Dell Precision 7920r Intel® Xeon® 3104

16 GB DDR4-SDRAM 500 GB HDD NVIDIA® NVS™ 310 Windows 10 Pro for Workstations Rack-mounted chassis Workstation Black, Stai

Model 7920rPart no. AWR7920

111 specifications

ProcessorIntel® Xeon®
Memory16 GB
Storage500 GB
GraphicsNVIDIA® NVS™ 310
TypeWorkstation
OSWindows 10 Pro for Workstations

See all specifications

Overview

Processor: Intel® Xeon®
Memory: 16 GB
Storage: 500 GB
Graphics: NVIDIA® NVS™ 310
Type: Workstation
OS: Windows 10 Pro for Workstations

Brand: Dell
Category: PCs/Workstations
Model: 7920r
Part numbers: AWR7920, CUPNVS31279X16SN2OJP
Also known as: DELL Precision 7920r Intel® Xeon® 3104 16 GB DDR4-SDRAM 500 GB HDD NVIDIA® NVS™ 310 Windows 10 Pro for Workstations Rack-mounted chassis Workstation Black, Stai

Specifications

111 specifications in 16 groups

Processor

Specification	Value
Processor manufacturer	Intel
Processor family	Intel® Xeon®
Processor generation	1st Generation Intel® Xeon® Scalable
Processor model	3104
Processor cores	6
Processor threads	6
Processor frequency	1.7 GHz
Processor cache	8.25 MB
Processor cache type	L3
Processor lithography	14 nm
Processor operating modes	64-bit
Processor codename	Skylake
Thermal Design Power (TDP)	85 W
Tcase	78 °C
Maximum number of PCI Express lanes	48
PCI Express slots version	3.0
Number of processors installed	1
Processor socket	LGA 3647 (Socket P)
Stepping	U0
Maximum internal memory supported by processor	768 GB
Memory types supported by processor	DDR4-SDRAM
Memory clock speeds supported by processor	2133 MHz
ECC supported by processor	Yes

Memory

Specification	Value
Internal memory	16 GB
Maximum internal memory	1.53 TB
Internal memory type	DDR4-SDRAM
Memory layout (slots x size)	2 x 8 GB
Memory slots	24x DIMM
Memory clock speed	2666 MHz
ECC	Yes
Memory channels	Hexa-channel

Storage

Specification	Value
Total storage capacity	500 GB
Optical drive type	No
Storage media	HDD
Number of storage drives installed	1
Number of HDDs installed	1
HDD capacity	500 GB
HDD interface	SATA III
HDD speed	7200 RPM
HDD size	2.5"

Graphics

Specification	Value
Discrete graphics card	Yes
On-board graphics card	No
Discrete graphics card model	NVIDIA® NVS™ 310
Discrete graphics card memory	1 GB
Discrete graphics memory type	GDDR3
Number of discrete graphics cards	1
On-board graphics card model	Not available

Performance

Specification	Value
Product type	Workstation
Market positioning	Business
Compatible processor series	Intel® Xeon®
Password protection	Yes
Password protection type	BIOS
Trusted Platform Module (TPM)	Yes

Network

Specification	Value
Ethernet LAN	Yes
Ethernet LAN data rates	10,100,1000 Mbit/s
Cabling technology	10/100/1000Base-T(X)
Wi-Fi	No

Ports & interfaces

Specification	Value
USB 2.0 ports quantity	2
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	2
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity	0
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity	0
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity	0
Thunderbolt 3 ports quantity	0
HDMI ports quantity	0
Ethernet LAN (RJ-45) ports	5
Headphone outputs	0
Microphone in	No
VGA (D-Sub) ports quantity	2
DVI port	No
Serial ports quantity	1

Power

Specification	Value
Power supply input voltage	100 - 240 V
Power supply input frequency	50 - 60 Hz

Design

Specification	Value
Chassis type	Rack-mounted chassis
Rack capacity	2U
Placement supported	Horizontal
Product colour	Black, Stainless steel

Software

Specification	Value
Operating system installed	Windows 10 Pro for Workstations
Trial software	McAfee Small Business Security

Display

Specification	Value
Display included	No

Processor special features

Specification	Value
Embedded options available	No
Enhanced Intel SpeedStep Technology	Yes
Execute Disable Bit	Yes
Intel 64	Yes
Intel TSX-NI	Yes
Intel TSX-NI version	1.00
Intel Trusted Execution Technology	Yes
Intel VT-x with Extended Page Tables (EPT)	Yes
Intel Virtualization Technology (VT-x)	Yes
Intel Virtualization Technology for Directed I/O (VT-d)	Yes
Intel® AES New Instructions (Intel® AES-NI)	Yes
Processor ARK ID	123546
Processor code	SR3GM
Processor package size	76.0 x 56.5 mm
Scalability	2S
Supported instruction sets	AVX, AVX 2.0, AVX-512, SSE4.2
Intel® Turbo Boost Technology	No
Intel® Hyper Threading Technology (Intel® HT Technology)	No
Conflict-Free processor	Yes

Operational conditions

Specification	Value
Operating temperature (T-T)	10 - 35 °C
Storage temperature (T-T)	-40 - 65 °C
Operating relative humidity (H-H)	10 - 80%
Storage relative humidity (H-H)	5 - 95%
Operating vibration	0.26 G
Non-operating vibration	1.88 G

Weight & dimensions

Specification	Value
Width	482 mm
Depth	715.5 mm
Height	86.8 mm
Weight	28.6 kg

Packaging content

Specification	Value
Cables included	AC
Manual	Yes

Sustainability

Specification	Value
Sustainability certificates	ENERGY STAR
