Fujitsu ESPRIMO P5635 E-Star 5.0

Model ESPRIMO P5635 E-Star 5.0Part no. VFY:P5635PF021DEEAN 4049699195990

121 specifications

ProcessorIntel® Pentium® D
Memory4 GB
Storage500 GB
GraphicsNVIDIA® GeForce® 9200
TypePC
OSWindows 7 Professional

See all specifications

Overview

Processor: Intel® Pentium® D
Memory: 4 GB
Storage: 500 GB
Graphics: NVIDIA® GeForce® 9200
Type: PC
OS: Windows 7 Professional

Brand: Fujitsu
Category: PCs/Workstations
Model: ESPRIMO P5635 E-Star 5.0
Part numbers: VFY:P5635PF021DE, VFY:P5635PF011DE
EAN / UPC: 4049699195990, 4049699195983
Also known as: Fujitsu ESPRIMO P5635 E-Star 5.0 Intel® Pentium® D 945 4 GB DDR2-SDRAM 500 GB NVIDIA® GeForce® 9200 Windows 7 Professional Micro Tower PC

Specifications

121 specifications in 19 groups

Processor

Specification	Value
Processor manufacturer	Intel
Processor family	Intel® Pentium® D
Processor model	945
Processor cores	2
Processor threads	2
Processor frequency	3.4 GHz
Processor cache	4 MB
Processor cache type	L2
Processor front side bus	800 MHz
Bus type	FSB
FSB Parity	No
Processor lithography	65 nm
Processor operating modes	64-bit
Processor series	Intel Pentium D 900 Series
Processor codename	Presler
Thermal Design Power (TDP)	95 W
Tcase	63.4 °C
Number of processors installed	1
Processor socket	LGA 775 (Socket T)
Number of Processing Die Transistors	376 M
Processing Die size	162 mm²
CPU multiplier (bus/core ratio)	17
Maximum number of SMP processors	1
ECC supported by processor	No

Memory

Specification	Value
Internal memory	4 GB
Maximum internal memory	16 GB
Internal memory type	DDR2-SDRAM
Memory clock speed	800 MHz

Storage

Specification	Value
Total storage capacity	500 GB
Optical drive type	DVD Super Multi
HDD interface	SATA II
HDD speed	7200 RPM
Card reader integrated	No
Floppy drive installed	No

Graphics

Specification	Value
On-board graphics card	Yes
Discrete graphics card model	NVIDIA® GeForce® 9200
Maximum graphics card memory	0.256 GB
External video modes refresh rate (max)	150 Hz
External video modes resolution (max)	1920 x 1200 pixels

Performance

Specification	Value
Product type	PC
Password protection type	BIOS

Network

Specification	Value
Ethernet LAN	Yes
Wi-Fi	No
Wake-on-LAN ready	Yes
Networking features	Gigabit Ethernet

Ports & interfaces

Specification	Value
USB 2.0 ports quantity	10
HDMI ports quantity	0
Ethernet LAN (RJ-45) ports	1
Headphone outputs	1
Line-out	Yes
Line-in	Yes
Microphone in	Yes
VGA (D-Sub) ports quantity	1
DVI port	No
PS/2 ports quantity	2
Firewire (IEEE 1394) ports	0
Serial ports quantity	1
Parallel ports quantity	0

Expansion slots

Specification	Value
PCI Express x1 slots	1
PCI Express x16 slots	1
PCI slots	2

Power

Specification	Value
Power requirements	AC 100 - 240V@50 - 60Hz
Power supply	300 W

Design

Specification	Value
Chassis type	Micro Tower
Cable lock slot	Yes
Cable lock slot type	Kensington
External drive bays	2x 3.5", 2x 5.25"
Internal drive bays	2x 3.5"

Software

Specification	Value
Operating system installed	Windows 7 Professional
Optional operating system supplied	Windows XP Professional
Compatible operating systems	Microsoft Windows 7 Home Premium/Vista Home Basic/Vista Home Premium/Vista Business, Linux
Mac compatibility	No
Bundled software	Nero Essentials S

Display

Specification	Value
Display included	No

Processor special features

Specification	Value
Embedded options available	No
Enhanced Intel SpeedStep Technology	Yes
Execute Disable Bit	Yes
Idle States	Yes
Intel 64	Yes
Intel Clear Video Technology	No
Intel Demand Based Switching	No
Intel Dual Display Capable Technology	No
Intel Enhanced Halt State	Yes
Intel FDI Technology	No
Intel Fast Memory Access	No
Intel Flex Memory Access	No
Intel Rapid Storage Technology	No
Intel Trusted Execution Technology	No
Intel VT-x with Extended Page Tables (EPT)	No
Intel Virtualization Technology (VT-x)	No
Intel Virtualization Technology for Directed I/O (VT-d)	No
Intel® AES New Instructions (Intel® AES-NI)	No
Intel® Clear Video HD Technology (Intel® CVT HD)	No
Intel® Clear Video Technology for Mobile Internet Devices (Intel CVT for MID)	No
Intel® InTru™ 3D Technology	No
Intel® Insider™	No
Intel® Wireless Display (Intel® WiDi)	No
Physical Address Extension (PAE)	32 bit
Processor ARK ID	27520
Processor package size	37.5 x 37.5 mm
Thermal Monitoring Technologies	No
Intel® Turbo Boost Technology	No
Intel® Hyper Threading Technology (Intel® HT Technology)	No
Intel® Quick Sync Video Technology	No
Intel® My WiFi Technology (Intel® MWT)	No
Intel® Anti-Theft Technology (Intel® AT)	No
Conflict-Free processor	No

Audio

Specification	Value
Audio system	Realtek ALC262

Weight & dimensions

Specification	Value
Width	203 mm
Depth	390 mm
Height	392 mm
Weight	12 kg

Packaging data

Specification	Value
Package dimensions (WxDxH)	500 x 290 x 540 mm

Packaging content

Specification	Value
Mouse included	Yes
Remote control included	No

Certificates

Specification	Value
Compliance industry standards	DMI 2.0, PC 2001, WMI 1.5, USB 2.0
Certification	CE, Nordic Swan, FCC Class B, cCSAus, RoHS, WEEE, HCT/HCL entry/WHQL, ENERGY STAR 5.0, EPEAT Silver

Other features

Specification	Value
TV tuner integrated	No
HDD user password	Yes
Drive bays	6
Motherboard	D2901
