Fujitsu ESPRIMO Q900 Intel® Core™ i5 i5-2520M

4 GB DDR3-SDRAM 500 GB Intel® HD Graphics 3000 Windows 7 Professional Mini PC Black, Grey

Model Q900Part no. VFY:Q0900PF031BEEAN 4051554328412

152 specifications

ProcessorIntel® Core™ i5
Memory4 GB
Storage500 GB
GraphicsIntel® HD Graphics 3000
TypeMini PC
OSWindows 7 Professional

See all specifications

Overview

Processor: Intel® Core™ i5
Memory: 4 GB
Storage: 500 GB
Graphics: Intel® HD Graphics 3000
Type: Mini PC
OS: Windows 7 Professional

Brand: Fujitsu
Category: PCs/Workstations
Model: Q900
Part numbers: VFY:Q0900PF031BE, VFY:Q0900PF041CH, LKN:Q0900P0001FR, VFY:Q0900PP301DE, VFY:Q0900PP3L1NC, VFY:Q0900PP3M1NC +32 more
EAN / UPC: 4051554328412, 4051554330347, 4051554337421, 4051554371333 +22 more
Also known as: Fujitsu ESPRIMO Q900 Intel® Core™ i5 i5-2520M 4 GB DDR3-SDRAM 500 GB Intel® HD Graphics 3000 Windows 7 Professional Mini PC Black, Grey

Specifications

152 specifications in 20 groups

Processor

Specification	Value
Processor manufacturer	Intel
Processor family	Intel® Core™ i5
Processor generation	2nd gen Intel® Core™ i5
Processor model	i5-2520M
Processor cores	2
Processor threads	4
Processor boost frequency	3.2 GHz
Processor frequency	2.5 GHz
Processor cache	3 MB
Processor cache type	Smart Cache
Bus type	DMI
FSB Parity	No
System bus rate	5 GT/s
Processor lithography	32 nm
Processor operating modes	64-bit
Processor series	Intel Core i5-2500 Mobile Series
Processor codename	Sandy Bridge
Thermal Design Power (TDP)	35 W
Tjunction	100 °C
Maximum number of PCI Express lanes	16
PCI Express configurations	1x16, 2x8, 1x8+2x4
PCI Express slots version	2.0
Number of processors installed	1
Processor socket	Socket 988
CPU multiplier (bus/core ratio)	25
Maximum number of SMP processors	1
Stepping	J1
Maximum internal memory supported by processor	16 GB
Memory types supported by processor	DDR3-SDRAM
Memory clock speeds supported by processor	1066,1333 MHz
Memory bandwidth supported by processor (max)	21.3 GB/s
ECC supported by processor	No

Memory

Specification	Value
Internal memory	4 GB
Maximum internal memory	8 GB
Internal memory type	DDR3-SDRAM
Memory layout (slots x size)	2 x 2 GB
Memory slots	2x SO-DIMM
Memory clock speed	1333 MHz
Memory channels	Dual-channel

Storage

Specification	Value
Total storage capacity	500 GB
Optical drive type	DVD Super Multi
Number of HDDs installed	1
HDD capacity	500 GB
HDD interface	SATA II
HDD speed	5400 RPM
HDD size	2.5"
Card reader integrated	No
Floppy drive installed	No

Graphics

Specification	Value
On-board graphics card	Yes
Discrete graphics card model	Intel® HD Graphics 3000
On-board graphics card family	Intel® HD Graphics
On-board graphics card model	Intel® HD Graphics 3000
Number of displays supported (on-board graphics)	2
On-board graphics card base frequency	650 MHz
On-board graphics card dynamic frequency (max)	1300 MHz
On-board graphics card ID	0x116
Graphics card family	Intel
Video adapter features	DirectX 10.1, HDCP, OpenGL 2.1
External video modes resolution (max)	2560 x 1600 pixels

Performance

Specification	Value
Product type	Mini PC
Motherboard chipset	Intel® QM67 Express
Password protection type	BIOS
Audio output channels	5.1 channels

Optical drive

Specification	Value
DVD interface type	SATA

Network

Specification	Value
Ethernet LAN	Yes
Ethernet LAN data rates	10,100,1000 Mbit/s
Cabling technology	10/100/1000Base-T(X)
Wi-Fi	Yes
Bluetooth	Yes
Wake-on-LAN ready	Yes
Networking features	Gigabit Ethernet

Ports & interfaces

Specification	Value
USB 2.0 ports quantity	5
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	2
DisplayPorts quantity	1
HDMI ports quantity	0
Ethernet LAN (RJ-45) ports	1
Headphone outputs	1
Line-in	Yes
Microphone in	Yes
VGA (D-Sub) ports quantity	0
DVI port	Yes
PS/2 ports quantity	0
Firewire (IEEE 1394) ports	0
S/PDIF out port	Yes
Serial ports quantity	0
Parallel ports quantity	0

Power

Specification	Value
Power supply type	AC/DC
Power requirements	AC 100V - 240V@47/63Hz
Power supply	90 W

Design

Specification	Value
Cable lock slot	Yes
Cable lock slot type	Kensington
Product colour	Black, Grey
External drive bays	1x 5.25"
Internal drive bays	1x 2.5"

Software

Specification	Value
Operating system installed	Windows 7 Professional
Operating system architecture	64-bit
Compatible operating systems	Microsoft Windows 7 Home Basic 32-bit, Windows 7 Home Premium 64-bit, Windows 7 Professional 32-bit, Windows Vista, Windows XP
Mac compatibility	No
Drivers included	Yes
Pre-installed software	Nero Essentials XL

Display

Specification	Value
Display included	No

Processor special features

Specification	Value
CPU configuration (max)	1
Embedded options available	No
Enhanced Intel SpeedStep Technology	Yes
Execute Disable Bit	Yes
Graphics & IMC lithography	32 nm
Idle States	Yes
Intel 64	Yes
Intel Clear Video Technology	No
Intel Demand Based Switching	No
Intel Dual Display Capable Technology	Yes
Intel Enhanced Halt State	Yes
Intel FDI Technology	Yes
Intel Fast Memory Access	Yes
Intel Flex Memory Access	Yes
Intel Identity Protection Technology version	1.00
Intel Rapid Storage Technology	No
Intel Trusted Execution Technology	Yes
Intel VT-x with Extended Page Tables (EPT)	Yes
Intel Virtualization Technology (VT-x)	Yes
Intel Virtualization Technology for Directed I/O (VT-d)	Yes
Intel® AES New Instructions (Intel® AES-NI)	Yes
Intel® Clear Video HD Technology (Intel® CVT HD)	Yes
Intel® Clear Video Technology for Mobile Internet Devices (Intel CVT for MID)	No
Intel® InTru™ 3D Technology	Yes
Intel® Insider™	No
Intel® Smart Cache	Yes
Intel® Wireless Display (Intel® WiDi)	Yes
Processor ARK ID	52229
Processor code	SR048
Processor package size	37.5 x 37.5 (rPGA988B); 31 x 24 (BGA1023)
Supported instruction sets	AVX
Thermal Monitoring Technologies	Yes
Intel® Turbo Boost Technology	2.0
Intel® Hyper Threading Technology (Intel® HT Technology)	Yes
Intel® Quick Sync Video Technology	Yes
Intel® My WiFi Technology (Intel® MWT)	Yes
Intel® Identity Protection Technology (Intel® IPT)	Yes
Intel® Anti-Theft Technology (Intel® AT)	Yes
Conflict-Free processor	No
Integrated 4G WiMAX	Yes

Audio

Specification	Value
Audio system	Realtek ALC662

Operational conditions

Specification	Value
Operating temperature (T-T)	5 - 35 °C

Weight & dimensions

Specification	Value
Width	165 mm
Depth	168 mm
Height	57 mm
Weight	1.4 kg

Packaging data

Specification	Value
Package dimensions (WxDxH)	395 x 198 x 284 mm

Packaging content

Specification	Value
Mouse included	Yes

Certificates

Specification	Value
Compliance industry standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab
Certification	CE, EN 60601-1-2, RoHS, WEEE, HCT, HCL entry, WHQL, ENERGY STAR

Other features

Specification	Value
HDD user password	Yes
