Fujitsu M720 power

Model M720 powerPart no. VFY:C0WXP71NCEAN 4053026428453

119 specifications

ProcessorIntel® Xeon® E5 Family
Memory16 GB
Storage1.12 TB
TypeWorkstation
OSWindows 7 Professional
Weight18 kg

See all specifications

Overview

Processor: Intel® Xeon® E5 Family
Memory: 16 GB
Storage: 1.12 TB
Type: Workstation
OS: Windows 7 Professional
Weight: 18 kg

Brand: Fujitsu
Category: PCs/Workstations
Model: M720 power
Part numbers: VFY:C0WXP71NC, VFY:M7200WXP81NC, VFY:M7200WXP91NC
EAN / UPC: 4053026428453, 4053026428439, 4053026428446
Also known as: Fujitsu CELSIUS M720 power Intel® Xeon® E5 Family E5-1650 16 GB DDR3-SDRAM 1.12 TB HDD+SSD Windows 7 Professional Workstation Black

Specifications

119 specifications in 19 groups

Processor

Specification	Value
Processor manufacturer	Intel
Processor family	Intel® Xeon® E5 Family
Processor model	E5-1650
Processor cores	6
Processor threads	12
Processor boost frequency	3.8 GHz
Processor frequency	3.2 GHz
Processor cache	12 MB
Processor cache type	Smart Cache
Bus type	QPI
System bus rate	0 GT/s
Processor lithography	32 nm
Processor operating modes	64-bit
Thermal Design Power (TDP)	130 W
Tcase	64 °C
Maximum number of PCI Express lanes	40
PCI Express slots version	3.0
Number of processors installed	1
Processor socket	LGA 2011 (Socket R)
CPU multiplier (bus/core ratio)	38
Maximum internal memory supported by processor	375 GB
Memory types supported by processor	DDR3-SDRAM
Memory clock speeds supported by processor	800,1066,1333,1600 MHz
Memory bandwidth supported by processor (max)	51.2 GB/s
ECC supported by processor	Yes

Memory

Specification	Value
Internal memory	16 GB
Maximum internal memory	128 GB
Internal memory type	DDR3-SDRAM
Memory slots	8x DIMM
Memory clock speed	1600 MHz
Memory channels	Quad-channel

Storage

Specification	Value
Total storage capacity	1.12 TB
Optical drive type	DVD Super Multi
Storage media	HDD+SSD
Number of storage drives installed	2
Number of HDDs installed	1
HDD capacity	1 TB
Number of SSDs installed	1
SSD capacity	128 GB
Card reader integrated	Yes
RAID support	Yes
RAID levels	0, 1, 5, 10

Graphics

Specification	Value
On-board graphics card	No
On-board graphics card model	Not available

Performance

Specification	Value
Product type	Workstation
Motherboard chipset	Intel® C602
Motherboard form factor	ATX

Optical drive

Specification	Value
Optical drives quantity	1

Network

Specification	Value
Ethernet LAN	Yes
Ethernet LAN data rates	10,100,1000 Mbit/s
Cabling technology	10/100/1000Base-T(X)
Wi-Fi	No

Ports & interfaces

Specification	Value
USB 2.0 ports quantity	8
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	2
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity	0
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity	0
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity	0
Thunderbolt 3 ports quantity	0
DisplayPorts quantity	2
HDMI ports quantity	0
Ethernet LAN (RJ-45) ports	1
Headphone outputs	1
Line-out	Yes
Line-in	Yes
Microphone in	Yes
VGA (D-Sub) ports quantity	0
DVI port	Yes
PS/2 ports quantity	2

Expansion slots

Specification	Value
Number of 3.5" bays	6
PCI Express x4 (Gen 2.x) slots	1
PCI Express x4 (Gen 3.x) slots	2
PCI Express x16 (Gen 3.x) slots	2
PCI slots	2

Power

Specification	Value
Power supply input voltage	100 - 240 V
Power supply input frequency	50 - 60 Hz

Design

Specification	Value
Placement supported	Vertical
Number of 5.25" bays	5
Number of 2.5" bays	8
Cable lock slot	Yes
Cable lock slot type	Kensington
Product colour	Black

Software

Specification	Value
Operating system installed	Windows 7 Professional
Operating system architecture	64-bit
Drivers included	Yes

Display

Specification	Value
Display included	No

Processor special features

Specification	Value
CPU configuration (max)	1
Embedded options available	No
Enhanced Intel SpeedStep Technology	Yes
Execute Disable Bit	Yes
Idle States	Yes
Intel 64	Yes
Intel Demand Based Switching	Yes
Intel Enhanced Halt State	Yes
Intel Flex Memory Access	No
Intel Identity Protection Technology version	0.00
Intel Trusted Execution Technology	Yes
Intel VT-x with Extended Page Tables (EPT)	Yes
Intel Virtualization Technology (VT-x)	Yes
Intel Virtualization Technology for Directed I/O (VT-d)	Yes
Intel® AES New Instructions (Intel® AES-NI)	Yes
Intel® Smart Cache	Yes
Processor ARK ID	64601
Processor package size	52.5 x 45.0 mm
Supported instruction sets	AVX
Thermal Monitoring Technologies	Yes
Intel® Turbo Boost Technology	2.0
Intel® Hyper Threading Technology (Intel® HT Technology)	Yes
Intel® Identity Protection Technology (Intel® IPT)	No

Operational conditions

Specification	Value
Operating temperature (T-T)	10 - 35 °C
Operating relative humidity (H-H)	5 - 85%

Weight & dimensions

Specification	Value
Width	186 mm
Depth	481 mm
Height	430 mm
Weight	18 kg

Packaging content

Specification	Value
Cables included	AC
Manual	Yes

Certificates

Specification	Value
Compliance certificates	RoHS
Certification	GS, CE, cCSAus, FCC B, IEC60601-1-2, CT/HCL/WHQL, VCCI, GOST, KCC, CCC, BSMI, SASO

Sustainability

Specification	Value
Sustainability certificates	EPEAT Gold, ENERGY STAR
