7960 Rack
Model 7960 RackPart no. XCTOPR7960EMEA_VP
73 specifications
- ProcessorIntel Xeon Silver
- Memory16 GB
- Storage512 GB
- GraphicsNot available
- TypeWorkstation
- OSWindows 11 Pro for Workstations
Overview
- Processor
- Intel Xeon Silver
- Memory
- 16 GB
- Storage
- 512 GB
- Graphics
- Not available
- Type
- Workstation
- OS
- Windows 11 Pro for Workstations
- Brand
- Dell
- Category
- PCs/Workstations
- Model
- 7960 Rack
- Part numbers
- XCTOPR7960EMEA_VP, AWF7960R_VP, XCTOPR7960CA_VP, XCTOPR7960US_VP, XCTOPR7960USAI_VP
- Also known as
- DELL Precision 7960 Rack Intel Xeon Silver 4410Y 16 GB DDR5-SDRAM 512 GB SSD Windows 11 Pro for Workstations Rack-mounted chassis Workstation Black, Silver
Specifications
73 specifications in 15 groups
Processor
| Specification | Value |
|---|---|
| Processor manufacturer | Intel |
| Processor family | Intel Xeon Silver |
| Processor generation | Intel Xeon Scalable 4th Gen |
| Processor model | 4410Y |
| Processor cores | 12 |
| Processor threads | 24 |
| Processor boost frequency | 3.9 GHz |
| Processor frequency | 2 GHz |
| Processor cache | 30 MB |
Memory
| Specification | Value |
|---|---|
| Internal memory | 16 GB |
| Maximum internal memory | 2 TB |
| Internal memory type | DDR5-SDRAM |
| Memory layout (slots x size) | 1 x 16 GB |
| Memory slots | 32x DIMM |
| Memory clock speed | 4800 MHz |
| ECC | Yes |
| Memory data transfer rate | 4800 MT/s |
Storage
| Specification | Value |
|---|---|
| Total storage capacity | 512 GB |
| Optical drive type | No |
| Storage media | SSD |
| Total SSDs capacity | 512 GB |
| Number of SSDs installed | 1 |
| SSD capacity | 512 GB |
| NVMe | Yes |
| SSD interface | PCI Express |
| SSD form factor | M.2 |
| SSD performance class | 40 |
Graphics
| Specification | Value |
|---|---|
| Discrete graphics card | No |
| On-board graphics card | No |
| Discrete graphics card model | Not available |
| On-board graphics card model | Not available |
Performance
| Specification | Value |
|---|---|
| Product type | Workstation |
| Market positioning | Business |
| Password protection | Yes |
| Trusted Platform Module (TPM) | Yes |
Network
| Specification | Value |
|---|---|
| Ethernet LAN | Yes |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| LAN controller | Broadcom 5720 |
| Wi-Fi | No |
Ports & interfaces
| Specification | Value |
|---|---|
| USB 2.0 ports quantity | 2 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 1 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity | 0 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity | 0 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity | 0 |
| USB 3.2 Gen 2x2 Type-C ports quantity | 0 |
| Thunderbolt 3 ports quantity | 0 |
| HDMI ports quantity | 0 |
| Ethernet LAN (RJ-45) ports | 2 |
| VGA (D-Sub) ports quantity | 2 |
Expansion slots
| Specification | Value |
|---|---|
| Number of 3.5" bays | 8 |
Power
| Specification | Value |
|---|---|
| Power supply | 1100 W |
| Power supply input voltage | 180 - 264 V |
| Power supply input frequency | 47 - 63 Hz |
Design
| Specification | Value |
|---|---|
| Chassis type | Rack-mounted chassis |
| Placement supported | Horizontal |
| Product colour | Black, Silver |
Software
| Specification | Value |
|---|---|
| Operating system installed | Windows 11 Pro for Workstations |
| Operating system architecture | 64-bit |
Display
| Specification | Value |
|---|---|
| Display included | No |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 10 - 35 °C |
| Storage temperature (T-T) | -40 - 65 °C |
| Operating relative humidity (H-H) | 20 - 80% |
| Storage relative humidity (H-H) | 5 - 95% |
| Operating altitude | -15.2 - 3050 m |
| Non-operating altitude | -15.2 - 12000 m |
| Operating vibration | 0.21 G |
| Non-operating vibration | 1.88 G |
| Operating shock | 6 G |
| Non-operating shock | 71 G |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 735 mm |
| Depth | 772.1 mm |
| Weight | 21 kg |
Packaging content
| Specification | Value |
|---|---|
| Cables included | AC |
