TEY21-i7 Intel® Core™ i7 i7-10510U
8 GB 256 GB SSD Windows 10 Pro Mini PC Black
Model TEY21-i7Part no. 5J.F5S11.212EAN 840046045371
64 specifications
- ProcessorIntel® Core™ i7
- Memory8 GB
- Storage256 GB
- SpeedWi-Fi 6 (802.11ax)
- TypeMini PC
- OSWindows 10 Pro
Overview
- Processor
- Intel® Core™ i7
- Memory
- 8 GB
- Storage
- 256 GB
- Speed
- Wi-Fi 6 (802.11ax)
- Type
- Mini PC
- OS
- Windows 10 Pro
- Brand
- BenQ
- Category
- PCs/Workstations
- Model
- TEY21-i7
- Part number
- 5J.F5S11.212
- EAN / UPC
- 840046045371, 4718755086281
- Also known as
- BenQ TEY21-i7 Intel® Core™ i7 i7-10510U 8 GB 256 GB SSD Windows 10 Pro Mini PC Black
Specifications
64 specifications in 14 groups
Processor
| Specification | Value |
|---|---|
| Processor manufacturer | Intel |
| Processor family | Intel® Core™ i7 |
| Processor generation | 10th gen Intel® Core™ i7 |
| Processor model | i7-10510U |
| Processor cores | 8 |
| Processor boost frequency | 4.41 GHz |
| Processor frequency | 1.07 GHz |
| Configurable TDP-up | 25 W |
| Configurable TDP-up frequency | 2.3 GHz |
| Configurable TDP-down | 10 W |
| Configurable TDP-down frequency | 0.8 GHz |
Memory
| Specification | Value |
|---|---|
| Internal memory | 8 GB |
| Maximum internal memory | 8 GB |
Storage
| Specification | Value |
|---|---|
| Total storage capacity | 256 GB |
| Optical drive type | No |
| Storage media | SSD |
| Total SSDs capacity | 256 GB |
| Number of SSDs installed | 1 |
| SSD capacity | 256 GB |
Graphics
| Specification | Value |
|---|---|
| Discrete graphics card | No |
| On-board graphics card | Yes |
| On-board GPU manufacturer | Intel |
| On-board graphics card family | Intel® UHD Graphics |
| On-board graphics card model | Intel® UHD Graphics |
| Graphics card | Intel HD Graphics |
Performance
| Specification | Value |
|---|---|
| Product type | Mini PC |
| Trusted Platform Module (TPM) | Yes |
Network
| Specification | Value |
|---|---|
| Ethernet LAN | Yes |
| Ethernet LAN data rates | 100,1000 Mbit/s |
| Wi-Fi | Yes |
| Top Wi-Fi standard | Wi-Fi 6 (802.11ax) |
| Wi-Fi standards | 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax) |
Ports & interfaces
| Specification | Value |
|---|---|
| USB 2.0 ports quantity | 1 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 3 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity | 1 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity | 0 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity | 0 |
| Thunderbolt 3 ports quantity | 0 |
| HDMI ports quantity | 1 |
| Ethernet LAN (RJ-45) ports | 1 |
Design
| Specification | Value |
|---|---|
| Chassis type | Mini PC |
| Product colour | Black |
Software
| Specification | Value |
|---|---|
| Operating system installed | Windows 10 Pro |
Display
| Specification | Value |
|---|---|
| Display included | No |
Processor special features
| Specification | Value |
|---|---|
| CPU configuration (max) | 1 |
| Embedded options available | No |
| Enhanced Intel SpeedStep Technology | Yes |
| Execute Disable Bit | Yes |
| Idle States | Yes |
| Intel 64 | Yes |
| Intel Clear Video Technology | Yes |
| Intel Flex Memory Access | Yes |
| Intel Software Guard Extensions (Intel SGX) | Yes |
| Intel Stable Image Platform Program (SIPP) | No |
| Intel TSX-NI | No |
| Intel Trusted Execution Technology | No |
| Intel VT-x with Extended Page Tables (EPT) | Yes |
| Intel Virtualization Technology (VT-x) | Yes |
| Intel Virtualization Technology for Directed I/O (VT-d) | Yes |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 180 mm |
| Depth | 119 mm |
| Height | 30 mm |
Logistics data
| Specification | Value |
|---|---|
| Harmonized System (HS) code | 84715000 |
Features
| Specification | Value |
|---|---|
| Compatibility | RP6503, RP7503, RP8603, RP6502, RP7502, RP8602, RP6501K, RP7501K, RP8601K RM6503, RM7503, RM8603 RM5502K, RM6502K, RM7502K, RM8602K RM5501K, RM6501K, RM7501K, RM8601K RM6502S, RM7502S, RM8602S RE6501, RE7501, RE8601, RE9801 IL4301, IL5501, CP6501K, CP8601K CS6501, CS7501, CS8601 ST4302, ST5502, ST65 |
