Dell OptiPlex GX520 Intel® Pentium® D 820 DDR2-SDRAM

80 GB HDD Windows 7 Home Premium Desktop PC Black

Model GX520Part no. 3700868405241EAN 3700868405241

104 specifications

Overview

Brand: Dell
Category: PCs/Workstations
Model: GX520
Part number: 3700868405241
EAN / UPC: 3700868405241
Also known as: DELL OptiPlex GX520 Intel® Pentium® D 820 DDR2-SDRAM 80 GB HDD Windows 7 Home Premium Desktop PC Black

104 specifications in 15 groups

Specification	Value
Processor manufacturer	Intel
Processor family	Intel® Pentium® D
Processor model	820
Processor cores	2
Processor threads	2
Processor frequency	2.8 GHz
Processor cache	2 MB
Processor cache type	L2
Processor front side bus	800 MHz
Bus type	FSB
FSB Parity	No
Processor lithography	90 nm
Processor operating modes	64-bit
Processor series	Intel Pentium D 800 Series
Processor codename	Smithfield
Thermal Design Power (TDP)	95 W
Tcase	64.1 °C
Number of processors installed	1
Processor socket	LGA 775 (Socket T)
Number of Processing Die Transistors	230 M
Processing Die size	206 mm²
CPU multiplier (bus/core ratio)	14
Processor core voltage (AC)	1.25 - 1.40 V
ECC supported by processor	No

Specification	Value
Total storage capacity	80 GB
Optical drive type	DVD Super Multi
Storage media	HDD
Number of storage drives installed	1
Number of HDDs installed	1
HDD capacity	80 GB
HDD interface	SATA II

Specification	Value
On-board graphics card	Yes
On-board graphics card family	Intel® GMA
On-board graphics card model	Intel® GMA 950

Specification	Value
Product type	PC
Motherboard chipset	Intel® 945G

Specification	Value
Optical drives quantity	1

Specification	Value
USB 2.0 ports quantity	8
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	0
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity	0
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity	0
HDMI ports quantity	0
Ethernet LAN (RJ-45) ports	1
Headphone outputs	1
Line-out	Yes
Line-in	Yes
Microphone in	Yes
VGA (D-Sub) ports quantity	1
DVI port	No
Serial ports quantity	1
Parallel ports quantity	1

Specification	Value
Power supply	220 W

Specification	Value
Chassis type	Desktop
Product colour	Black

Specification	Value
Operating system installed	Windows 7 Home Premium
Drivers included	Yes

Specification	Value
Display included	No

Specification	Value
Embedded options available	No
Enhanced Intel SpeedStep Technology	No
Execute Disable Bit	Yes
Idle States	Yes
Intel 64	Yes
Intel Clear Video Technology	No
Intel Demand Based Switching	No
Intel Dual Display Capable Technology	No
Intel Enhanced Halt State	Yes
Intel FDI Technology	No
Intel Fast Memory Access	No
Intel Flex Memory Access	No
Intel Rapid Storage Technology	No
Intel Trusted Execution Technology	No
Intel VT-x with Extended Page Tables (EPT)	No
Intel Virtualization Technology (VT-x)	No
Intel Virtualization Technology for Directed I/O (VT-d)	No
Intel® AES New Instructions (Intel® AES-NI)	No
Intel® Clear Video HD Technology (Intel® CVT HD)	No
Intel® Clear Video Technology for Mobile Internet Devices (Intel CVT for MID)	No
Intel® InTru™ 3D Technology	No
Intel® Insider™	No
Intel® Smart Cache	No
Intel® Wireless Display (Intel® WiDi)	No
Physical Address Extension (PAE)	32 bit
Physical Address Extension (PAE)	Yes
Processor ARK ID	27512
Processor package size	37.5 x 37.5 mm
Thermal Monitoring Technologies	No
Intel® Turbo Boost Technology	No
Intel® Hyper Threading Technology (Intel® HT Technology)	No
Intel® Quick Sync Video Technology	No
Intel® My WiFi Technology (Intel® MWT)	No
Intel® Anti-Theft Technology (Intel® AT)	No
Conflict-Free processor	No

Specification	Value
Manual	Yes
