor manufacturer	AMD
Processor family	AMD Athlon
Processor model	4450B
Processor frequency	2.3 GHz
Processor cache	1 MB
Processor cache type	L2

Memory

Specification	Value
Internal memory	1 GB
Maximum internal memory	8 GB
Internal memory type	DDR2-SDRAM
Memory clock speed	800 MHz
Minimum RAM	512 MB

Storage

Specification	Value
Total storage capacity	160 GB
Optical drive type	DVD-ROM
HDD speed	7200 RPM
Card reader integrated	No
Storage drive controller	SATA 3.0Gb/s NCQ SMART IV
Disk subsystem controller	SATA 3.0Gb/s NCQ SMART IV
Diskette drive	Optional
Storage drive type	160 GB

Graphics

Specification	Value
Discrete graphics card model	AMD Radeon HD 3100
Maximum graphics card memory	0.256 GB
Video card features	3D/2D Controller: support is fully compliant with Microsoft standard API such as Microsoft DirectX10, DirectXVA, VMR9, GDI/GDI+; OpenGL 2.0 1.4.; Integrated VGA Controller; integrated 350 MHz RAMDAC; 400 MHz Controller Clock Speed; Overlay Planes: Single overlay support with 5x3 filtering; Maximum C
Video adapter, bus	PCI Express x16
Video card resolution	Maximum Vertical Refresh Rate: 85 Hz at up to 1920x1440, 75 Hz at 2048x1536

Performance

Specification	Value
Product type	PC
Motherboard chipset	AMD 780V
Acoustic power emissions	IDLE (Fixed disk drive spinning): LWAd = 3.8 Bels; FIXED DISK (Random write): LWAd = 3.9 Bels; OPTICAL DRIVE (Sequential Reads): LWAd = 5.2 Bels

Network

Specification	Value
Networking features	Gigabit Ethernet

Ports & interfaces

Specification	Value
USB 2.0 ports quantity	8
Ethernet LAN (RJ-45) ports	1
Headphone outputs	1
Microphone in	Yes
VGA (D-Sub) ports quantity	1
DVI port	Yes
PS/2 ports quantity	2
Serial ports quantity	1
Parallel ports quantity	0
I/O ports	Rear: 6 USB 2.0, 1 serial port, 1 optional serial port, 1 optional parallel port, 2 PS/2, 1 RJ-45, 1 VGA, 1 DVI-D, audio in/out; Front: 2 USB 2.0, audio ports
Rear ports note	6 USB 2.0; 2 PS/2; 1 serial; 1 serial (optional 2nd); 1 parallel (optional); 1 audio out; 1 audio in; 1 RJ-45; 1 DVI-D

Expansion slots

Specification	Value
PCI Express x1 slots	2
PCI Express x16 slots	1
Expansion slots	1 x PCI

Power

Specification	Value
Power requirements	90 – 264 / 100 – 240 VAC, 50/60 Hz, 47 – 63 Hz
Power consumption (typical)	240 W
Power management	Operating Voltage Range: 90 – 264 VAC; Rated Voltage Range: 100 – 240 VAC; Rated Line Frequency: 50/60 Hz; Operating Line Frequency Range: 47 – 63 Hz; Rated Input Current 80 Plus: 1.7 A; Current Leakage (NFPA 99): < 275 µA; System Heat Dissipation 80 Plus: Typical 315 btu/hr (79 kg-cal/hr), Maximum

Design

Specification	Value
Cable lock slot	Yes
Cable lock slot type	Kensington
External drive bays	1 x 5.25", 1 x 3.5"
Internal drive bays	1 x 3.5"
Country of origin	China
Upgrade type	Windows Vista capable

Software

Specification	Value
Operating system installed	Windows Vista Business
Applications supported	Windows Vista Premium ready
Compatible operating systems	FreeDOS
Bundled software	On some models only (not included with FreeDOS): HP ProtectTools Security Solutions, HP Backup and Recovery Manager, HP Insight Diagnostics (available via HP Backup and Recovery Manager), HP Software Agent, HP Total Care Advisor, HP Client Configuration Manager, HP Client Manager for Altiris, HP Sof
Driver LAN	Microsoft Windows XP, Microsoft Windows Vista, FreeDos, Linux

Display

Specification	Value
Display included	No

Audio

Specification	Value
Audio system	HD
Audio included	Integrated High Definition audio with ADI1884 codec, microphone and headphone front ports, line-out and line-in rear ports, multistreaming capable, internal PC speaker

Operational conditions

Specification	Value
Operating temperature (T-T)	10 - 35 °C
Storage temperature (T-T)	-30 - 60 °C
Operating relative humidity (H-H)	10 - 90%
Storage relative humidity (H-H)	5 - 95%
Relative humidity	10 - 90%
Non-operating altitude	9144
Non-operating relative humidity (non-condensing)	5 - 90%

Weight & dimensions

Specification	Value
Width	337 mm
Depth	378 mm
Height	100 mm
Weight	7.6 kg

Keyboard

Specification	Value
Pointing device	HP PS/2 2-Button Optical Scroll Mouse
Keyboard type	HP PS/2

Features

Specification	Value
Security management description	Integrated 1.2 TPM Embedded Security Chip (except for Russia), HP Business PC Security Lock, HP USB Biometric Fingerprint Reader

Other features

Specification	Value
Security features	Kensington Lock
Drive bays	1 external 5.25 inch, 1 external 3.5 inch 1 internal 3.5 inch
