BUSINESSline Workstation WS1310R
Model BUSINESSline Workstation WS1310RPart no. 850565EAN 4250749708033
70 specifications
- ProcessorAMD Ryzen™ Threadripper™
- Memory32 GB
- Storage500 GB
- GraphicsNVIDIA Quadro RTX A4000
- SpeedWi-Fi 7 (802.11be)
- TypeWorkstation
Overview
- Processor
- AMD Ryzen™ Threadripper™
- Memory
- 32 GB
- Storage
- 500 GB
- Graphics
- NVIDIA Quadro RTX A4000
- Speed
- Wi-Fi 7 (802.11be)
- Type
- Workstation
- Brand
- bluechip
- Category
- PCs/Workstations
- Model
- BUSINESSline Workstation WS1310R
- Part numbers
- 850565, 850625, 850672, 850748, 850433
- EAN / UPC
- 4250749708033, 4250749710074, 4250749711484, 4250749712733 +1 more
- Also known as
- bluechip BUSINESSline Workstation WS1310R 19" Rack mit Wasserkühlung, AMD Ryzen™ Threadripper™ 7960X Prozessor / bis zu 5.30 GHz, Windows 11 Pro, AMD® TRX50, 32
Specifications
70 specifications in 14 groups
Processor
| Specification | Value |
|---|---|
| Processor manufacturer | AMD |
| Processor family | AMD Ryzen™ Threadripper™ |
| Processor generation | AMD Ryzen Threadripper 7000 Series |
| Processor model | 7960X |
| Processor cores | 24 |
| Processor threads | 48 |
| Processor boost frequency | 5.3 GHz |
| Processor frequency | 4.2 GHz |
| Processor cache | 128 MB |
| Processor cache type | L3 |
| Number of processors installed | 1 |
| Processor socket | Socket sTR5 |
| Processor base power | 350 W |
Memory
| Specification | Value |
|---|---|
| Internal memory | 32 GB |
| Maximum internal memory | 1 TB |
| Internal memory type | DDR5-SDRAM |
| Memory layout (slots x size) | 2 x 16 GB |
| Memory slots | 4x DIMM |
| Memory clock speed | 5600 MHz |
| ECC | Yes |
Storage
| Specification | Value |
|---|---|
| Total storage capacity | 500 GB |
| Optical drive type | No |
| Storage media | SSD |
| Number of storage drives installed | 1 |
| Total SSDs capacity | 500 GB |
| Number of SSDs installed | 1 |
| SSD capacity | 500 GB |
| NVMe | Yes |
| SSD interface | PCI Express 4.0 |
Graphics
| Specification | Value |
|---|---|
| Discrete graphics card | Yes |
| On-board graphics card | No |
| Discrete GPU manufacturer | NVIDIA |
| Discrete graphics card model | NVIDIA Quadro RTX A4000 |
| Discrete graphics card memory | 16 GB |
| Discrete graphics memory type | GDDR6 |
| Number of discrete graphics cards | 1 |
| On-board graphics card model | Not available |
| Graphics card DisplayPorts quantity | 4 |
| Maximum discrete graphics card resolution | 7680 x 4320 pixels |
Performance
| Specification | Value |
|---|---|
| Product type | Workstation |
| Motherboard chipset | AMD TRX50 |
Network
| Specification | Value |
|---|---|
| Ethernet LAN | Yes |
| Ethernet LAN data rates | 2500,10000 Mbit/s |
| LAN controller | Intel I226-LM |
| Wi-Fi | Yes |
| Top Wi-Fi standard | Wi-Fi 7 (802.11be) |
| Wi-Fi standards | Wi-Fi 7 (802.11be) |
| Bluetooth | Yes |
| Bluetooth version | 5.4 |
Ports & interfaces
| Specification | Value |
|---|---|
| USB 2.0 ports quantity | 4 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 0 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity | 0 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity | 6 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity | 0 |
| USB 3.2 Gen 2x2 Type-C ports quantity | 1 |
| Ethernet LAN (RJ-45) ports | 2 |
| Combo headphone/mic port | Yes |
| S/PDIF out port | Yes |
Expansion slots
| Specification | Value |
|---|---|
| PCI Express x16 (Gen 5.x) slots | 2 |
Power
| Specification | Value |
|---|---|
| Power supply | 1000 W |
| 80 PLUS certification | 80 PLUS Gold |
Design
| Specification | Value |
|---|---|
| Chassis type | Rack-mounted chassis |
| Product colour | Black |
Software
| Specification | Value |
|---|---|
| Operating system installed | Windows 11 Pro |
| Operating system architecture | 64-bit |
Display
| Specification | Value |
|---|---|
| Display included | No |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 479 mm |
| Depth | 737 mm |
| Height | 178 mm |
Features
| Specification | Value |
|---|---|
| Motherboard manufacturer | .ASUS Pro WS TRX50-SAGE WiFi |
