ASUS D820MT-I7670V0010 PC Intel® Core™ i7 i7-6700

ASUS D820MT-I7670V0010 PC Intel® Core™ i7 i7-6700

8 GB DDR4-SDRAM 1 TB HDD FreeDOS Mini Tower Black

Model D820MT-I7670V0010

142 specifications
  • ProcessorIntel® Core™ i7
  • Memory8 GB
  • Storage1 TB
  • TypePC
  • OSFreeDOS
  • Weight13.5 kg
See all specifications

Overview

Processor
Intel® Core™ i7
Memory
8 GB
Storage
1 TB
Type
PC
OS
FreeDOS
Weight
13.5 kg
Brand
ASUS
Model
D820MT-I7670V0010
Part number
D820MT-I7670V0010
Also known as
ASUS D820MT-I7670V0010 PC Intel® Core™ i7 i7-6700 8 GB DDR4-SDRAM 1 TB HDD FreeDOS Mini Tower Black

Specifications

142 specifications in 18 groups

Processor

Processor manufacturerIntel
Processor familyIntel® Core™ i7
Processor generation6th gen Intel® Core™ i7
Processor modeli7-6700
Processor cores4
Processor threads8
Processor boost frequency4 GHz
Processor frequency3.4 GHz
Processor cache8 MB
Processor cache typeSmart Cache
Bus typeDMI3
FSB ParityNo
System bus rate8 GT/s
Processor lithography14 nm
Processor operating modes64-bit
Processor seriesIntel Core i7-6700 Desktop series
Processor codenameSkylake
Thermal Design Power (TDP)65 W
Tcase71 °C
Maximum number of PCI Express lanes16
PCI Express configurations2x8, 1x8+2x4, 1x16
PCI Express slots version3.0
Processor socketLGA 1151 (Socket H4)
SteppingR0
Maximum internal memory supported by processor64 GB
Memory types supported by processorDDR3L-SDRAM, DDR4-SDRAM
Memory clock speeds supported by processor1333,1600,1866,2133 MHz
Memory bandwidth supported by processor (max)34.1 GB/s
ECC supported by processorNo
Memory voltage supported by processor1.35 V

Memory

Internal memory8 GB
Maximum internal memory64 GB
Internal memory typeDDR4-SDRAM
Memory slots4x DIMM
Memory clock speed2133 MHz
Memory channelsDual-channel

Storage

Total storage capacity1 TB
Optical drive typeDVD Super Multi
Storage mediaHDD
Card reader integratedYes
Compatible memory cardsCF, MMC, MS Duo, MS Micro (M2), MS PRO, MS PRO Duo, Memory Stick (MS), MicroDrive, MicroSD (TransFlash), MiniMMC, MiniSD, RS-MMC, SD, SDHC

Graphics

On-board graphics cardYes
On-board graphics card familyIntel® HD Graphics
On-board graphics card modelIntel® HD Graphics 530
Maximum on-board graphics card memory1.74 GB
Number of displays supported (on-board graphics)3
On-board graphics card base frequency350 MHz
On-board graphics card dynamic frequency (max)1150 MHz
On-board graphics card DirectX version12.0
On-board graphics card ID1912
On-board graphics card OpenGL version4.4
Graphics card Open GL supportYes

Performance

Product typePC
Motherboard chipsetIntel® Q170

Optical drive

Optical drives quantity1

Network

Ethernet LANYes
Ethernet LAN data rates10,100,1000 Mbit/s

Ports & interfaces

USB 2.0 ports quantity2
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity6
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity2
DisplayPorts quantity1
HDMI ports quantity1
Ethernet LAN (RJ-45) ports2
Headphone outputs1
Microphone inYes
VGA (D-Sub) ports quantity1
DVI portNo
PS/2 ports quantity2

Expansion slots

PCI Express x16 slots2
PCI slots1

Design

Chassis typeMini Tower
Cable lock slotYes
Cable lock slot typeKensington
Product colourBlack

Software

Operating system installedFreeDOS

Display

Display includedNo

Processor special features

CPU configuration (max)1
Embedded options availableYes
Enhanced Intel SpeedStep TechnologyYes
Execute Disable BitYes
Graphics & IMC lithography14 nm
Idle StatesYes
Intel 64Yes
Intel Clear Video TechnologyYes
Intel Demand Based SwitchingNo
Intel Dual Display Capable TechnologyNo
Intel Enhanced Halt StateYes
Intel FDI TechnologyNo
Intel Fast Memory AccessNo
Intel Flex Memory AccessNo
Intel HD GraphicsYes
Intel Identity Protection Technology version1.00
Intel Rapid Storage TechnologyNo
Intel Secure Key Technology version1.00
Intel Small Business Advantage (SBA) version1.00
Intel Software Guard Extensions (Intel SGX)Yes
Intel Stable Image Platform Program (SIPP)Yes
Intel Stable Image Platform Program (SIPP) version1.00
Intel TSX-NIYes
Intel TSX-NI version1.00
Intel Trusted Execution TechnologyYes
Intel VT-x with Extended Page Tables (EPT)Yes
Intel Virtualization Technology (VT-x)Yes
Intel Virtualization Technology for Directed I/O (VT-d)Yes
Intel® AES New Instructions (Intel® AES-NI)Yes
Intel® Built-in Visuals TechnologyYes
Intel® Clear Video HD Technology (Intel® CVT HD)Yes
Intel® Clear Video Technology for Mobile Internet Devices (Intel CVT for MID)Yes
Intel® InTru™ 3D TechnologyYes
Intel® Insider™Yes
Intel® OS GuardYes
Intel® Secure KeyYes
Intel® Small Business Advantage (Intel® SBA)Yes
Intel® Smart CacheYes
Intel® Wireless Display (Intel® WiDi)Yes
Processor ARK ID88196
Processor codeSR2BT
Processor package size37.5 x 37.5 mm
Scalability1S
Supported instruction setsSSE4.1, AVX 2.0, SSE4.2
Thermal Monitoring TechnologiesYes
Thermal solution specificationPCG 2015C
Intel® Turbo Boost Technology2.0
Intel® Hyper Threading Technology (Intel® HT Technology)Yes
Intel® Quick Sync Video TechnologyYes
Intel® My WiFi Technology (Intel® MWT)No
Intel® Identity Protection Technology (Intel® IPT)Yes
Intel® Anti-Theft Technology (Intel® AT)No
Conflict-Free processorYes

Weight & dimensions

Width181 mm
Depth365 mm
Height398 mm
Weight13.5 kg

Packaging data

Package width295 mm
Package depth490 mm
Package height520 mm

Packaging content

Mouse includedYes
Keyboard includedYes
AC adapter includedYes
ManualYes

Sustainability

Sustainability certificatesEPEAT Gold, ENERGY STAR

Certificates

CertificationBSMI/CB/CE/FCC/UL/CCC/Energy Star/EPEAT /CECP/RCM
