ASUS ESC500 G4-M2W

ASUS ESC500 G4-M2W

Model ESC500 G4-M2WPart no. 90SV04ZA-M2WCE0

51 specifications
  • ProcessorIntel® Xeon® E3 Family
  • Memory8 GB
  • Storage1 TB
  • TypeWorkstation
  • OSNo
  • Weight12.7 kg
See all specifications

Overview

Processor
Intel® Xeon® E3 Family
Memory
8 GB
Storage
1 TB
Type
Workstation
OS
No
Weight
12.7 kg
Brand
ASUS
Model
ESC500 G4-M2W
Part number
90SV04ZA-M2WCE0
Also known as
ASUS ESC500 G4-M2W Intel® Xeon® E3 Family E3-1245V6 8 GB DDR4-SDRAM 1 TB HDD Tower Workstation Black

Specifications

51 specifications in 16 groups

Processor

Processor manufacturerIntel
Processor familyIntel® Xeon® E3 Family
Processor modelE3-1245V6
Processor cores4
Processor threads8
Processor boost frequency4.1 GHz
Processor frequency3.7 GHz
Processor cache8 MB
Number of processors installed1

Memory

Internal memory8 GB
Maximum internal memory64 GB
Internal memory typeDDR4-SDRAM

Storage

Total storage capacity1 TB
Storage mediaHDD
Number of storage drives installed1
Number of HDDs installed1
HDD capacity1 TB

Graphics

On-board graphics cardYes
On-board graphics card modelIntel® HD Graphics P630

Performance

Product typeWorkstation
Motherboard chipsetIntel® C236

Network

Ethernet LANYes

Ports & interfaces

USB 2.0 ports quantity2
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity6
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity0
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity1
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity1
Thunderbolt 3 ports quantity0
DisplayPorts quantity1
HDMI ports quantity1
Ethernet LAN (RJ-45) ports2
Headphone outputs1
Microphone inYes
VGA (D-Sub) ports quantity1
DVI portYes
S/PDIF out portYes

Design

Chassis typeTower
Product colourBlack

Software

Operating system installedNo

Display

Display includedNo

Operational conditions

Operating temperature (T-T)10 - 35 °C
Storage temperature (T-T)-40 - 70 °C
Storage relative humidity (H-H)20 - 90%

Weight & dimensions

Width423 mm
Depth190 mm
Height435 mm
Weight12.7 kg

Packaging data

Package weight14.5 kg

Sustainability

Sustainability certificatesENERGY STAR

Certificates

CertificationBSMI, CCC, CE, FCC(Class B), Energy Star

Logistics data

Harmonized System (HS) code84715000
