ASUS ROG GR8-R076R PC/workstation Intel® Core™ i7 i7-4510U

ASUS ROG GR8-R076R PC/workstation Intel® Core™ i7 i7-4510U

8 GB DDR3L-SDRAM 1 TB HDD NVIDIA® GeForce® GTX 750 Ti Windows 8.1 Mini PC Black, Red

Model GR8-R076REAN 4716659947226

137 specifications
  • ProcessorIntel® Core™ i7
  • Memory8 GB
  • Storage1 TB
  • GraphicsNVIDIA® GeForce® GTX 750 Ti
  • SpeedWi-Fi 5 (802.11ac)
  • TypeMini PC
See all specifications

Overview

Processor
Intel® Core™ i7
Memory
8 GB
Storage
1 TB
Graphics
NVIDIA® GeForce® GTX 750 Ti
Speed
Wi-Fi 5 (802.11ac)
Type
Mini PC
Brand
ASUS
Model
GR8-R076R
Part number
GR8-R076R
EAN / UPC
4716659947226
Also known as
ASUS ROG GR8-R076R PC/workstation Intel® Core™ i7 i7-4510U 8 GB DDR3L-SDRAM 1 TB HDD NVIDIA® GeForce® GTX 750 Ti Windows 8.1 Mini PC Black, Red

Specifications

137 specifications in 16 groups

Processor

Processor manufacturerIntel
Processor familyIntel® Core™ i7
Processor generation4th gen Intel® Core™ i7
Processor modeli7-4510U
Processor cores2
Processor threads4
Processor boost frequency3.1 GHz
Processor frequency2 GHz
Processor cache4 MB
Processor cache typeSmart Cache
Bus typeDMI2
FSB ParityNo
System bus rate5 GT/s
Processor lithography22 nm
Processor operating modes64-bit
Processor seriesIntel Core i7-4500 Mobile series
Processor codenameHaswell
Thermal Design Power (TDP)15 W
Tjunction100 °C
Maximum number of PCI Express lanes12
PCI Express configurations4x1, 2x4
PCI Express slots version2.0
Number of processors installed1
Processor socketBGA 1168
SteppingD0
Maximum internal memory supported by processor16 GB
Memory types supported by processorDDR3L-SDRAM, LPDDR3-SDRAM
Memory clock speeds supported by processor1333,1600 MHz
Memory bandwidth supported by processor (max)25.6 GB/s
ECC supported by processorNo

Memory

Internal memory8 GB
Maximum internal memory16 GB
Internal memory typeDDR3L-SDRAM
Memory slots2x SO-DIMM
Memory clock speed1600 MHz
Memory channelsDual-channel

Storage

Total storage capacity1 TB
Storage mediaHDD

Graphics

On-board graphics cardYes
Discrete graphics card modelNVIDIA® GeForce® GTX 750 Ti
Discrete graphics card memory2 GB
On-board graphics card familyIntel® HD Graphics
On-board graphics card modelIntel® HD Graphics 4400
Maximum on-board graphics card memory1.74 GB
Number of displays supported (on-board graphics)3
On-board graphics card base frequency200 MHz
On-board graphics card dynamic frequency (max)1100 MHz
On-board graphics card DirectX version11.2/12
On-board graphics card ID0xA16
On-board graphics card OpenGL version4.3
Graphics card Open GL supportYes

Performance

Product typeMini PC

Network

Ethernet LANYes
Ethernet LAN data rates10,100,1000 Mbit/s
Wi-FiYes
Top Wi-Fi standardWi-Fi 5 (802.11ac)
Wi-Fi standards802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)

Ports & interfaces

USB 2.0 ports quantity2
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity4
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity0
DisplayPorts quantity1
HDMI ports quantity1
Ethernet LAN (RJ-45) ports1
Headphone outputs1
Microphone inYes
VGA (D-Sub) ports quantity0
DVI portNo
S/PDIF out portYes
DC-in jackYes
Number of SATA III connectors4

Power

Power supply120 W

Design

Chassis typeMini PC
Volume2.5 L
Cable lock slotYes
Cable lock slot typeKensington
Product colourBlack, Red

Software

Operating system installedWindows 8.1

Display

Display includedNo

Processor special features

CPU configuration (max)1
Embedded options availableNo
Enhanced Intel SpeedStep TechnologyYes
Execute Disable BitYes
Idle StatesYes
Intel 64Yes
Intel Clear Video TechnologyNo
Intel Demand Based SwitchingNo
Intel Dual Display Capable TechnologyNo
Intel Enhanced Halt StateYes
Intel FDI TechnologyYes
Intel Fast Memory AccessNo
Intel Flex Memory AccessNo
Intel HD GraphicsYes
Intel Identity Protection Technology version1.00
Intel ME Firmware Version9.5
Intel Rapid Storage TechnologyYes
Intel Secure Key Technology version1.00
Intel Smart Connect Technology version1.00
Intel TSX-NINo
Intel TSX-NI version0.00
Intel Trusted Execution TechnologyNo
Intel VT-x with Extended Page Tables (EPT)Yes
Intel Virtualization Technology (VT-x)Yes
Intel Virtualization Technology for Directed I/O (VT-d)No
Intel® AES New Instructions (Intel® AES-NI)Yes
Intel® Built-in Visuals TechnologyYes
Intel® Clear Video HD Technology (Intel® CVT HD)Yes
Intel® Clear Video Technology for Mobile Internet Devices (Intel CVT for MID)No
Intel® High Definition Audio (Intel® HD Audio)Yes
Intel® InTru™ 3D TechnologyYes
Intel® Insider™Yes
Intel® Secure KeyYes
Intel® Smart CacheYes
Intel® Virtualization Technology (Intel® VT)VT-x
Intel® Wireless Display (Intel® WiDi)Yes
Processor ARK ID81015
Processor codeSR1EB
Processor package size40 x 24 x 1.5 mm
Supported instruction setsAVX 2.0, SSE4.1, SSE4.2
Thermal Monitoring TechnologiesYes
Intel® Turbo Boost Technology2.0
Intel Smart Connect TechnologyYes
Intel® Hyper Threading Technology (Intel® HT Technology)Yes
Intel® Quick Sync Video TechnologyYes
Intel® My WiFi Technology (Intel® MWT)No
Intel® Identity Protection Technology (Intel® IPT)Yes
Intel® Anti-Theft Technology (Intel® AT)Yes
Conflict-Free processorYes

Weight & dimensions

Width60 mm
Depth245 mm
Height238 mm
Weight1.28 kg

Packaging content

Mouse includedYes
Keyboard includedYes
AC adapter includedYes
ManualYes

Sustainability

Sustainability certificatesENERGY STAR

Certificates

CertificationBSMI/CB/CE/FCC/UL/Energy Star/C-Tick/VCCI
