Area-51 R7
Model Area-51 R7Part no. 51R7-4146EAN 5397184204146
144 specifications
- ProcessorAMD Ryzen™ Threadripper™
- Memory64 GB
- Storage2.51 TB
- GraphicsNVIDIA® GeForce RTX™ 2080 Ti
- SpeedWi-Fi 5 (802.11ac)
- TypePC
Overview
- Processor
- AMD Ryzen™ Threadripper™
- Memory
- 64 GB
- Storage
- 2.51 TB
- Graphics
- NVIDIA® GeForce RTX™ 2080 Ti
- Speed
- Wi-Fi 5 (802.11ac)
- Type
- PC
- Brand
- Alienware
- Category
- PCs/Workstations
- Model
- Area-51 R7
- Part number
- 51R7-4146
- EAN / UPC
- 5397184204146
- Also known as
- Alienware Area-51 R7 AMD Ryzen™ Threadripper™ 2950X 64 GB DDR4-SDRAM 2.51 TB HDD+SSD NVIDIA® GeForce RTX™ 2080 Ti Windows 10 Home Tower PC Liquid cooling system
Specifications
144 specifications in 21 groups
Processor
| Specification | Value |
|---|---|
| Processor manufacturer | AMD |
| Processor family | AMD Ryzen™ Threadripper™ |
| Processor generation | AMD Ryzen Threadripper 2000 Series |
| Processor model | 2950X |
| Processor cores | 16 |
| Processor threads | 32 |
| Processor boost frequency | 4.4 GHz |
| Processor frequency | 3.5 GHz |
| Processor cache | 32 MB |
| Processor cache type | L3 |
| Processor lithography | 12 nm |
| Thermal Design Power (TDP) | 180 W |
| PCI Express slots version | 3.0 |
| Number of processors installed | 1 |
| Processor socket | Socket TR4 |
| Memory types supported by processor | DDR4-SDRAM |
| Memory clock speeds supported by processor | 2933 MHz |
Memory
| Specification | Value |
|---|---|
| Internal memory | 64 GB |
| Maximum internal memory | 64 GB |
| Internal memory type | DDR4-SDRAM |
| Memory slots | 4x DIMM |
| Memory clock speed | 2933 MHz |
Storage
| Specification | Value |
|---|---|
| Total storage capacity | 2.51 TB |
| Optical drive type | DVD±RW |
| Storage media | HDD+SSD |
| Number of storage drives installed | 2 |
| Number of HDDs installed | 1 |
| HDD capacity | 2 TB |
| HDD interface | SATA III |
| HDD speed | 7200 RPM |
| Number of SSDs installed | 1 |
| SSD capacity | 512 GB |
| SSD interface | PCI Express |
| Card reader integrated | No |
Graphics
| Specification | Value |
|---|---|
| Discrete graphics card | Yes |
| On-board graphics card | No |
| Discrete graphics card model | NVIDIA® GeForce RTX™ 2080 Ti |
| Discrete graphics card memory | 11 GB |
| Discrete graphics memory type | GDDR6 |
| Number of discrete graphics cards | 1 |
| On-board graphics card model | Not available |
| CUDA | Yes |
| CUDA cores | 4352 |
| NVIDIA G-SYNC | Yes |
| Graphics card DisplayPorts quantity | 3 |
| Graphics card HDMI ports quantity | 1 |
Performance
| Specification | Value |
|---|---|
| Product type | PC |
| Market positioning | Gaming |
| Virtual Reality (VR) ready | Yes |
| Motherboard chipset | AMD X399 |
| Audio output channels | 7.1 channels |
Optical drive
| Specification | Value |
|---|---|
| Optical drives quantity | 1 |
Network
| Specification | Value |
|---|---|
| Ethernet LAN | Yes |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| Cabling technology | 10/100/1000Base-T(X) |
| Wi-Fi | Yes |
| Top Wi-Fi standard | Wi-Fi 5 (802.11ac) |
| Wi-Fi standards | 802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n) |
| WLAN controller model | Killer Wireless-AC 1535 |
| Antenna type | 2x2 |
| Bluetooth | Yes |
| Bluetooth version | 4.1 |
Ports & interfaces
| Specification | Value |
|---|---|
| USB 2.0 ports quantity | 2 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 10 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity | 0 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity | 1 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity | 1 |
| Thunderbolt 3 ports quantity | 0 |
| HDMI ports quantity | 0 |
| Ethernet LAN (RJ-45) ports | 2 |
| Headphone outputs | 1 |
| Line-out | Yes |
| Line-in | Yes |
| Microphone in | Yes |
| VGA (D-Sub) ports quantity | 0 |
| DVI port | No |
| S/PDIF out port | Yes |
| On/off button | Yes |
Power
| Specification | Value |
|---|---|
| Power supply | 1500 W |
| 80 PLUS certification | 80 PLUS Gold |
Design
| Specification | Value |
|---|---|
| Chassis type | Tower |
| Colour name | Epic Silver |
| Placement supported | Vertical |
| Liquid cooling system | Yes |
| Product colour | Black, Silver |
Software
| Specification | Value |
|---|---|
| Operating system installed | Windows 10 Home |
| Operating system architecture | 64-bit |
| Operating system language | English |
| Trial software | McAfee LiveSafe (30 days Trial), Microsoft Office (30 days Trial) |
| Bundled software | Financial Tracker & Retail Information Cyberlink PowerDVD 18 Ultra Media Player |
Display
| Specification | Value |
|---|---|
| Display included | No |
Audio
| Specification | Value |
|---|---|
| Audio chip | Realtek ALC3861 |
| Audio system | High Definition Audio |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 35 °C |
| Storage temperature (T-T) | -40 - 65 °C |
| Operating relative humidity (H-H) | 10 - 90% |
| Storage relative humidity (H-H) | 0 - 95% |
| Operating altitude | -15.2 - 3048 m |
| Non-operating altitude | -15.2 - 10668 m |
| Operating vibration | 0.66 G |
| Non-operating vibration | 1.3 G |
| Operating shock | 110 G |
| Non-operating shock | 160 G |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 272.7 mm |
| Depth | 639 mm |
| Height | 569.2 mm |
| Weight | 28 kg |
Packaging data
| Specification | Value |
|---|---|
| Package width | 490 mm |
| Package depth | 597 mm |
| Package height | 387.7 mm |
| Package weight | 15.3 kg |
Packaging content
| Specification | Value |
|---|---|
| Mouse included on selected markets only | Yes |
| Keyboard included on selected markets only | Yes |
| Manual | Yes |
| Power cord included | Yes |
Recycling data
| Specification | Value |
|---|---|
| Paper molded pulp content per package | 0 g |
| Bamboo molded pulp content per package | 0 g |
| Wheat straw molded pulp content per package | 0 g |
| Grey board content per package | 0 g |
| Corrugated cardboard content per package | 2.72 kg |
| Corrugated cardboard content per shipping (inner) case | 2.22 kg |
| Corrugated cardboard content per box for accessories | 491.9 g |
| Corrugated cardboard content per sleeve for accessories | 0 g |
| Polyethylene terephthalate (PET) content per package | 0 g |
| High-density polyethylene (HDPE) content per package | 0 g |
| Low-density polyethylene (LDPE) content per package | 431 g |
| Polypropylene (PP) content per package | 0 g |
| Polystyrene (PS) content per package | 0 g |
| Other materials content per package | 0 g |
Sustainability
| Specification | Value |
|---|---|
| EPEAT rating | 86.93% |
| Sustainability certificates | No |
Keyboard
| Specification | Value |
|---|---|
| Keyboard layout | QWERTY |
| Keyboard language | UK English |
| Windows keys | Yes |
Logistics data
| Specification | Value |
|---|---|
| Products per intermodal container (20ft) | 160 pc(s) |
| Products per intermodal container (40ft) | 336 pc(s) |
| Pallet gross width | 100 cm |
| Pallet gross length | 120 cm |
| Pallet gross weight | 130.2 kg |
| Pallet volume weight | 183.1 kg |
| Package volume weight | 18.902 kg |
| Products per pallet layer | 4 pc(s) |
| Layers per pallet | 2 pc(s) |
| Products per pallet | 8 pc(s) |
