ESC500 G4

Model ESC500 G4Part no. 90SV04ZA-M7CCE0EAN 4718017001427

89 specifications

Overview

Brand: ASUS
Category: PCs/Workstations
Model: ESC500 G4
Part numbers: 90SV04ZA-M7CCE0, 90SV04ZA-M01CE0, 90SV04ZA-M2VCE0, 90SV04ZA-M2SCE0, 90SV04ZA-M3PCE0, 90SV04ZA-M3QCE0 +8 more
EAN / UPC: 4718017001427, 889349378427, 4712900378429, 4712900829334 +11 more
Also known as: ASUS ESC500 G4 Intel® Core™ i5 i5-7500 8 GB DDR4-SDRAM 256 GB SSD Tower Workstation Black

89 specifications in 20 groups

Specification	Value
Processor manufacturer	Intel
Processor family	Intel® Core™ i5
Processor generation	7th gen Intel® Core™ i5
Processor model	i5-7500
Processor cores	4
Processor threads	4
Processor boost frequency	3.8 GHz
Processor frequency	3.4 GHz
Processor cache	6 MB
Processor cache type	Smart Cache
Bus type	DMI3
Number of processors installed	1
Processor socket	LGA 1151 (Socket H4)

Specification	Value
Total storage capacity	256 GB
Optical drive type	DVD±RW
Storage media	SSD
Number of storage drives installed	1
Total SSDs capacity	256 GB
Number of SSDs installed	1
SSD capacity	256 GB

Specification	Value
Discrete graphics card	No
On-board graphics card	Yes
Discrete graphics card model	Not available
On-board graphics card model	Intel® HD Graphics 630
Maximum on-board graphics card memory	64 GB
Graphics card Open GL support	Yes

Specification	Value
Product type	Workstation
Motherboard chipset	Intel® C236

Specification	Value
Optical drives quantity	1

Specification	Value
Ethernet LAN	Yes

Specification	Value
USB 2.0 ports quantity	2
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	6
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity	0
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity	1
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity	1
Thunderbolt 3 ports quantity	0
DisplayPorts quantity	1
HDMI ports quantity	1
Ethernet LAN (RJ-45) ports	2
Headphone outputs	1
Microphone in	Yes
VGA (D-Sub) ports quantity	1
DVI port	Yes
S/PDIF out port	Yes

Specification	Value
Number of 3.5" bays	3
PCI Express x16 slots	4

Specification	Value
Power supply input voltage	100 - 240 V
Power supply input frequency	50 - 60 Hz

Specification	Value
Operating system installed	No

Specification	Value
Display included	No

Specification	Value
CPU configuration (max)	1
Embedded options available	Yes
Enhanced Intel SpeedStep Technology	Yes
Execute Disable Bit	Yes
Idle States	Yes
Intel 64	Yes
Intel Clear Video Technology	Yes
Intel Enhanced Halt State	Yes
Intel Identity Protection Technology version	1.00
Intel Secure Key Technology version	1.00
Intel Software Guard Extensions (Intel SGX)	Yes
Intel Stable Image Platform Program (SIPP)	Yes
Intel Stable Image Platform Program (SIPP) version	1.00
Intel TSX-NI	Yes
Intel TSX-NI version	1.00
Intel Trusted Execution Technology	Yes
Intel VT-x with Extended Page Tables (EPT)	Yes
Intel Virtualization Technology (VT-x)	Yes
Intel Virtualization Technology for Directed I/O (VT-d)	Yes
Conflict-Free processor	Yes
