Fujitsu CELSIUS M470-2 Intel® Xeon® 3000 Sequence W3670

12 GB DDR3-SDRAM Windows 7 Professional Tower Workstation Black

Model M470-2Part no. VFY:M4702WXE11DE/K8EAN 4049699461316

101 specifications

ProcessorIntel® Xeon® 3000 Sequence
Memory12 GB
Storage1 TB
TypeWorkstation
OSWindows 7 Professional
Weight18 kg

See all specifications

Overview

Processor: Intel® Xeon® 3000 Sequence
Memory: 12 GB
Storage: 1 TB
Type: Workstation
OS: Windows 7 Professional
Weight: 18 kg

Brand: Fujitsu
Category: PCs/Workstations
Model: M470-2
Part numbers: VFY:M4702WXE11DE/K8, VFY:M4702WXE11DE/K9, VFY:M4702WXE21DE/K1, VFY:M4702WXE21DE/K10, VFY:M4702WXE21DE/K11, VFY:M4702WXE21DE/K2 +34 more
EAN / UPC: 4049699461316, 4051554236380, 4051554260286, 4051554260293 +15 more
Also known as: Fujitsu CELSIUS M470-2 Intel® Xeon® 3000 Sequence W3670 12 GB DDR3-SDRAM Windows 7 Professional Tower Workstation Black

Specifications

101 specifications in 19 groups

Processor

Specification	Value
Processor manufacturer	Intel
Processor family	Intel® Xeon® 3000 Sequence
Processor model	W3670
Processor cores	6
Processor threads	12
Processor boost frequency	3.46 GHz
Processor frequency	3.2 GHz
Processor cache	12 MB
Processor cache type	L3
Bus type	QPI
System bus rate	4.8 GT/s
Processor lithography	32 nm
Processor operating modes	64-bit
Processor series	Intel Xeon 3600 Series
Thermal Design Power (TDP)	130 W
Tcase	67.9 °C
Number of QPI links	1
Number of processors installed	1
Processor socket	Socket B (LGA 1366)
CPU multiplier (bus/core ratio)	24
Maximum internal memory supported by processor	24 GB
Memory bandwidth supported by processor (max)	25.6 GB/s
ECC supported by processor	Yes

Memory

Specification	Value
Internal memory	12 GB
Maximum internal memory	24 GB
Internal memory type	DDR3-SDRAM
Memory layout (slots x size)	3 x 4 GB
Memory slots	6x DIMM
Memory clock speed	1333 MHz
ECC	Yes

Storage

Specification	Value
Optical drive type	DVD Super Multi
Number of HDDs installed	2
HDD capacity	1 TB
HDD interface	SATA
HDD speed	7200 RPM
SSD capacity	128 GB
Card reader integrated	Yes
RAID support	Yes
RAID levels	0, 1, 5, 10

Graphics

Specification	Value
Maximum graphics card memory	1.024 GB
Graphics card	Quadro 2000
Graphics card family	NVIDIA

Performance

Specification	Value
Product type	Workstation
Motherboard chipset	Intel® X58 Express

Network

Specification	Value
Networking features	Gigabit Ethernet (10/100/1000)

Ports & interfaces

Specification	Value
USB 2.0 ports quantity	11
Ethernet LAN (RJ-45) ports	1
Headphone outputs	3
Microphone in	Yes
VGA (D-Sub) ports quantity	1
PS/2 ports quantity	2
Firewire (IEEE 1394) ports	2
Serial ports quantity	1
Parallel ports quantity	0

Expansion slots

Specification	Value
Number of 3.5" bays	4
PCI Express x4 slots	2
PCI Express x16 slots	2
PCI slots	2

Power

Specification	Value
Power supply	190 W
Power supply input voltage	100 - 240 V
Power supply input frequency	50 - 60 Hz

Design

Specification	Value
Chassis type	Tower
Number of 5.25" bays	3
Cable lock slot	Yes
Cable lock slot type	Kensington
Product colour	Black

Software

Specification	Value
Operating system installed	Windows 7 Professional
Operating system architecture	64-bit

Display

Specification	Value
Display included	No

Processor special features

Specification	Value
CPU configuration (max)	1
Embedded options available	No
Enhanced Intel SpeedStep Technology	Yes
Execute Disable Bit	Yes
Idle States	Yes
Intel 64	Yes
Intel Demand Based Switching	Yes
Intel Enhanced Halt State	Yes
Intel Trusted Execution Technology	Yes
Intel VT-x with Extended Page Tables (EPT)	Yes
Intel Virtualization Technology (VT-x)	Yes
Intel® AES New Instructions (Intel® AES-NI)	Yes
Physical Address Extension (PAE)	36 bit
Processor ARK ID	47918
Processor package size	42.5 X 45 mm
Supported instruction sets	SSE4.2
Thermal Monitoring Technologies	No
Intel® Turbo Boost Technology	1.0
Intel® Hyper Threading Technology (Intel® HT Technology)	Yes
Conflict-Free processor	No

Audio

Specification	Value
Audio system	HD
Speakers	1

Operational conditions

Specification	Value
Operating temperature (T-T)	15 - 35 °C
Operating relative humidity (H-H)	10 - 75%

Weight & dimensions

Specification	Value
Width	215 mm
Depth	522 mm
Height	446 mm
Weight	18 kg

Packaging content

Specification	Value
Mouse included	Yes

Certificates

Specification	Value
Compliance industry standards	IEEE 802.3/802.3u/802.3ab
Certification	GS, CE, FCC, RoHS, ENERGY STAR, CCC

Other features

Specification	Value
HDD user password	Yes
