Aurora 6

Model Aurora 6Part no. ALIEN_R4_008

130 specifications

Overview

Brand: Alienware
Category: PCs/Workstations
Model: Aurora 6
Part numbers: ALIEN_R4_008, ALIEN_R4_009
Also known as: Alienware Aurora 6 Intel® Core™ i7 X-series i7-3820 8 GB DDR3-SDRAM 2 TB AMD Radeon HD 7870 Windows 7 Home Premium Midi Tower PC Black

130 specifications in 17 groups

Specification	Value
Processor manufacturer	Intel
Processor family	Intel® Core™ i7 X-series
Processor generation	3rd gen Intel® Core™ i7
Processor model	i7-3820
Processor cores	4
Processor threads	8
Processor boost frequency	3.8 GHz
Processor frequency	3.6 GHz
Processor cache	10 MB
Processor cache type	Smart Cache
Processor front side bus	1600 MHz
Bus type	DMI
FSB Parity	No
System bus rate	5 GT/s
Processor lithography	32 nm
Processor operating modes	64-bit
Processor series	Intel Core i7-3800 Desktop Series
Processor codename	Sandy Bridge E
Thermal Design Power (TDP)	130 W
Tcase	66.8 °C
Maximum number of PCI Express lanes	40
PCI Express slots version	2.0
Processor socket	LGA 2011 (Socket R)
CPU multiplier (bus/core ratio)	44
Stepping	M1
Maximum internal memory supported by processor	64 GB
Memory types supported by processor	DDR3-SDRAM
Memory clock speeds supported by processor	1066,1333,1600 MHz
Memory bandwidth supported by processor (max)	51.2 GB/s
ECC supported by processor	No

Specification	Value
On-board graphics card	No
Discrete graphics card model	AMD Radeon HD 7870
Discrete graphics card memory	2 GB
Discrete graphics memory type	GDDR5
Number of discrete graphics cards	2
On-board graphics card model	Not available
Graphics card family	AMD

Specification	Value
Optical drives quantity	1

Specification	Value
USB 2.0 ports quantity	6
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	2
HDMI ports quantity	1
Ethernet LAN (RJ-45) ports	1
Headphone outputs	2
Line-in	Yes
Microphone in	Yes
VGA (D-Sub) ports quantity	1
DVI port	Yes
Mini HDMI ports quantity	1
PS/2 ports quantity	0
Firewire (IEEE 1394) ports	0
S/PDIF out port	Yes
Serial ports quantity	0
Parallel ports quantity	0

Specification	Value
PCI Express x1 slots	2
PCI Express x16 slots	2

Specification	Value
Power supply	875 W

Specification	Value
Chassis type	Midi Tower
Product colour	Black

Specification	Value
Operating system installed	Windows 7 Home Premium
Operating system architecture	64-bit

Specification	Value
Display included	No

Specification	Value
CPU configuration (max)	1
Embedded options available	No
Enhanced Intel SpeedStep Technology	Yes
Execute Disable Bit	Yes
Idle States	Yes
Intel 64	Yes
Intel Clear Video Technology	No
Intel Demand Based Switching	No
Intel Dual Display Capable Technology	No
Intel Enhanced Halt State	Yes
Intel FDI Technology	No
Intel Fast Memory Access	No
Intel Flex Memory Access	No
Intel Identity Protection Technology version	1.00
Intel Rapid Storage Technology	No
Intel Smart Response Technology version	1.00
Intel Trusted Execution Technology	No
Intel VT-x with Extended Page Tables (EPT)	Yes
Intel Virtualization Technology (VT-x)	Yes
Intel Virtualization Technology for Directed I/O (VT-d)	Yes
Intel® AES New Instructions (Intel® AES-NI)	Yes
Intel® Clear Video HD Technology (Intel® CVT HD)	No
Intel® Clear Video Technology for Mobile Internet Devices (Intel CVT for MID)	No
Intel® InTru™ 3D Technology	No
Intel® Insider™	No
Intel® Smart Cache	Yes
Intel® Wireless Display (Intel® WiDi)	No
Processor ARK ID	63698
Processor code	SR0LD
Processor package size	52.5 x 45.0 mm
Supported instruction sets	AVX, SSE4.2
Thermal Monitoring Technologies	Yes
Intel® Smart Response Technology	Yes
Intel® Turbo Boost Technology	2.0
Intel® Hyper Threading Technology (Intel® HT Technology)	Yes
Intel® Quick Sync Video Technology	No
Intel® My WiFi Technology (Intel® MWT)	No
Intel® Identity Protection Technology (Intel® IPT)	Yes
Intel® Anti-Theft Technology (Intel® AT)	No
Conflict-Free processor	No
