ASUS EeeBox PC B202

Model EeeBox PC B202Part no. 90PE0MC513208B59UCHZEAN 610839783168

98 specifications

ProcessorIntel Pentium Mobile
Memory1 GB
Storage160 GB
GraphicsIntel® GMA 950
TypePC
OSWindows XP Home Edition

See all specifications

Overview

Processor: Intel Pentium Mobile
Memory: 1 GB
Storage: 160 GB
Graphics: Intel® GMA 950
Type: PC
OS: Windows XP Home Edition

Brand: ASUS
Category: PCs/Workstations
Model: EeeBox PC B202
Part numbers: 90PE0MC513208B59UCHZ, 90PE0MC213203B59UCHZ, EBXB202-WHX0057, EBXB202-BKL0043, 90PE0MC213203452UC0Q, 90PE0MC313203452UC0Q +22 more
EAN / UPC: 610839783168, 610839783175, 610839769018, 4719543696705 +18 more
Also known as: ASUS Eee PC EeeBox PC B202 Intel Pentium Mobile N270 1 GB DDR2-SDRAM 160 GB Intel® GMA 950 Windows XP Home Edition SFF Black

Specifications

98 specifications in 17 groups

Processor

Specification	Value
Processor manufacturer	Intel
Processor family	Intel Pentium Mobile
Processor model	N270
Processor cores	1
Processor threads	2
Processor frequency	1.6 GHz
Processor cache	0.512 MB
Processor cache type	L2
Processor front side bus	533 MHz
Bus type	FSB
FSB Parity	No
Processor lithography	45 nm
Processor operating modes	32-bit
Processor series	Intel Atom N200 Series
Processor codename	Diamondville
Thermal Design Power (TDP)	2.5 W
Tjunction	90 °C
Number of processors installed	1
Processor socket	Socket F (1207)
Number of Processing Die Transistors	47 M
Processing Die size	26 mm²
CPU multiplier (bus/core ratio)	12
Stepping	C0
ECC supported by processor	No

Memory

Specification	Value
Internal memory	1 GB
Internal memory type	DDR2-SDRAM

Storage

Specification	Value
Total storage capacity	160 GB
Optical drive type	No
HDD interface	SATA II
HDD speed	5400 RPM
Card reader integrated	Yes
Floppy drive installed	No

Graphics

Specification	Value
On-board graphics card	Yes
Discrete graphics card model	Intel® GMA 950

Performance

Specification	Value
Product type	PC

Network

Specification	Value
Ethernet LAN	Yes
Wi-Fi	Yes
Networking features	802.11b/g

Ports & interfaces

Specification	Value
USB 2.0 ports quantity	4
HDMI ports quantity	0
Ethernet LAN (RJ-45) ports	1
Headphone outputs	3
Microphone in	Yes
VGA (D-Sub) ports quantity	0
DVI port	Yes
PS/2 ports quantity	0
Firewire (IEEE 1394) ports	0
S/PDIF out port	Yes
Serial ports quantity	0
Parallel ports quantity	0

Power

Specification	Value
Power supply type	19V DC
Power supply	65 W

Design

Specification	Value
Chassis type	SFF
Product colour	Black

Software

Specification	Value
Operating system installed	Windows XP Home Edition

Display

Specification	Value
Display included	No

Processor special features

Specification	Value
Embedded options available	Yes
Enhanced Intel SpeedStep Technology	Yes
Execute Disable Bit	Yes
Idle States	No
Intel 64	No
Intel Clear Video Technology	No
Intel Demand Based Switching	No
Intel Dual Display Capable Technology	No
Intel Enhanced Halt State	No
Intel FDI Technology	No
Intel Fast Memory Access	No
Intel Flex Memory Access	No
Intel Rapid Storage Technology	No
Intel Trusted Execution Technology	No
Intel VT-x with Extended Page Tables (EPT)	No
Intel Virtualization Technology (VT-x)	No
Intel Virtualization Technology for Directed I/O (VT-d)	No
Intel® AES New Instructions (Intel® AES-NI)	No
Intel® Clear Video HD Technology (Intel® CVT HD)	No
Intel® Clear Video Technology for Mobile Internet Devices (Intel CVT for MID)	No
Intel® InTru™ 3D Technology	No
Intel® Insider™	No
Intel® Wireless Display (Intel® WiDi)	No
Processor ARK ID	36331
Processor code	SLB73
Processor package size	22 x 22 mm
Supported instruction sets	SSE2, SSE3
Thermal Monitoring Technologies	Yes
Intel® Turbo Boost Technology	No
Intel® Hyper Threading Technology (Intel® HT Technology)	Yes
Intel® Quick Sync Video Technology	No
Intel® My WiFi Technology (Intel® MWT)	No
Intel® Anti-Theft Technology (Intel® AT)	No
Conflict-Free processor	No

Audio

Specification	Value
Audio system	Realtek ALC662

Ergonomics

Specification	Value
Acoustic pressure emissions	26 dB

Weight & dimensions

Specification	Value
Width	222 mm
Depth	178 mm
Height	26.9 mm
Weight	1 kg

Packaging content

Specification	Value
Remote control included	No

Other features

Specification	Value
TV tuner integrated	No
