Fujitsu P400 + Display L20T-4

Model P400 + Display L20T-4Part no. VFY:P0400PP131BE#*KIT*

164 specifications

Display50.8 cm (20")
Resolution1600 x 900 pixels
ProcessorIntel Pentium G
Memory2 GB
Storage500 GB
GraphicsNot available

See all specifications

Overview

Display: 50.8 cm (20")
Resolution: 1600 x 900 pixels
Processor: Intel Pentium G
Memory: 2 GB
Storage: 500 GB
Graphics: Not available

Brand: Fujitsu
Category: PCs/Workstations
Model: P400 + Display L20T-4
Part number: VFY:P0400PP131BE#*KIT*
Also known as: Fujitsu ESPRIMO P400 + Display L20T-4 Intel Pentium G G630 2 GB DDR3-SDRAM 500 GB Windows 7 Professional Mini Tower PC Black

Specifications

164 specifications in 21 groups

Processor

Specification	Value
Processor manufacturer	Intel
Processor family	Intel Pentium G
Processor model	G630
Processor cores	2
Processor threads	2
Processor frequency	2.7 GHz
Processor cache	3 MB
Processor cache type	Smart Cache
Bus type	DMI
System bus rate	5 GT/s
Processor lithography	32 nm
Processor operating modes	64-bit
Processor series	Intel Pentium G600 Series for Desktop
Processor codename	Sandy Bridge
Thermal Design Power (TDP)	65 W
Tcase	69.1 °C
PCI Express slots version	2.0
Number of processors installed	1
Processor socket	LGA 1155 (Socket H2)
CPU multiplier (bus/core ratio)	27
Stepping	Q0
Maximum internal memory supported by processor	32 GB
Memory types supported by processor	DDR3-SDRAM
Memory clock speeds supported by processor	1066 MHz
Memory bandwidth supported by processor (max)	17 GB/s

Memory

Specification	Value
Internal memory	2 GB
Maximum internal memory	8 GB
Internal memory type	DDR3-SDRAM
Memory layout (slots x size)	1 x 2 GB
Memory slots	2x DIMM
Memory clock speed	1333 MHz
Memory channels	Dual-channel

Storage

Specification	Value
Total storage capacity	500 GB
Number of HDDs installed	1
HDD capacity	500 GB
HDD interface	SATA III
HDD speed	7200 RPM
HDD size	3.5"
Card reader integrated	No
Floppy drive installed	No

Graphics

Specification	Value
On-board graphics card	Yes
Discrete graphics card model	Not available
On-board graphics card family	Intel® HD Graphics
On-board graphics card model	Intel® HD Graphics
Number of displays supported (on-board graphics)	2
On-board graphics card base frequency	850 MHz
On-board graphics card dynamic frequency (max)	1100 MHz
Maximum graphics card memory	1.759 GB
Graphics card family	Intel
Maximum resolution	1920 x 1200 pixels

Performance

Specification	Value
Product type	PC
Motherboard chipset	Intel® H61
Motherboard form factor	micro ATX
Password protection type	BIOS

Network

Specification	Value
Ethernet LAN	Yes
Ethernet LAN data rates	10,100,1000 Mbit/s
Cabling technology	10/100/1000Base-T(X)
Wi-Fi	No
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
Wi-Fi standards	802.11a, 802.11b, 802.11g
Bluetooth	No
Internal modem	No
Wake-on-LAN ready	Yes
Networking features	Gigabit Ethernet

Ports & interfaces

Specification	Value
USB 2.0 ports quantity	8
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	0
Thunderbolt ports quantity	0
DisplayPorts quantity	0
HDMI ports quantity	0
Ethernet LAN (RJ-45) ports	1
Headphone outputs	1
Line-out	Yes
Line-in	Yes
Microphone in	Yes
VGA (D-Sub) ports quantity	1
DVI port	Yes
Mini HDMI ports quantity	0
Mini DisplayPorts quantity	0
PS/2 ports quantity	2
Firewire (IEEE 1394) ports	0
eSATA ports quantity	0
S/PDIF out port	No
DC-in jack	No
SmartCard slot	No
TV-out	No
Serial ports quantity	0
Parallel ports quantity	0
Modem (RJ-11) ports	0
Headphone connectivity	3.5 mm
Microphone connectivity	3.5 mm
eSATA/USB 2.0 ports quantity	0
USB 1.1 ports quantity	0

Expansion slots

Specification	Value
Number of 3.5" bays	3
PCI Express x1 slots	2
PCI Express x16 slots	1

Power

Specification	Value
Power supply type	AC/DC
Power supply	300 W
Power supply input voltage	200 - 240 V
Power supply input frequency	50 - 60 Hz

Design

Specification	Value
Chassis type	Mini Tower
Placement supported	Vertical
Number of 5.25" bays	2
Cable lock slot	Yes
Cable lock slot type	Kensington
Product colour	Black
External drive bays	1x 3.5", 2x 5.25"
Internal drive bays	2x 3.5"

Software

Specification	Value
Operating system installed	Windows 7 Professional
Operating system architecture	64-bit
Compatible operating systems	Microsoft Windows 7 Home Basic 32-bit, Windows 7 Home Premium 64-bit, Windows 7 Professional 32-bit, Windows Vista, Windows XP, openSUSE Linux
Mac compatibility	No
Pre-installed software	Nero Essentials S, Fujitsu Recovery, Norton Internet Security, Microsoft Office Starter
Trial software	Norton Internet Security

Display

Specification	Value
Display included	Yes
Display diagonal	50.8 cm (20")
Display type	LED
Display resolution	1600 x 900 pixels
Native aspect ratio	16:9
Contrast ratio (typical)	1000:1
Touchscreen	No
Display brightness	250 cd/m²

Processor special features

Specification	Value
CPU configuration (max)	1
Embedded options available	No
Enhanced Intel SpeedStep Technology	Yes
Execute Disable Bit	Yes
Idle States	Yes
Intel 64	Yes
Intel Dual Display Capable Technology	Yes
Intel Enhanced Halt State	Yes
Intel FDI Technology	Yes
Intel Fast Memory Access	Yes
Intel Flex Memory Access	Yes
Intel Trusted Execution Technology	No
Intel VT-x with Extended Page Tables (EPT)	Yes
Intel Virtualization Technology (VT-x)	Yes
Intel Virtualization Technology for Directed I/O (VT-d)	No
Intel® AES New Instructions (Intel® AES-NI)	No
Intel® Clear Video HD Technology (Intel® CVT HD)	No
Intel® InTru™ 3D Technology	No
Intel® Insider™	No
Intel® Wireless Display (Intel® WiDi)	No
Processor ARK ID	53483
Processor code	SR05S
Processor package size	37.5 x 37.5 mm
Thermal Monitoring Technologies	Yes
Intel® Turbo Boost Technology	No
Intel® Hyper Threading Technology (Intel® HT Technology)	No
Intel® Quick Sync Video Technology	No

Audio

Specification	Value
Audio system	Realtek ALC663
Built-in microphone	No

Operational conditions

Specification	Value
Storage temperature (T-T)	10 - 35 °C
Operating temperature (T-T)	50 - 95 °F

Weight & dimensions

Specification	Value
Width	175 mm
Depth	425 mm
Height	353 mm

Packaging data

Specification	Value
Package dimensions (WxDxH)	500 x 290 x 540 mm

Packaging content

Specification	Value
Mouse included	Yes
Keyboard included	Yes
Remote control included	No

Certificates

Specification	Value
Compliance certificates	RoHS
Compliance industry standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab
Certification	CE, WEEE, HCT, HCL entry, WHQL

Multimedia

Specification	Value
Built-in camera	No

Other features

Specification	Value
TV tuner integrated	No
