X87001 Intel® Core™ i9 X-series i9-7900X
64 GB DDR4-SDRAM 9 TB HDD+SSD NVIDIA® GeForce® GTX 1080 Ti Windows 10 Pro PC Black, Blue
Model X87001Part no. 10022072
95 specifications
- ProcessorIntel® Core™ i9 X-series
- Memory64 GB
- Storage9 TB
- GraphicsNVIDIA® GeForce® GTX 1080 Ti
- SpeedWi-Fi 5 (802.11ac)
- TypePC
Overview
- Processor
- Intel® Core™ i9 X-series
- Memory
- 64 GB
- Storage
- 9 TB
- Graphics
- NVIDIA® GeForce® GTX 1080 Ti
- Speed
- Wi-Fi 5 (802.11ac)
- Type
- PC
- Brand
- ERAZER
- Category
- PCs/Workstations
- Model
- X87001
- Part number
- 10022072
- Also known as
- ERAZER X87001 Intel® Core™ i9 X-series i9-7900X 64 GB DDR4-SDRAM 9 TB HDD+SSD NVIDIA® GeForce® GTX 1080 Ti Windows 10 Pro PC Black, Blue
Specifications
95 specifications in 15 groups
Processor
| Specification | Value |
|---|---|
| Processor manufacturer | Intel |
| Processor family | Intel® Core™ i9 X-series |
| Processor generation | 7th gen Intel® Core™ i9 |
| Processor model | i9-7900X |
| Processor cores | 10 |
| Processor threads | 20 |
| Processor boost frequency | 4.3 GHz |
| Processor frequency | 3.3 GHz |
| Processor cache | 13.75 MB |
| Processor cache type | L3 |
| Bus type | DMI3 |
| System bus rate | 8 GT/s |
| Processor lithography | 14 nm |
| Processor operating modes | 64-bit |
| Processor codename | Skylake |
| Thermal Design Power (TDP) | 140 W |
| Tjunction | 95 °C |
| Maximum number of PCI Express lanes | 44 |
| PCI Express slots version | 3.0 |
| Number of QPI links | 0 |
| Number of processors installed | 1 |
| Processor socket | LGA 2066 (Socket R4) |
| Stepping | U0 |
| Maximum internal memory supported by processor | 128 GB |
| Memory types supported by processor | DDR4-SDRAM |
| Memory clock speeds supported by processor | 2666 MHz |
| ECC supported by processor | No |
Memory
| Specification | Value |
|---|---|
| Internal memory | 64 GB |
| Maximum internal memory | 128 GB |
| Internal memory type | DDR4-SDRAM |
| Memory layout (slots x size) | 4 x 16 GB |
| Memory slots | 8x DIMM |
| Memory clock speed | 2666 MHz |
| Memory channels | Quad-channel |
Storage
| Specification | Value |
|---|---|
| Total storage capacity | 9 TB |
| Optical drive type | Blu-Ray DVD Combo |
| Storage media | HDD+SSD |
| Number of SSDs installed | 1 |
| SSD capacity | 1 TB |
| Card reader integrated | Yes |
Graphics
| Specification | Value |
|---|---|
| Discrete graphics card | Yes |
| Discrete graphics card model | NVIDIA® GeForce® GTX 1080 Ti |
| Discrete graphics card memory | 11 GB |
| Discrete graphics memory type | GDDR5X |
| Number of discrete graphics cards | 1 |
Performance
| Specification | Value |
|---|---|
| Product type | PC |
| Motherboard chipset | Intel X299 Express |
Optical drive
| Specification | Value |
|---|---|
| Optical drives quantity | 1 |
Network
| Specification | Value |
|---|---|
| Ethernet LAN | Yes |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| Cabling technology | 10/100/1000Base-T(X) |
| Wi-Fi | Yes |
| Top Wi-Fi standard | Wi-Fi 5 (802.11ac) |
| Wi-Fi standards | 802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n) |
| Bluetooth | Yes |
| Bluetooth version | 4.0 |
Ports & interfaces
| Specification | Value |
|---|---|
| USB 2.0 ports quantity | 3 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 7 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity | 1 |
| DisplayPorts quantity | 3 |
| HDMI ports quantity | 1 |
| Ethernet LAN (RJ-45) ports | 1 |
| Headphone outputs | 1 |
| Line-out | Yes |
| Line-in | Yes |
| Microphone in | Yes |
| PS/2 ports quantity | 1 |
| S/PDIF out port | Yes |
Power
| Specification | Value |
|---|---|
| Power supply | 850 W |
Design
| Specification | Value |
|---|---|
| Placement supported | Vertical |
| Product colour | Black, Blue |
Software
| Specification | Value |
|---|---|
| Operating system installed | Windows 10 Pro |
| Operating system architecture | 64-bit |
Display
| Specification | Value |
|---|---|
| Display included | No |
Processor special features
| Specification | Value |
|---|---|
| CPU configuration (max) | 1 |
| Embedded options available | No |
| Enhanced Intel SpeedStep Technology | Yes |
| Execute Disable Bit | Yes |
| Intel 64 | Yes |
| Intel Virtualization Technology (VT-x) | Yes |
| Intel Virtualization Technology for Directed I/O (VT-d) | Yes |
| Intel® AES New Instructions (Intel® AES-NI) | Yes |
| Processor ARK ID | 123613 |
| Processor code | SR3L2 |
| Scalability | 1S |
| Supported instruction sets | AVX 2.0, AVX-512, SSE4.1, SSE4.2 |
| Thermal solution specification | PCG 2017X |
| Intel® Turbo Boost Technology | 2.0 |
| Intel® Hyper Threading Technology (Intel® HT Technology) | Yes |
| Conflict-Free processor | Yes |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 280 mm |
| Depth | 555 mm |
| Height | 560 mm |
| Weight | 19 kg |
Packaging content
| Specification | Value |
|---|---|
| Mouse included | Yes |
