HP 12M31EA#UUG PC/workstation Intel® Core™ i7 i7-10700
HP

12M31EA#UUG PC/workstation Intel® Core™ i7 i7-10700

16 GB DDR4-SDRAM 512 GB SSD NVIDIA® Quadro® P620 Windows 10 Pro Tower Black

Model 12M31EA#UUG

136 specifications
  • ProcessorIntel® Core™ i7
  • Memory16 GB
  • Storage512 GB
  • GraphicsNVIDIA® Quadro® P620
  • TypeWorkstation
  • OSWindows 10 Pro
See all specifications

Overview

Processor
Intel® Core™ i7
Memory
16 GB
Storage
512 GB
Graphics
NVIDIA® Quadro® P620
Type
Workstation
OS
Windows 10 Pro
Brand
HP
Model
12M31EA#UUG
Part number
12M31EA#UUG
Also known as
HP 12M31EA#UUG PC/workstation Intel® Core™ i7 i7-10700 16 GB DDR4-SDRAM 512 GB SSD NVIDIA® Quadro® P620 Windows 10 Pro Tower Black

Specifications

136 specifications in 18 groups

Processor

Processor manufacturerIntel
Processor familyIntel® Core™ i7
Processor generation10th gen Intel® Core™ i7
Processor modeli7-10700
Processor cores8
Processor threads16
Processor boost frequency4.8 GHz
Processor frequency2.9 GHz
Processor cache16 MB
Processor cache typeL3
System bus rate8 GT/s
Processor lithography14 nm
Processor operating modes64-bit
Processor codenameComet Lake
Thermal Design Power (TDP)35 W
Configurable TDP-down25 W
Configurable TDP-down frequency1.3 GHz
Tjunction100 °C
Maximum number of PCI Express lanes16
PCI Express configurations1x16, 2x8, 1x8+2x4
PCI Express slots version3.0
Number of processors installed1
Processor socketLGA 1200 (Socket H5)
Maximum internal memory supported by processor128 GB
Memory types supported by processorDDR4-SDRAM
Memory clock speeds supported by processor2933 MHz
Memory bandwidth supported by processor (max)45.8 GB/s

Memory

Internal memory16 GB
Maximum internal memory128 GB
Internal memory typeDDR4-SDRAM
Memory layout (slots x size)2 x 8 GB
Memory slots2x DIMM
Memory clock speed2666 MHz
ECCNo

Storage

Total storage capacity512 GB
Storage mediaSSD
Total SSDs capacity512 GB
Number of SSDs installed1
SSD capacity512 GB
NVMeYes
SSD form factorM.2

Graphics

Discrete graphics cardYes
On-board graphics cardYes
Discrete GPU manufacturerNVIDIA
Discrete graphics card modelNVIDIA® Quadro® P620
Discrete graphics card memory2 GB
Discrete graphics memory typeGDDR5
On-board GPU manufacturerIntel
On-board graphics card modelIntel® UHD Graphics 630
Maximum on-board graphics card memory64 GB
Number of displays supported (on-board graphics)3
On-board graphics card base frequency350 MHz
On-board graphics card dynamic frequency (max)1200 MHz
On-board graphics card DirectX version12.0
On-board graphics card ID0x9BC5
On-board graphics card OpenGL version4.5
Graphics card interfacePCIe x16

Performance

Product typeWorkstation
Market positioningPerformance
Motherboard chipsetIntel Q470
Password protectionYes
Password protection typePower on

Network

Ethernet LANYes
Ethernet LAN data rates10,100,1000 Mbit/s
Cabling technology10/100/1000Base-T(X)
Wi-FiNo

Ports & interfaces

USB 2.0 ports quantity2
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity4
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity0
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity4
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity1
Thunderbolt 3 ports quantity0
DisplayPorts quantity2
HDMI ports quantity0
Ethernet LAN (RJ-45) ports1
Combo headphone/mic portYes
Headphone outputs1
Line-outYes
Line-inYes
Microphone inNo
DVI portNo

Expansion slots

PCI Express x1 slots2
PCI Express x16 slots2

Design

Chassis typeTower
Placement supportedVertical
Product colourBlack

Software

Operating system installedWindows 10 Pro
Operating system architecture64-bit
Drivers includedYes

Display

Display includedNo

Processor special features

CPU configuration (max)1
Embedded options availableNo
Enhanced Intel SpeedStep TechnologyYes
Execute Disable BitYes
Idle StatesYes
Intel 64Yes
Intel Clear Video TechnologyYes
Intel Software Guard Extensions (Intel SGX)Yes
Intel Stable Image Platform Program (SIPP)Yes
Intel Trusted Execution TechnologyYes
Intel VT-x with Extended Page Tables (EPT)Yes
Intel Virtualization Technology (VT-x)Yes
Intel Virtualization Technology for Directed I/O (VT-d)Yes
Intel® AES New Instructions (Intel® AES-NI)Yes
Intel® Clear Video HD Technology (Intel® CVT HD)Yes
Intel® InTru™ 3D TechnologyYes
Intel® OS GuardYes
Intel® Secure KeyYes
Processor ARK ID199314
Processor package size37.5 x 37.5 mm
Scalability1S
Supported instruction setsSSE4.1, SSE4.2, AVX 2.0
Thermal Monitoring TechnologiesYes
Thermal solution specificationPCG 2015B
Intel® Turbo Boost Technology2.0
Intel® Hyper Threading Technology (Intel® HT Technology)Yes
Intel® Quick Sync Video TechnologyYes
Intel® Identity Protection Technology (Intel® IPT)Yes

Brand-specific features

HP JumpStartYes
HP Support AssistantYes
HP Security toolsHP Secure Erase; HP Sure Click; HP Sure Sense; HP Sure Start Gen6; HP Sure Run Gen3; HP Sure Recover Gen3; HP DriveLock and Automatic DriveLock; HP BIOSphere Gen6; HP Client Security Manager Gen6
HP Management toolsHP Client Catalog; HP Cloud Recovery; HP Driver Packs; HP Management Integration Kit for Microsoft System Center Configuration Management Gen4; HP System Software Manager; HP Image Assistant Gen5; HP BIOS Configuration Utility
HP Software providedHP Noise Cancellation Software; HP Privacy Settings; HP Desktop Support Utilities
HP segmentBusiness

Audio

Audio chipConexant CX20632

Weight & dimensions

Width370 mm
Depth308 mm
Height168 mm
Weight9.86 kg

Packaging data

Package width299 mm
Package depth478 mm
Package height517 mm
Package weight11.3 kg

Packaging content

Mouse includedYes
Keyboard includedYes

Keyboard

Keyboard typeUSB
